Model: 45-6840
Date Code: CPSIA#2-45-6840-_______-GR
Purchase Date: ______________________
84" Billiard Table with
Please keep this instruction manual for future reference
If you have any problems with your new product,
please contact Escalade Sports at 1-888-996-2729
or e-mail us at gameroom@escaladesports.com
Table Tennis Top
for any technical support or warranty issues.
Advertisement
Table of Contents
Related Manuals for Triumph Sports USA 45-6840
Summary of Contents for Triumph Sports USA 45-6840
- Page 1 Model: 45-6840 Date Code: CPSIA#2-45-6840-_______-GR Purchase Date: ______________________ 84” Billiard Table with Table Tennis Top Please keep this instruction manual for future reference If you have any problems with your new product, please contact Escalade Sports at 1-888-996-2729 or e-mail us at gameroom@escaladesports.com...
-
Page 2: Limited 90-Day Warranty
Limited 90-Day Warranty All Triumph Sports USA (TSU) games have a limited 90-day from date of purchase warranty. This warrants the retail purchaser for any TSU game purchased to be free from any defect in materials and construction for 90 days from the date of purchase. The only exceptions to the warranty include main frames, tabletops, playing surfaces, batteries or tools. -
Page 3: Parts List
Parts List CABINET FOR 5/16’’X1-1/4’’ LEG BOLT BILLIARD LEFT LEG RIGHT LEG END LEG BRACE SIDE LEG BRACE 1 PC 2 PCS 2 PCS 2 PCS 2 PCS 12 PCS (Packed in Playfield) 5/16″×Ø19×1.5 MM 1/4″×1″ LEG BOLT 1/4″×Ø15×1 MM 4x12MM WASHER TABEL TENNIS WASHER... - Page 4 Assembly Tips: Attention: If you are using an electric screwdriver in the assembly, please set at low torque and do not over tighten the hardware. When assembling individual parts, loosely tighten screws until all screws are inserted, then tighten completely. Assembly Instructions NOTE: We recommend that two adults work together to assemble this game.
-
Page 5: Right Leg
PART REQUIRED: 2 pcs - #2 Left Leg 2 pcs - #3 Right Leg 12 pcs - #6 Allen Head Bolt 12 pcs - #8 Flat Washer 4 pcs - #16 Leg Leveler 1 pc - #29 Allen Wrench Step 4 Attach Left (#2) and Right (#3) Legs to support frame using three of Leg Bolts (#6) and three Washers (#8) per leg.Then locate the four Leg Levelers (#16) and screw one into each Leg. -
Page 6: End Leg Brace
PART REQUIRED: 2 pcs - #4 End Leg Braces 12 pcs - #10 Screws Step 5 Attach End Leg Braces (#4) to Legs using six Screws (#10) per Leg. See FIG.3. -
Page 7: Side Leg Brace
PART REQUIRED: 2 pcs - #5 Side Leg Brace 8 pcs - #7 Allen Head Bolt 8 pcs - #9 Flat Washer 1 pc - #29 Allen Wrench Step 6 Attach Side Leg Braces (#5) to Legs using two of Leg Bolts (#7) and two of Washers (#9) er Leg. -
Page 8: Parts Required
PARTS REQUIRED: 2 pcs - #11 Table Tennis Support 1 pc - #20 Net 2 pcs - #22 Table Tennis Surface (A) 2 pcs - #21 Net Post 1 pc - #30 Table Tennis Surface (B) 4 pcs - #31 EVA Pad Step 7 Place the Table Tennis Surface Half... - Page 9 PRODUCT PARTS LIST FOR MODEL # 45-6840 Key # Part # Qty. Description Cabinet for Billiard 45-6840GR1 Left Leg 45-6840GR2 Right Leg 45-6840GR3 End Leg Brace 45-6840GR4 Side Leg Brace 45-6840GR5 5/16’’X1-1/4’’ Leg Bolt 45-6840GR6 1/4″×1″ Leg Bolt 45-6840GR7 5/16″×Ø19×1.5 MM Washer 45-6840GR8 1/4″×Ø15×1 MM Washer...
