OpenEye E Series Quick Reference Manual

This guide is a quick reference for users to operate OpenEye E-
Series recorders, and only provides basic information on settings
and operation. For questions regarding information that is not
presented here, please read the user manual thoroughly.
LOGGING IN
Log in to your E-Series recorder using your Manager account.
1. Right-click on the Live screen and then click Setup.
2. Click the User field to select your Manager account.
3. Click the Password field, and then use the on-screen keyboard to
type your password.
LIVE DISPLAY MODE
You can view live video from multiple channels at one time in 4, 9,
and 16-channel combinations. You can also select a two-channel
picture in picture (PiP) screen. Press LIVE on the front of the
recorder to toggle through the viewing options.
Single-channel
To view live video from a specific channel, press the channel but-
ton on the front of the recorder, or double-click the channel on the
Live screen. To return to the previous screen mode, double-click
again.
Multi-screen
When viewing in 4 and 19-channel combinations, toggle to the
next group of channels by pressing the LEFT and RIGHT arrow
buttons.
Picture in Picture (PiP)
When using the PiP channel combination, toggle through chan-
nels in the inset window by pressing the LEFT and RIGHT arrow
buttons.
MOUSE-OVER MENU
Move the mouse pointer to the bottom of the monitor in Live mode to see
the mouse-over menu.
Sequence - Click to start a camera sequence.
Emergency Recording - Click to start
emergency recording. The system will record all
channels.
PTZ Mode - Click to control PTZ camera chan-
nels.
E-SERIES RECORDER
QUICK REFERENCE GUIDE
RIGHT-CLICK MENU
Right-click the Live screen to
open the Right-click Menu.
Hide Live View - Hide the
selected camera from Live view.
Record Change - Change
the recording settings for the
selected channel, including PPS,
Quality, Resolution, and Event
Response.
Page Sequence - Channel
screens will display in sequence,
depending on the current
configuration of the Live screen.
Freeze All - Pause all channels
displayed on screen.
Show Motion Area - Display the motion grid for the selected camera.
Display PiP - Change the screen to display Picture in Picture.
Audio - Select an audio channel to be played on speakers attached to the
recorder.
Logoff - Log out as a user or Manager.
Search - Open the Search menu.
PTZ - Switch to PTZ mode to control PTZ camera channels.
Setup - Open the Setup menu.
• Click Menu to access the Setup, Search, or Export menus.
• Click the channel numbers to view channels in full screen, or click the
display mode options to view multiple screens at once.
Quick Search - Click to automatically play back
the most recent video clip.
Dock Tool Menu - Click to make the mouse-
over menu visible at all times.
