Popp POPE009204 Manual

Popp 4 Button Key Chain Controller
SKU: POPE009204
Quickstart
This is a secure Simple Remote Control for Europe. To run this device please insert fresh 1 * CR2032 batteries. Please make sure the internal battery is
fully charged.
This wireless Z–Wave wall controller can act in two different modes that are activated with the first configuration action after factory default:
1. Pushing Button 1 for one sec. (red/green blink) adds the wireless wall controller to an existing network as secondary controller. The four
buttons will send activate 4 different scenes (Central Scene Command) in the central controller The wall controller is able to control up to 4 different
scenes with its four buttons. (with different configuration even more)
2. Pushing Button 3 for one sec. (green blink) adds a new Z-Wave actuator device to the controller who becomes the primary controller of this
new network. The connected new device (actuator) can be controlled using the two buttons left (Button 1 = up/on/open, Button 3 = down/off/closed).
After the first action you can further manage and configure the wall controller using the management mode. To activate this management mode push all
four buttons for one second simultaneously (green blinks slowly). The buttons will have different functions then (see Installation Guidelines).
Attention:For convenience reasons some special short cut apply IF and only IF the KFOB is the primary controller of the network: The first device
included into a button group will define the commands sent out by this group regardless of the default value of the configuration parameters 11-14. If
the device is a door lock the button group will turn into door lock control (value=7). For dimmers and motor controls the value changes into Multilevel Switch
Control (value=1). All other devices will turn the button group into Basic control (value=2). All configuration values can be changed if needed. When KFOB
is primary controller the very first device included will be automatically put into button group A and the command set will change according to the rules
just mentioned. All other devices need ot be put in button groups manually.
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart section.
(For more information about frequency regulations please refer to
Z-Wave ensures a reliable communication by reconfirming every message (two-way communication) and
every mains powered node can act as a repeater for other nodes (meshed network) in case the receiver is
not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency range.
If a device supports secure communication it will communicate with other devices secure as long as this
device provides the same or a higher level of security. Otherwise it will automatically turn into a lower level
of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The Secure Key Fob Controller is a 4 button Z-Wave device capable to act both as primary or secondary controller. The four buttons can control other Z-Wave
devices such as switches, dimmer and even door locks directly. Various options - configurable by Z-Wave configuration commands - define the actions and
the commands used for this control. It is possible to use two sets of buttons (one of on/open/up and one for off/closed/down) or 4 single buttons to control 4
different groups of devices.
the frequency coverage overview at Sigma Designs Website ).
