Chapter II. FCoE Storport Miniport

iv. On the FC Ports, if a FC target is connected then perform the following steps -

Switch(config)#vsan database

Switch(config-vsan-db)#vsan 2

Switch(config-vsan-db)# vsan 2 interface fc 2/2

Switch(config-vsan-db)#exit

Switch(config)interface fc 2/2

Switch(config-if)# switchport mode auto

Switch(config-if)# switchport speed auto

Switch(config-if)# no shutdown.

v. If you have not created a zone then make sure the default-zone permits the VSAN created,

otherwise the initiator and the target on that particular VSAN although FLOGI'd into the

switch will not talk to each other. To enable it, execute the below command.

Switch(config)# zone default-zone permit vsan 2

2.2.

FCoE fabric discovery verification

Verifying Target Discovery

To check the summary of targets being discovered from FCoE ports, open device manger and

follow the steps given below:

Go to Start->Control Panel->Device Manager or launch device manager directly from

Start->Run->devmgmt.msc and hit [Enter].

ii. Go to Disk drives section under which you will find the list of all the LUNS that were

discovered.

Chelsio Unified Wire for Windows

Figure 11 - Discovered Target LUNs
