QUARTZ-G3 Range
External Sounder
F
EATURES
- 108dB(A) siren output
- 12v dc voltage operation
- Integral low current LED strobe.
- 2 way tamper protection: cover & rear
- Separate sound and strobe trigger inputs
- Hold-off supply failure detection
- Battery and piezo test with fault output
- Selectable sound auto cut-off timer: 5s (for test)
or 15 minutes
Technical Support Line +44 (0)23 9269 6638 (Option 3)
Models
QUARTZ-1000-G3, QUARTZ-3000-G3
- Full SAB using internal battery
- Twin Comfort LEDs selectable on, off, alternate
flash
- Audible Tamper to assist commissioning
- Ring Line Monitoring
- Engineer Mode for quiet installation and
maintenance
- Polycarbonate cover and backplate
- Microprocessor controlled
PAK200544 Iss 01A Mar 2012
Tel: +44(0)23 9269 6638
Fax: +44(0)23 9266 0483
Web:
www.elmdene.co.uk
©2012 ELMDENE INTERNATIONAL LTD
Advertisement
Table of Contents
Related Manuals for Elmdene Quartz-3000-G3
Summary of Contents for Elmdene Quartz-3000-G3
- Page 1 - Battery and piezo test with fault output maintenance - Selectable sound auto cut-off timer: 5s (for test) - Polycarbonate cover and backplate or 15 minutes - Microprocessor controlled Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
-
Page 2: Operation
Switching this control panel output high when maintenance is required will prevent the sounder from self activating when the cover is removed or R- Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD... - Page 3 (see Figure 3.0) Tamper return connection to control panel. (See Figures 2.0 and 3.0) Negative siren trigger. Negative strobe trigger and supply. Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
- Page 4 Piezo Piezo BATT + BATT – Fault Fault H – R – ST – Figure 1: Board Connections Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
- Page 5 If preferred, pull the ENG i/p high using a programmable control panel output, rather than wiring it directly to H+. Fig 3: Multiple Cascade Quartz-G3 Tamper Connection Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
- Page 6 Fit backplate to wall using minimum of 3 x No. 10 fixing screws suitable for material of mounting surface. TAMPER EXTENDER PARKING COVER SCREW PARKING LOOP CABLE UNDER CABLE CLAMP Fig 4: Backplate Mounting Positions Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
-
Page 7: Maintenance
IMPORTANT: Ensure correct polarity of connections and that exposed battery leads DO NOT accidentally touch. Dispose of used batteries in accordance with all national and local regulations Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD... - Page 8 2 Flashes Battery test failed Change battery 3 Flashes Piezo self test failed Change sounder 4 Flashes Battery charger failure Change sounder Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD...
-
Page 9: Fault Finding
See Specification for battery type information. The battery is marked with the crossed out wheelie bin symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For more information see: www.recyclethis.info Technical Support Line +44 (0)23 9269 6638 (Option 3) PAK200544 Iss 01A Mar 2012 ©2012 ELMDENE INTERNATIONAL LTD... -
Page 10: Specification
PECIFICATION Sounder Volume 105dB(A) single piezo (QUARTZ-1000-G3) 108 dB(A) dual piezo (QUARTZ-3000-G3) Cut off Timer 15 minutes max (5 second test) Waterproofing All electronics conformal coated Operating Temp -25 to + 60 °C Storage Temp -25 to + 70 °C Supply Voltage 9—15V d.c.
