AWP 2, AWP 3

Overview

To reduce the risk of serious injury or death
to yourself or others, read the Safety
instructions section found on the previous
pages of this manual before operating the
machine.

Design and function

The APT Atlas Copco hydraulic submersible pumps WAP
2 and WAP 3 are designed to meet the demand for
efficient pumping. They offer a high performance in
relation to weight, are spark-proof, and withstand
running dry.
The WAP 2 water pump is delivered with a 10 m (32
ft) 50,8 mm (2 in.) discharge hose and the WAP 3
trash pump with a 10 m (32 ft) (3 in.) discharge
hose. Both hoses are fitted with snap-lock
quick-release couplings for easy connection.
The WAP 2 water pump and the WAP 3 trash pump
can be connected to an Atlas Copco power pack or
any other hydraulic power source with the required
specifications, see "Technical data".
The APT Atlas Copco hydraulic submersible pumps can
be used for several different jobs, such as emergency
pumping, pumping in tunnels and emptying of
excavations and cellars. The WAP 2 water pump can
handle solids up to 10 mm (
trash pump can handle solids up to 60 mm (2
in.). No other use is permitted.

Main parts

(doc no.)
WAP 2
in.), and the WAP 3
3
8
1
2
SAFETY & OPERATING INSTRUCTIONS
Safety and operating instructions
Pump housing
A.
Bearing housing
B.
C.
Hydraulic motor
Filter
D.
Discharge coupling
E.
Discharge hose
F.
Quick release couplings
G.
WAP 3
Pump housing
A.
Bearing housing
B.
Hydraulic motor
C.
Handle
D.
E.
Discharge coupling
F.
Discharge hose
Quick release couplings
G.

Labels

The machine is fitted with labels containing
important information about personal safety and
machine maintenance. The labels must be in such
condition that they are easy to read. New labels can
be ordered from the spare parts list.
9
