Service Manual: ENGINE MECHANICAL - 4.8L, 5.3L, AND 6.0L - 2 OF 4
ON-VEHICLE REPAIR INSTRUCTIONS > OIL PUMP, SCREEN AND
CRANKSHAFT OIL DEFLECTOR REPLACEMENT > REMOVAL PROCEDURE
Fig 1: View Of Oil Pump Screen & O-Ring Seal
Courtesy of GENERAL MOTORS CORP.
1. Remove the oil pan. Refer to Oil Pan Replacement .
2. Remove the engine front cover. Refer to Engine Front Cover Replacement .
3. Remove the oil pump screen bolt and nuts.
4. Remove the oil pump screen with O-ring seal.
5. Remove the O-ring seal from the pump screen.
6. Discard the O-ring seal.
