Inserting the battery
1. Insert the battery with the contact side first into the battery compartment and slide
the battery to the end (Picture 8.3)
2. Push down the other side of the battery (Picture 9.1
battery latches (Picture 9.1
3. Put the battery cover back into place (side with latches first) (Picture 9.2)
4. Push the battery cover down and tighten the six battery cover screws (Picture 8.1)
Image 9.1
1
2
)
2
Image 9.2
2
) and close the two
1
