- Page 2 Limited 90-Day Triumph Sports USA, Inc. Warranty All Triumph Sports USA, Inc. (TSU) games have a limited 90-day from date of purchase warranty. This warrants the retail purchaser for any TSU game purchased to be free from any defect in materials and construction for 90 days from the date of purchase. The only exceptions to the warranty include main frames, tabletops, playing surfaces, batteries or tools.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS Read all instructions-All the safety and operating instructions should be read carefully before the hockey game is played. Caution-This is not a toy and is intended for use by or under the supervision of adults. Adults should review safety guidelines with children to avoid possible risk of electric shock or other injuries.
- Page 4 Rail Support Panel 3.5x33mm 3.5x14mm 3.5x14mm 4x40mm 4×7mm Screw 6x40mm 6x32mm 8 Pieces...
-
Page 5: Parts List
Parts List 3.5x18mm Screw 4 Pieces 4Pieces 1 Piece 2 Pieces Pre-installed 5×17mm Screw Cue Holder Bracket 4 Hole 8 Pieces 2 Pieces Assembly Tips: Attention: If you are using an electric screw driver in assembly, please set at low torque and do not over tighten the hardware. - Page 6 Assembly Instructions NOTE: We recommend that two adults work together to assemble this game. Open the carton of your new table game near where you will play. Select a clear level area. Step 1 Please inspect table tops and playing surfaces before putting the game together. Remove all the contents from inside the carton and verify that you have all listed parts as shown on the parts list.
- Page 7 Step 3 When all the parts are out of the table top (#1), replace the pool table surface(#6). Attach the pool table surface by using the screws (#14). Step 4 Insert the corner baskets (#38) and side baskets (#39) into the cabinet-hockey (#1) using screw (#20).
- Page 8 Step 5 Screw 2 lock pins (#13) into predrilled holes on leg pedestal (#7) with screws (#19).Attach the catcher box (#8) to the leg pedestal (#7) with screws (#14) into predrilled holes. Black Silver Step 6 Screw the ball below board (#9) to the leg pedestal (#7) using screws (#14) into predrilled holes.
- Page 9 Attach leg levelers (#12) to bottom of each leg. Flip the legs over, attach the legs (#2) Step 7 & (#3) to the leg pedestal (#7) by inserting screw (#17) and washer (#21) into the predrilled holes of the leg pedestal. Attach the leg panel (#11) to the legs from the inside using screw (#15).
- Page 10 Step 9 Note: Attach the table top (#1) by sliding the shaft’s already attached the end’s of the table top ,into the 2 slots on part(#7) be sure the loose washer is placed on the inside of part(#7) Loose washer placed inside of part( #7) Step 10 Attach top side panel (#5) to the assembled leg pedestal by aligning the holes in the...
- Page 11 Step 12 Clip the cue holder (#43) to the outside rail (#10). Store the cue sticks (#24) in the cue holder.
- Page 12 BILLIARDS: After the break, regardless of whether any balls were pocketed on the break, the table is Open, with the choice of stripes or solids determined by the next legally pocketed ball. In the course of play, a player must call each shot in advance, by indicating the ball to be made and the pocket into which it will be made.
- Page 13 TABLE TENNIS: In singles, the server first makes a good service and then the receiver makes a good return. Thereafter, server and receiver alternately each make a good return. In doubles, the server first makes a good service and the receiver returns the ball. Then the partner of the server makes a good return, followed by the partner of the receiver returning the ball.
