FCC Part 15 C Notice
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
• Consult the dealer or experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired
operation.
WARNING!
Requires Speed Class 6 or higher microSD or
CHOKING HAZARD - Small parts.
microSDHC card (not included)
Not suitable for children under 3 years.
microSDHC Logo is a trademark of SD-3C, LLC.
Conforms to safety requirements of FCC.
This product is manufactured by AMAX Industrial Group Shenzhen.
Propel™ and Propel RC™ are licensed trademarks of Rooftop Group LTD Singapore.
AMAX USA Address: 12645 Memorial Dr Suite F1 #388 Houston, TX 77024
All Rights Reserved. Visit us at www.propelrc.com
MAXIMUM™ brand was designed exclusively for Walmart by Eastern Design Group.
For more information visit www.easterndesigngroup.com 2017 All Rights Reserved.
14
2.4GHz Quadrocopter with HD Camera
WARNING: Never leave product charging unattended for extended periods of
time. Always disconnect X04 from charger immediately after the X04 is fully
Made in China
V 3.0
X04
INSTRUCTION BOOKLET
charged. Please refer to enclosed safety instructions.
PACKAGE CONTAINS:
X04
2.4G Wireless Controller
Colors and styles may vary slightly.
ARTWORK NO.
DESCRIPTION
X04 En IM
112×172 mm
ON BOARD
ON BOARD
CAMERA
VIDEO
1280 x 720 pixel
30 frames per second
Spare Parts
Instruction Booklet
PROPEL
MDSER
DESIGNER
DATE
Jerry
2019/3/22
