Summary of Contents for Asco 565
- Page 1 Surge Protective Devices Installation & Operation Manual Model 575 Model 565...
- Page 2 Installation, Operation and Maintenance Manual IO-70074 Rev- 04-19...
-
Page 3: Table Of Contents
System Grounding and Bonding Neutral Connection Parallel Connection / Wire Diagram INSTALLATION INSTRUCTIONS Product Installation Suggested Circuit Breaker and Wire Size – Model 575/565 Dimensional Information – Model 575/565 MONITORING FEATURES Visable Status Indicators (Standard) Summary Alarm Contact (Standard) TROUBLESHOOTING / SERVICING / MAINTENANCE... -
Page 4: Unpacking And Installation
If any damage as a result of shipping is observed, immediately file a claim with the shipping agency and forward a copy to your local ASCO Surge Protection Sales Representative. Storage The unit should be stored in a clean, dry environment. Storage temperature range is -55ºC (-67ºF) to +85ºC (+185ºF). -
Page 5: Warnings Defined
Les signes ATTENTION sans symbole d’alerte de sécurité peuvent être utilisés pour mettre en garde contre des pratiques dangereuses qui peuvent entraîner des dommages matériels seulement. 575 & 565 MODEL NUMBERS ASCO Catalog UL Legacy Part... -
Page 6: Electrical Connections
ELECTRICAL CONNECTIONS All wiring must comply with the National Electrical Code (NEC ) and applicable local codes. ® DANGER! ONLY QUALIFIED PERSONNEL SHOULD INSTALL OR SERVICE THIS SYSTEM. ELECTRICAL SAFETY PRE-CAUTIONS MUST BE FOLLOWED WHEN INSTALLING OR SERVICING THIS EQUIPMENT. TO PREVENT RISK OF ELECTRICAL SHOCK, TURN OFF AND LOCK OUT ALL POWER SOURCES TO THE UNIT BEFORE MAKING ELECTRICAL CONNECTIONS OR SERVICING. -
Page 7: Voltage Protection Rating
Voltage Protection Ratings To obtain the voltage protection ratings (VPRs), as obtained by Underwriters Laboratory, Incorporated, in accordance with the Standard for Safety, Surge Protective Devices (SPDs), Standard 1449, Fourth Edition, marked on this product, the wire size listed for each product must be utilized to connect the unit to your facilities’... -
Page 8: Neutral Connection
These instructions do not replace national or local electrical codes. Check applicable electrical codes to ensure compliance. Installation of the SPD system should only be performed by qualified personnel. Model 575/565 is a type 2 device that requires over current protection. -
Page 9: Monitoring Features
ASCO Surge Protection at 1-800-237-4567 or 1-727-535-6339. Periodically monitor the status of the LEDs. Reduced protection exists if the GREEN LED’s are extinguished or the RED LED is illuminated. Please contact ASCO Surge Protection at 1-800-237- 4567 or 1-727-535-6339. -
Page 10: Suggested Circuit Breaker And Wire Size - Model 575/565
Model 575 / Model 565 - Motorola R56 Approved Models Suggested Circuit Breaker And Wire Size – 575/565 Series Allowable Range Factory Suggested Size Surge Rating Per Mode Circuit Breaker Size Connection Wire Size Circuit Breaker Size Connection Wire Size... -
Page 11: Troubleshooting/Servicing Maintenance
Nature of problem – (including condition of all status indicators and alarms). Servicing The ASCO Models 575/565 include a ten year parts warranty. For servicing assistance, contact your local Sales Representative or ASCO, Surge Protection at 1-800-237-4567 or 1-727-535-6339. DANGER! ONLY QUALIFIED PERSONNEL SHOULD INSTALL OR SERVICE THIS SYSTEM. - Page 12 14550 58th Street North While every precaution has been taken to ensure accuracy and completeness in this literature, ASCO Power Technologies Clearwater, Florida 33760 assumes no responsibility, and disclaims all liability for damages P (800) 237-4567 resulting from use of this information or for any errors or omissions.
