Popp Wall Controller 2 Manual

Popp
POPP Wall Controller 2
SKU: POPE700861

Quickstart

This is a Z-Wave Device for Europe. To run this device please connect it to your mains power supply. On factory default state pushing any button for one
seconds starts inclusion (red/green LED blinking fast). This behavior can be used to test the factory default or exclusion state.

What is Z-Wave?

Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified
Z-Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.

Product Description

The Popp Wall Controller is a Z-Wave device that can both control other Z-Wave devices and activate predefined scenes in an IP gateway. Although it is
controlling other devices, the Wall Controller cannot act as Z-Wave network controller (primary or secondary) and will always need a Z-Wave network controller to
be included into a Z-Wave network. The device can be used in different modes that are selected by configuration parameters:
1. Control of groups of other Z-Wave devices using "ON", "OFF" and Dim commands.
2. Activation of predefined scenes in Gateways or other Z-Wave devices.
The wall controller must be completed by a mounting frame, the wall switch frame and a rocker. They are not scope of delivery of this device.
This device support secure communication when included by a controller that also supports secure communication. The device will then send all commands as
secure commands unless the receiving device can not accept them. Then the command is send the normal way automatically.
The device will be completed with different designs of wall frame and rockers.
For example:
• Berker (S.1, B.1, B.3, B.7 Glass),
• GIRA (System 55, Standard 55, E2, E22, Event, Esprit),
• Merten (1-M, Atelier-M, M-Smart, M-Arc, M-Star, M-Plan),
• Schneider Electric Exxact,
• Jung (A 500, AS 500, A plus, A creation)
• Kopp HK07

Prepare for Installation / Reset

Please read the user manual before installing the product.
In order to include (add) a Z-Wave device to a network it must be in factory default state. Please make sure to reset the device into factory default. You can do
this by performing an Exclusion operation as described below in the manual. Every Z-Wave controller is able to perform this operation however it is recommended
to use the primary controller of the previous network to make sure the very device is excluded properly from this network.
Reset to factory default
This device also allows to be reset without any involvement of a Z-Wave controller. This procedure should only be used when the primary controller is inoperable.
The device can be set back to factory defaults without performing an exclusion process. Please executes the following steps: (1) Turn the device into Management
Mode, (2) click on Button 3, (3) keep button 4 pushed for 4 seconds.
