L1 Service Manual
Communication Ltd.
Pixi5-7 3G
9203A
Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior
notice on the characteristics of described equipments.
Rev.
Page
1.1
1/17
9203A Level 1 Service Manual
All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
Advertisement
Table of Contents
Related Manuals for TLC Alcatel Pixi5-7 3G
Summary of Contents for TLC Alcatel Pixi5-7 3G
- Page 1 L1 Service Manual Communication Ltd. Pixi5-7 3G 9203A Note: this manual is non-contractual and TCL Communication Ltd. can modify it without prior notice on the characteristics of described equipments. Rev. Page 1/17 9203A Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
- Page 2 L1 Service Manual Communication Ltd. 2017-2-24 Released Keira Xie 2017-2-7 Preliminary Draft Marvin Chen Keira Xie Rev. Date Modification description Prepared By Checked By Approved By Rev. Page 2/17 9203A Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization.
-
Page 3: Table Of Contents
L1 Service Manual Communication Ltd. Content 1. General ............................. 4 2. Portable Label ..........................6 2.1. Commercial Label Samples......................6 2.2. CU label ............................7 2.3. L1 Spare Part List ..........................7 2.4. Accessory ............................7 2.4.1. Charger ............................7 2.4.2. -
Page 4: General
L1 Service Manual Communication Ltd. 1. General Pixi5-7 3G (9203A) is a MT8321 Platform tablet with Quad core 1.3 GHz, and BT/WLAN/MP3, social network service etc functions. It originally installed Android 6.0 system. It can work with the GSM and W- CDMA (UMTS-FDD, UTRA-FDD) network, 850/900/1900/2100MHz. - Page 5 L1 Service Manual Communication Ltd. RAM Capacity 1GB (512MB/2GB Compatible) External storage Capability up to 32GB Internal, End user memory size 12GB Glonass Bluetooth supported version V4.1 Wi-Fi / WLAN 802.11 b/g/n WIFI direct Connectivity Touch Icon position in LCD VA Wireless Display Capability (Miracast) Bluetooth Tethering...
-
Page 6: Portable Label
L1 Service Manual Communication Ltd. Standby time 430hours 5Hours-3G 10Hours-2G Talking time (Hours) (depend on different network) Charging time [Hours] within 4hours Battery type (RF standby mode) Soft pack 2. Portable Label 2.1. Commercial Label Samples 9203A-2AALMX1 IMEI V01 Rev. Page 6/17 9203A Level 1 Service Manual... -
Page 7: Cu Label
L1 Service Manual Communication Ltd. 2.2. CU label 9203A-2AALMX1 CU V01 2.3. L1 Spare Part List Please get the latest SPL in Forlog system. 2.4. Accessory 2.4.1. Charger Rev. Page 7/17 9203A Level 1 Service Manual All rights reserved. Transfer, copy, use or communication of this file is prohibited without authorization. -
Page 8: End User Usb Cable
L1 Service Manual Communication Ltd. 2.4.2. End user USB cable 2.5. Maintenance policy This chapter describes the maintenance of the 9203A series device authorized at L1 repair centre. The maintenance operations can only be performed in approved repair centres. General Main L1 maintenance operations are as following: 2.5.1. -
Page 9: For Standard Accessories (Charger, Headset And Usb Cable)
L1 Service Manual Communication Ltd. 2.5.2. For standard accessories (charger, headset and USB cable) Warranty check Functional check Replacement of defective accessories 2.5.3. If input the following codes on tablet, you can: Code Description “Settings” -> “About tablet” -> Check IMEI number “Status”... - Page 10 L1 Service Manual Communication Ltd. 2. Press “volume” key to select “wipe data / factory reset”, press “power” key to confirm; 3. Press “volume” key to select “Yes—delete all user data” and the press “power” key to double confirm the factory reset; Rev.
-
Page 11: Tablet Maintenance
L1 Service Manual Communication Ltd. 4. Factory reset complete, press “volume” key to select “reboot system now” and press “power” key to confirm. 2.6. Tablet maintenance Equipments for handset test. Battery with full power. One SIM card. It is recommended the following tools: ... -
Page 12: Invoice Check
L1 Service Manual Communication Ltd. 2.7. Invoice check 1. Check warranty status of Handset by POP (Proof of Purchase) firstly. 2. If the end user lost his POP, then consider the data code on commercial label as the purchasing day. Coding year Coding month Coding day... -
Page 13: Imei Check
L1 Service Manual Communication Ltd. Note: mouth year 2.8. IMEI Check Power on the handset, enter ”Settings” -> “About tablet” -> “Status” -> “IMEI information”. Input 0X0-0+= on calculator screen. There are three IMEI sticker positions on the device: Position 1: in the back casing Position 2: in the PCBA Position 3: in the SD slot cover Rev. -
Page 14: Humidity Sensitive Sticker Check
L1 Service Manual Communication Ltd. If the IMEI sticker in the back casing is not lost: We should make sure that the IMEI number MUST be the same with the one on the IMEI sticker; if not, it‟s out of warranty policy. 2.9. -
Page 15: Visual Mechanical Inspection
L1 Service Manual Communication Ltd. 2.10. Visual Mechanical inspection Please refer to <Visual mechanical check flow chart> in support website (CSS/RSH) for details. 2.11. Accessories inspection Please refer to < Accessories inspection > in support website (CSS/RSH) for details. 2.12. Tablet maintenance procedure Check that the SIM card and SD card are set correctly. -
Page 16: Software Download
L1 Service Manual Communication Ltd. If the tablet asks to input NCK code, which means it is SIM locked, and can only be worked with dedicated SIM card. Use the correct SIM card. Enter the phone code if necessary. If power on, test step by step with the auto test code: Open “Calculator”... - Page 17 L1 Service Manual Communication Ltd. If you have any question or problem, please feel free to contact us. Thanks for your cooperation. TCL Communication Ltd. Global Customer Service TS Dept. Feb,7 , 2017 Rev. Page 17/17 9203A Level 1 Service Manual All rights reserved.
