- Page 1 DWR-2410M Operation manual 2.4GHz Digital Receiver Module CHIAYO ELECTRONICS CO.,LTD.
- Page 2 DWR-2410M 2.4GHz Digital Receiver Module Parts and functions DWR-2410M Digital Wireless Receiver 2467 FREQ 1. LCD 7. Antenna socket (SMA type) 4. UP button 2. Synchronization button 5. SET button 3. DOWN button 6. Power switch/volume control After power on, the LCD will display channel-frequency in use, which should be the same of the transmitter.
- Page 3 Instructions CHANNEL SYNCHRONIZING of the receiver and transmitter When interference is encountered try reducing the sensitivity of the receiver, thus less susceptible to interference. To operate the squelch setting: Press and hold the receiver’s SYNC button Press and hold the transmitter’s DWR-2400M FREQ Digital Wireless Receiver...
- Page 4 CH1 to CH189. FREQ CH 189 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw ｜ Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 ｜ Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 ｜ Fax: 886-5-5767611...
