LPC STANDARD DISPLAY
170 Cherry Ave.
West Sayville, NY 11796
www.kussmaul.com
INSTRUCTION MANUAL
AUTO CHARGE
LPC SERIES
MODEL #091-206-12-240
INPUT: 240 volt, 50/60 Hz, 6.5 amps
OUTPUT: 80 AMPERES
3 YEAR WARRANTY
FILE: IM_091-206-12-240_revA
REV: A
REVISED BY: THN/PSS
DATE: 06-9-2014
Phone: 631-567-0314
Fax: 631-567-5826
sales@kussmaul.com
Advertisement
Table of Contents
Related Manuals for KUSSMAUL AUTO CHARGE LPC Series
Summary of Contents for KUSSMAUL AUTO CHARGE LPC Series
- Page 1 REVISED BY: THN/PSS DATE: 06-9-2014 INSTRUCTION MANUAL AUTO CHARGE LPC SERIES MODEL #091-206-12-240 LPC STANDARD DISPLAY INPUT: 240 volt, 50/60 Hz, 6.5 amps OUTPUT: 80 AMPERES 3 YEAR WARRANTY Phone: 631-567-0314 170 Cherry Ave. Fax: 631-567-5826 West Sayville, NY 11796 www.kussmaul.com sales@kussmaul.com...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS 1. SAVE THESE INSTRUCTIONS - This manual contains important safety and operating instructions for battery charger model: 091-206-12. 2. Do not expose the charger to rain or snow. 3. Wire charger inaccordance with all: National, Local and/or Underwriter requirements for NEMA. - Page 3 INTRODUCTION The AUTO CHARGE LPC SERIES is a low profile, completely automatic, single channel, battery float charger designed for vehicles with a single battery system. The LPC improves upon package size and parasitic systems. The charger is also ruggedized to withstand the shock and vibration encountered by vehicle mounted equipment.
- Page 4 The output terminal strip provides an additional output to accomodate 12 volt accessories, such as: Kussmaul's 12VDC air pump. The AUX output works in conjunction with a front panel mounted rocker switch. For normal operation, the rocker switch should be left in AC mode, which means that the aux accessory works only when shoreline power is supplied to the charger.
-
Page 5: Operation
OPERATION Battery Charger Output: 1. A discharged battery is recharged to roughly 90% or until the current tapers down to less than 2 amps. The ouput voltage never exceeds the float voltage, which is regulated from 0 to 80 amps (current-limit). 2. -
Page 6: Installation
INSTALLATION 1. The Auto Charge LPC should be installed in a well ventilated area. 2. Mount the charger with the four holes provided. WIRING 1. Refer to Installation Wiring Diagram. 2. CAUTION: CONNECT DC WIRES TO CHARGER FIRST, THEN TO BATTERIES. 2. -
Page 7: Installation Wiring Diagram
INSTALLATION WIRING DIAGRAM I. FOR BAR GRAPH DISPLAY, 091-200-IND OR DELUXE STATUS CENTER, 091-194C-IND Note: For 240 VAC, pin-4 of indicator must go to pin-5 of Remote Display on charger. CAUTION: CHARGING LEADS MUST BE DISCONNECTED FROM BATTERY PRIOR TO WORKING ON CHARGER Use 5/16 ring lug and M8 x 1.25 hardware, supplied. - Page 8 II. FOR WATERTIGHT DELUXE STATUS CENTER, 091-194C-IND-WT-XX Note: For 240 VAC, pin-4 of indicator must go to pin-5 of Remote Display on charger. CAUTION: CHARGING LEADS MUST BE Remote DISCONNECTED FROM BATTERY 5 - GREEN 22AWG Indicator 3 - WHITE 22AWG PRIOR TO WORKING ON CHARGER 2 - BLACK 22AWG 1 - RED 22AWG...
-
Page 9: Optional Accessories
OPTIONAL ACCESSORIES DELUXE STATUS CENTER MODEL #: 091-194C-IND DELUXE STATUS CENTER WATERTIGHT MODEL #: 091-194C-IND-WT Bezel available in various colors: red, yellow, white, gray, blue, and black... -
Page 10: Specifications
(2) 1/4 ring lugs (p/n: 2S6R1) (1) 5-pin plug; (1) 2-pin plug (2) M8 x 1.25 bolt, lockwasher, and nut (2) Rubber terminal insulators (1-black, 1-red) (1) 100amp Circuit Breaker (p/n: 090-0100-0) Weight: 10 pounds Outline Dimensions: AUTO CHARGE LPC SERIES... -
Page 11: Warranty
Kussmaul Electronics Company, Inc. shall have no liability for damages of any kind to associated equipment arising from the installation and /or use of the Kussmaul Electronics Company, Inc. products. The purchaser, by the acceptance of the equipment, assumes all liability for any damages which may result from its installation, use or misuse, by the purchaser, his or its employees or others.
