- Page 1 INFINITY KAPPA 6, KAPPA 8, AND KAPPA 10 MARINE SPEAKER In nity Kappa 6, Kappa 8, and Kappa 10 marine speaker - Owner’s Manual Haut-parleur marine In nity Kappa 6, Kappa 8 et Kappa 10 - Mode D’emploi Altavoz para entornos marinoss In nity Kappa 6, Kappa 8 y Kappa 10 - Manual de Propietario...
-
Page 2: About The Manual
INFINITY KAPPA 6, KAPPA 8, AND KAPPA 10 MARINE SPEAKER THANK YOU FOR YOUR PURCHASE . . . Your Infinity product has been designed to provide you with the performance and ease of operation you would expect from Infinity. ABOUT THE MANUAL This manual describes general installation guidelines. - Page 3 Kappa 10 11-5/8” (295mm) 9-9/16” (235.6mm) SPEAKER SIGNAL WIRING To send signal to the Infinity marine speaker, connect the positive (+) and negative (-) speaker wires to the appropriate speaker outputs of your source unit or amplifier. Be sure to observe proper polarity. SPEAKER LED WIRING To provide power for the LEDs, plug the 24-gauge black (+), blue, green, and red LED wires from the speaker into the included female connector, then run the wires from the female connector to your compatible 12-volt power source or light...
-
Page 4: Mounting The Speaker
Wire connected to positive Wire connected to Color produced (+12V) terminal negative (-) terminal Green Green Blue Blue Red + Green Yellow Black Red + Blue Purple Blue + Green Aquamarine Red + Blue + Green White APPLYING FOAM SEAL To help seal your installation against water, and to provide an airtight acoustic seal, apply the self-adhesive foam seal to the speaker frame. - Page 5 REMOVING THE TWEETER FOR SEPARATE MOUNTING (KAPPA 8 ONLY) Use the included 2-pin tool to remove the tweeter from the woofer housing. Place the pins of the tool in the holes of the tweeter grille and rotate 45 degrees clockwise to loosen and remove. 45°...
- Page 6 *NOTE: Because of the woofer’s low impedance, do not wire two or more in parallel to an amplifier; doing so can result in overheating and damage to the amplifier. HARMAN International Industries, © 2018 HARMAN International Industries, Incorporated. All rights reserved. Incorporated 8500 Balboa Boulevard, Infinity is a trademark of HARMAN International Industries, Incorporated, Northridge, CA 91329 USA registered in the United States and/or other countries.
