- Page 1 HIQ Home User Manual v1.3.1...
- Page 2 Sales and management Robotina d.o.o. OIC-Hrpelje 38 6240 Kozina Slovenia +386 5 689 2020 info@robotina.com www.robotina.com Manufacturing and service Cybrotech Ltd. 14 Brinell Way Harfreys Industrial Estate Norfolk, NR31 0LU United Kingdom +44 741 845 4980 info@cybrotech.com www.cybrotech.com...
-
Page 3: Table Of Contents
Content Features Outline Features Utility Concept Devices Expansion Background Lights and blinds RGB dimmer Scene Automatic lights Ready light Evo light Heating and cooling Timetable Key concepts Automation Alarm Access control Energy Customization Software HIQ Configurator HIQ Commander HIQ Universe Hardware PS-IQ power supply HC-IQ home controller... -
Page 4: Outline
Outline home automation system comfort simplicity security safety flexibility HIQ is a home automation system, including lights, blinds, heating and cooling; temperature monitoring, energy management, timetable, evant-based automation and security alarm. HIQ can be used for both a new project and HIQ consists both of hardware and software. -
Page 5: Features
Features unique concept and style separate thermostat for each room smartphone controls everything manual or automatic operation integration with other systems independent of internet connection unlimited expansion possibilities full user control over all parameters extremely simple to use Multiple timetables Advanced RGB control RGB mode allows control of hue, saturation and brightness;... -
Page 6: Utility
Utility various lodging solutions small house large house apartment building urban house farm house bungalow full renovation new house HIQ system is suitable for h ouse or apartment, s mall or large, residence or weekend house. However, it is not the best choice for a partial retrofit, where a wireless solution may be prefered. -
Page 7: Concept
Concept system architecture HIQ Universe HIQ devices scenes and distribution board thermostats configuration and control buttons controlled devices heating, ventilation and air-conditioning Features... -
Page 8: Devices
Devices what are devices used for Device Used for LC-10-IQ halogen and LED downlighters, light controller all kinds of general-purpose lights managed socket for floor lamp, table fan, hi-fi system, projector, and all kinds of appliances LD-P4-IQ dimmable lights of all kinds LD-D8-IQ universal dimmer LD-V4-IQ... -
Page 9: Expansion
Expansion out-of-the-box vs project-based features Basic configuration tablet 230VAC smartphone switches laptop Wi-Fi Ethernet Ethernet router IEX bus switchboard desktop PC One home controller covers approximately 200m2, or one level in a multistory building. Advanced system access energy security safety surveillance control management... -
Page 10: Background
Background experience behind the product Design Features - hardware watch-dog Cybrotech originate from industry control and automation, all devices are designed - transient supression and build up to a much higher standards - short circuit tolerant outputs then usually expected in home automation. - reverse polarity tolerant supply - wide temperature range Firmware... -
Page 11: Lights And Blinds
Lights and blinds control anything from anywhere Outputs on/off dimmer blinds position 0..100% 0..100% Scene control a group with a single command Light type Blinds type incandescent/halogen classic blinds managed socket for a compact fluorescent slatted blinds floor lamp, table fan, dehumidifier, electric mosquito repellent, hi-fi system... -
Page 12: Rgb Dimmer
RGB dimmer hue, saturation and brightness In RGB mode, dimmer channels are connected to red, RGB dimmer may be used in white temperature green, blue and white lights. White channel is mode. Here, user controls brightness and white optional. Instead of individual channels, user controls temperature. -
Page 13: Scene
Scene one key to rule them all Scene is an user-defined memory to control lights, dimmers and blinds. Each output can be on, off or not affected by the scene. inputs timetable automation scene matrix Scene mapping outputs on/off dimmer blinds On/off action Dimmer action... - Page 14 How to set a new scene 1. Identify lights that will be controlled by the scene Using HIQ Configurator Using HIQ Commander out 0 out 2 Front left reflector Open Lights+blinds page, Press and hold until pop-up out 3 check the output number dialog appears, Information 2.
-
Page 15: Automatic Lights
Automatic lights where and how to use automatic lights HIQ system offers several ways to automate lights. The appropriate configuration is selected based on the way how the space is intended to be used. smart light ready light Smart light is based on presence and low light signal. It is motion sensor used for living room and it can be combined with evo light. - Page 16 Input mode and output mode settings usage input mode output mode function press on, press off manual control on/off press on, press off on/off + timer when timer expires, light goes off press on staircase press again to reload the timer when timer expires, light goes off press on, release off doorbell...
-
Page 17: Ready Light
Ready light advanced automatic light control Ready light is an advanced lighting system, based on motion and door sensors. It is best suited for closed Features: spaces that residents don’t occupy - instant on as soon as door begins to open permanently. -
Page 18: Evo Light
Evo light automatic transition to warm evening lights Evo light is a half-automatic system for controlling light temperature. It uses RGB dimmer in white temperature mode. Brightness is controlled by user, hue and saturation are controlled by the system. During the selected period, lights are going from a cool white to warm white, perfectly matching our natural daily cycle. -
Page 19: Heating And Cooling
Heating and cooling general features of heating/cooling system Heating/cooling Energy demand Up to five regulation zones are supported, each with their own thermostat. Generally, energy comes from boiler for heating and chiller for cooling, but other combinations are possible. configurable delay allow termostat to start boiler Thermostat TH-1M-IQ... -
Page 20: Timetable
Timetable weekly event scheduler timetable 0 timetable 1 timetable 2 timetable 3 Selected part is a period when heating system is active. Each rectangle represents a half hour. Tables are fully independent of each other. To set multiple fields, hold left button and drag mouse. Each timetable can directly control one output or apply a scene. -
Page 21: Key Concepts
Key concepts low light and presence signals auto manual presence indicator smartphone Alarm button presence Presence signal is generated from all available sources, and indicate that somebody is at home. fingerprint reader Lights&blinds Automation external alarm HVAC location date and time Ready light low light Low light signal is generated as... -
Page 22: Automation
Automation execute tasks automatically Coming home Default setpoint Let your house show how When active, any setpoint happy it is when you come adjustment is valid for about back home. When phone half hour, then it returns to the connects to your wi-fi network, temperature defined in lights and heating will turn on automation setup. - Page 23 Coming home Leaving home presence presence lights lights heating heating coming home leaving home Use presence signal to set the scene and turn the heating on. Use presence signal to turn the lights and heating off. Smart lights sunrise sunset low light Automatic lights with an optional slope control, synchronized with...
-
Page 24: Alarm
Alarm security at no additional cost alarm inactive ARMING alarm turned on and will be armed when time expires (default 30s) ARMED alarm ready, no intrusion ACTIVE ARMING EXPIRED ACTIVATING sensor activated, alarm has to be turned off before delay time expires (default 30s) ACTIVE burglary, siren output active... -
Page 25: Access Control
Access control unlock front door automatically output setup: timer 10s numeric keylock coming home pulse front door electric strike input setup: input only presence presence setup: external on location: front door rfid reader auto arming fingerprint reader alarm input setup: direct presence setup: none location: front door inner side open door manually... -
Page 26: Energy
Energy electricity measurement Required hardware SDM-120C power meter Energy monitoring is the first step to CAD-232-A2 converter efficient energy usage. Once knowing how much energy something is using, one can make a rational strategy for saving. Energy consumption in last 30 days [kWh] Bargraph for last 30 days is a quick way to check for an excess consumption. -
Page 27: Customization
Customization get the maximum out of your system integrated development environment Customization is for the one who wants to get the The goal of customization is to add functionality maximum out of the system. It requires a basic related to some specific needs. HIQ system is programming skills. -
Page 28: Software
www.cybrotech.com HIQ Configurator system setup and configuration Install automatic hardware detect Windows PC Package content HIQ Configurator HIQ Timeplot HIQ View HIQ Simulator - control center - temperature timeplot - floorplan control test HIQ features - system configuration - consumption timeplot - configurable by user without the actual - diagnostics and repair... -
Page 29: Hiq Commander
Google Play HIQ Commander application for your smartphone App Store Autodetect all devices Autodetect must run in local network. If internet is available, configuration automatically registers on HIQ Home server, enabling remote access. Light 0 Light 1 Light 2 Rename Features... -
Page 30: Hiq Universe
my.hiq-home.com HIQ Universe cloud access and management Local and internet connection LAN / WAN switching is server fully automatic. Number of phones is not limited. home internet Remote access and management enable internet create account HIQ account consists of two parts, remote access and user account. -
Page 31: Ps-Iq Power Supply
PS-IQ power supply power source for the whole system power supply for sensors power supply and communication 230VAC 24VDC Secondary power supply manual switching automatic switching normally closed secondary secondary power supply power supply +24V +24V 230VAC 230VAC relay primary primary power supply power supply... -
Page 32: Hc-Iq Home Controller
HC-IQ master controller home automation central hub QX0 - radiator 0 QX1 - radiator 1 QX2 - radiator 2 QX3 - radiator 3 Mounting: 35mm DIN rail 6M QX4 - radiator 4 QX6 - boiler QX7 - chiller installation relay 16A/230V boiler chiller radiator 0 radiator 1 radiator 2 radiator 3 radiator 4... -
Page 33: Lc-10-Iq Light Controller
LC-10-IQ light controller 10 relay outputs LC-10-IQ mk1 +24V Mounting: 35mm DIN rail 6M 230Vac LC-10-IQ mk2 Features +24V IX7 IX8 nominal output current power outage: <10min - lights come back >10min - lights will stay off 230Vac managed socket for devices such as dehumidifier, hi-fi system, floor lamp, portable fan, electric mosquito repellent... -
Page 34: Ld-P4-Iq Universal Dimmer
LD-P4-IQ universal dimmer 4-channel dimmer with a separate power driver 1..10V 1..10V or 0..10k or 0..10k Mounting: 35mm DIN rail 2M + 4x1M IX0 C IX1 LUD12 LUD12 LUD12 LUD12 +24V QX0 QX1QX2 QX3 230VAC Features Operation RGB mode white temperature mode hue, saturation, brightness adjust hue in range from instead of individual RGB... -
Page 35: Ld-V4-Iq Led Dimmer
LD-V4-IQ LED dimmer 4-channel constant voltage dimmer for LED stripes independent channels mode Mounting: junction box or drywall +12/24V +12/24V power power supply supply +24V +24V CANH CANH CANL CANL 1-10V 1-10V or 10k or 10k Features Operation RGB mode white temperature mode hue, saturation, brightness adjust hue in range from... -
Page 36: Ld-D8-Iq Dali Dimmer
LD-D8-IQ DALI dimmer 8-channel dimmer for DALI ballasts DALI ballast Features DALI ballast control 8 independent groups Mounting: DIN rail 2M DALI+ DALI- drive up to 64 individual ballasts C0 IX1 internal DALI current source, 200mA no additional power needed Operation short press: on/off long press: 0..100%... -
Page 37: Bc-5-Iq Blinds Controller
BC-5-IQ blinds controller 5-channel blinds position controller Mounting: 35mm DIN rail 6M +24V IX0U IX0D IX1U IX1D IX2U IX2D IX3U IX3D IX4U IX4D QX0U QX0D QX1U QX1D QX2U QX2D QX3U QX3D QX4U QX4D 230VAC Features up and down buton short press: move up/down automatic correction at boundary position short press while moving: stop at the position... -
Page 38: Sc-4-Iq Scene Controller
SC-4-IQ scene controller 4-button universal scene controller SC-4T-IQ SC-4S-IQ - 4 configurable touch buttons - 4 button inputs and 4 LED indicators - connect to any classic button system - IR receiver + haptic feedback - extra-small size fits into any mounting +24V CANH CANL... -
Page 39: Th-1-Iq Thermostat
TH-1-IQ thermostat simple electronic thermostat Mounting: rectangular box 3M CANL CANH +24V temperature window sensor switch Fan options Features fan speed 0 or 1 on/off fan speed 0, 1 or 2 fan speed 0, 1, 2 or 3 setpoint maximum output for a limited time fan control Display when on fan max... -
Page 40: Th-2-Iq Thermostat
TH-2-IQ thermostat blind electronic thermostat Mounting: on wall CANL CANH +24V LED indicator temperature sensor device selected (white) setpoint increased (red blink) setpoint decreased (blue blink) Features on/off setpoint fan control fan max maximum output for a limited time precise temperature measurement manual measurement correction secondary setpoint when thermostat is off humidity meter... -
Page 41: Th-3-Iq Thermostat
TH-3-IQ thermostat thermostat with display and configurable buttons Mounting: round 60mm junction box +24V CANH CANL window temperature switch sensor Features on/off Configuration setpoint fan control fan max maximum output for a limited time parameter value press and hold secondary setpoint when thermostat is off - on/off - setpoint - fan speed... -
Page 42: Fc-1-Iq Fan-Coil Actuator
FC-1-IQ fan-coil actuator 3-speed fan coil actuator 230VAC Mounting: inside fan-coil SPEED temperature CANL sensor CANH +24V fan coil - 2-pipe system - electromechanical valve - 3-speed fan - both heating and cooling Features simple no adjustments, no jumpers or DIP switches, configuration is completely performed on PC flexible can be used with a wide range of... -
Page 43: Power Meter
Power meter SDM120C voltage, power and energy Mounting: 35mm DIN rail 1M + 2M 9 10 SDM120C CAD-232-A2 SDM120C 230VAC 230VAC utility grid switch panel CAD-232-A2 RS232/485 converter CAD-232-P0 cable SDM-120C is supplied with the power meter converter Technical specifications Nominal voltage: 230VAC, 110VAC Voltage range:... -
Page 44: Motion, Door And Light Sensor
Motion, door and light sensor sensors for automation and alarm Motion sensor +24V Motion sensor is mounted above or lateral to room entrance. People entering the room must intersect sensor beams. At the moment when IR-580-IQ LC-10-IQ closing the door, person should be in the area of maximum sensitivity. -
Page 45: Temperature Sensor
Temperature sensor indoor and outdoor measurement ES-P ES-B ES-W Technical specifications ES-P Housing: heatshrink tube Operating range: -50 to +100°C Degree of protection: IP50 Cable length: ES-B Housing: steel tube Operating range: -50 to +100°C Degree of protection: IP67 Cable length: ES-W Housing: plastic box, white... -
Page 46: Touchless Switch
Touchless switch no-contact wall mounting switch +24V Mounting: standard 68mm junction box LC-10-IQ AS-24RA Operation Features reliable way to detect a hand through most materials countless decorative switchplates switchplates attach via magnets and are easily exchanged range adjusted with potentiometer low power consumption excellent noise immunity 10cm... -
Page 47: Wiring
Wiring Bus wiring Switchboard and field modules 1. Take one ingoing and one outgoing wire together, and remove insulation for about 10-12mm. 10-12mm 2. Crimp wires together into a ferrule. switchboard field modules 100m max. 3. Wrap wires together for a few centimeters. Power supply must be connected to the first (leftmost) device. -
Page 48: Schematic Diagram
Schematic diagram 63A/0.3A 25A/0.03A living kitchen dish kitchen kitchen work guest washing clothes garden bedroom room condition fridge washer stove oven room room machine dryer PS-IQ LC0 mk2 LC1 mk2 LC2 mk2 L0..L9 L10..L19 L20..L29 B0..B4 B5..B9 24VDC lights living room, lights kitchen, lights hall and blinds living room... -
Page 49: Switch Panel
Switch panel ground neutral FA1 neutral FA2 limitator surge protector PS-IQ HC-IQ digital ground This diagram represents a typical switchboard layout. Four DIN rails are used, top row for fuses, next two rows for HIQ modules, and the last row for interconnecting terminals. -
Page 50: Dimensions
Dimensions 45.5 32.5 24.5 15.7 Hardware... -
Page 51: Order Code
Order code devices and sensors LD-P4-IQ LD-V4-IQ 4-channel LC-10-IQ 4-channel universal dimmer light controller LED strip with 10 outputs LUD-12 dimmer power driver BC-5-IQ LD-D8-IQ 5-channel 8-channel blinds controller DALI dimmer SC-4S-IQ SC-4T-IQ scene controller for touch screen standard buttons scene controller TH-1T-IQ TH-3-IQ... - Page 52 Order code cables and accessories ES-P ES-W RE-2 temperature sensor temperature sensor IR remote ES-B temperature sensor CAD-2-BUT 2x mini-button CAD-P0 bus cable 2.5cm, RJ9/RJ9 connecting devices in switchboard CAD-P2 bus cable 2m, RJ9/RJ9 connecting rows in switch panel CAD-232-P0 15cm crossed, RJ9/RJ9 cable for power meter SM11-PW-NT...
