- Page 1 Swarm-enabled Solar Battery System Installation and Operating instructions PBX-200 PB (230 V, 200 W, 1.2 kWh AGM Battery) PBX-200 Li (230 V, 200 W, 1.2 kWh Li-ion Battery) 2017-03-13...
-
Page 2: Table Of Contents
7.8.3 Installation of power systems greater than 9 Power-Blox ..............24 INITIAL START-UP ............................25 LED DISPLAY ..............................26 ......................... 26 NDICATES THE BATTERY STATUS .......................... 26 ISPLAY ON SYNCHRONIZATION ............................26 ISPLAY OF ERRORS TROUBLESHOOTING ..........................27 MAINTENANCE ............................28 DISPOSAL ..............................29 TECHNICAL DATA ............................30 DISCLAIMER OF LIABILITY ..........................32 WARRANTY AND GUARANTEE PROVISIONS ....................33 HOW TO CONTACT WITH ..........................37 NOTES ................................. 38 Installation and Operating Instructions PBX-200 PB / Li page 2... -
Page 3: General Safety Instructions
— People with physical, sensory or mental impairments, — Persons who do not have sufficient experience and knowledge. Unless they have been instructed and initially supervised by a person responsible for their safety. Installation and Operating Instructions PBX-200 PB / Li page 3... -
Page 4: Scope Of Delivery
Quick Start Guide § Installation and operating instructions (online) § Optional accessories: Solar cables with MC-4-port § WP 200 or 250 WP solar module § Print version installation and operating instructions § Installation and Operating Instructions PBX-200 PB / Li page 4... -
Page 5: Intended Use
3 Intended use The solar battery system, hereafter referred to as the power-Blox or System referred to, may be used only in photovoltaic systems. Furthermore, Only solar modules can be connected to the solar module connector. § The connected loads must be suitable for the corresponding output voltage (230 V §... -
Page 6: Markings
Caution Possible risk of minor or moderate bodily injury Attention Possible property damage Note Note on the operation of the controller or on how to use the instructions Installation and Operating Instructions PBX-200 PB / Li page 6... -
Page 7: Quick Start Guide
5 Quick Start Guide DANGER! Danger to life due to electrocution. Observe the safety instructions in section 9.1 Installation and Operating Instructions PBX-200 PB / Li page 7... -
Page 8: Overview Of The Power Blox
6 Overview of the Power Blox Figure 1: Power-Blox front page Figure 2: Front connectors and power switch Installation and Operating Instructions PBX-200 PB / Li page 8... - Page 9 Figure 3: Power-Blox back Figure 4: Terminal connections behind cover installation Installation and Operating Instructions PBX-200 PB / Li page 9...
-
Page 10: Legend Of Components And Connections
14 Installation flap for terminal connections 15 Anti-theft locking pins 16 Terminal block transfer connection 17 Not used 18 Terminal block for power / generator input 19 Solar connection terminal block 20 Strain relief bar Installation and Operating Instructions PBX-200 PB / Li page 10... -
Page 11: Installation
Isolate the open cable ends with an insulating tape or a luster clamp. Connect the cables from the solar module and the consumers to the Power-Blox in the order described. - Page 12 WARNING: Model PBX 200 with lead batteries Risk of injury from acid. The Power-Blox contains two AGM lead batteries with 12 V and 50 Ah each. Do not expose the battery to open fire or sparks. Thoroughly ventilate the installation location of the Power-Blox. Flammable gases can escape from the battery.
-
Page 13: Connections And Main Switch
The main switch is switched on by tilting to the left (position I). Tilt to the right (position O) turns off the Power-Blox. The Power-Blox starts into a boot and measuring cycle after switching on, so it does not deliver power directly to the integrated sockets (1). Wait approximately one minute for the Power-Blox to complete all tests and be ready for operation. -
Page 14: Use The Usb Connectors (4) (5) And 12 V Dc
Figure 6: The DC connectors on the front of the Power-Blox If you want to use the Power-Blox DC power units, you have the possibility to connect a 12 V device to the maximum of 3 A (car connection) and two USB devices up to 2.1 A at the front. -
Page 15: Coupling Of Power-Blox
(14). Read more in the chapter 7.7. 7.2.5 Coupling of Power-Blox By linking individual Power-Blox devices to a whole system, you can achieve several effects: § The performance of the entire system is increased § The memory of the combined system is increased §... - Page 16 The resulting tower is provided at the sockets outlet (1) the power of all Power-Blox in the tower. If you want to create larger mini-grids, go to chapter 7.8.3.
-
Page 17: Minimum Distances
The interconnection of several towers takes place analogously to the coupling process described in the previous chapter to a Power-Blox tower. In this case, the transfer cable (9) of the lowest power-blox is connected to the transfer bush (6) of the neighboring tower. -
Page 18: Using The Connection Terminals (16-19)
Thus, the system delivers the performance of the entire system at one of the top sockets of a tower. In our example, with 9 Power-Blox, this results in 9 x 200 W = 1.8 kW power, which can be tapped at the socket. Please note that some types of sockets are designed for a lower maximum power depending on the country specification. - Page 19 Prepare the cables according to the following drawing and push them as far as they will go into the corresponding opening of the terminal: Now close the terminals: When closing, ensure that the clamp is fully closed and the bracket does not protrude: Installation and Operating Instructions PBX-200 PB / Li page 19...
- Page 20 Figure 12: Securing the cable with a cable tie on the strain relief bar To feed the cable from the Power-Blox, the Power-Blox break-out tabs are provided in the installation cover. In this case, break out a tab at a suitable location, for example with a side...
-
Page 21: Connection Types
Figure 14: Single solar system with solar panel If you want to use a Power-Blox as a single independent system and connect loads directly to the integrated sockets (1), connect the solar module directly to the solar sleeve (8) and the two MC4 plugs with the solar module via the optionally available standard cable. -
Page 22: Use As Backup System (Ups)
Figure 16: Interconnection of the Power-Blox as a pure backup unit If you are using the Power-Blox as an interruption-free power supply, simply connect it to the power outlet using the supplied power cord and use the integrated sockets (1) to feed your appliances. -
Page 23: Power-Blox Installation
IMPORTANT! Terminal (19) is connected to the mains input of the Power-Blox as standard, so you will already find three installed cables on these terminals. To avoid dangerous mains voltage at the contacts of the mains socket (7), remove the three pre-installed cables before connecting the mains to terminal (18) and isolate them individually with insulating tape or luster terminals. -
Page 24: Installation Of Additional Power-Blox To A Tower Or A Power-Wall (Maximum 9 Units)
3. Power-Blox set up 4. Mount the solar module using a suitable mount at the destination 5. Lay the solar cable to the Power-Blox and connect it to the solar socket (8) or the clamping block (19) 6. If necessary, transfer the transfer connector (16) to the building distributor 7.8.2 Installation of additional Power-Blox to a tower or a Power-Wall (maximum 9 units) -
Page 25: Initial Start-Up
3. Make sure that all devices attached to the outlet are switched off 4. Turn the main switch (3) to "I" 5. Wait at least 60 seconds for the startup to complete 6. Now the system is ready for operation Installation and Operating Instructions PBX-200 PB / Li page 25... -
Page 26: Led Display
LED. When the discharge reaches 40%, the indicator changes to orange and 30% to red. Below 20% the inverter is switched off and the last red LED starts flashing. Operate the Power-Blox only in the green area of the display. In this charging area the battery is spared and has the highest life expectancy. -
Page 27: Troubleshooting
LEDs light up again o Yes, several LEDs light up à Did you wait 60 seconds after switching on the Power-Blox? The unit requires a certain amount of time until the power supply (1) is available. à Plug your power supply into the second socket and check that there is no voltage present. -
Page 28: Maintenance
(>40%) at all times. A lower charging state (orange, red) will not destroy the device, but will shorten the life of the battery. In a system with multiple Power-Blox (see chapter 7.2.5) all devices should show the same load status. If a Power-Blox deviates, this indicates a problem. -
Page 29: Disposal
12 Disposal Do not dispose of this device through domestic waste! Dispose of the device at the collection point provided in your country or send the device to the Power-Blox customer service after the end of its service life. The packaging of the device consists of recyclable material. -
Page 30: Technical Data
Recommended PV power 200 W IUoU , temperature Li BMS , temperature Charging characteristics regulated regulated Battery 2 x Hoppecke 2 x SmartBattery Included batteries sun power VR M 12 V 58 12 V 50 AH Battery technology Lead acid / AGM LiFePO4 Internal battery voltage Cycle stability 2500 cycles 5000 cycles Expected lifetime 3 - 5 Jahre > 10 Jahre DC Output Cigarette lighter socket 12 V, 3 A USB socket 2 x 5 V, 2 A Installation and Operating Instructions PBX-200 PB / Li page 30... - Page 31 LiFePo4 lithium iron phosphate If the operating temperature is above 30 ° C, the batteries age considerably faster Theoretical value, which must be tested for the new technology only in practice Installation and Operating Instructions PBX-200 PB / Li page 31...
-
Page 32: Disclaimer Of Liability
Both the observance of these instructions as well as the conditions and methods for the installation, operation, use and maintenance of the Power-Blox can not be monitored by the manufacturer. Incorrect execution of the installation can lead to damage to property and to subsequent persons. -
Page 33: Warranty And Guarantee Provisions
(purchase document). If the customer finds a problem, he must first contact his dealer / installer or the Power-Blox AG. 2. Beneficiaries of this manufacturer's guarantee Power-Blox will only issue this guarantee to the operator, who is proven to have acquired a product which is entitled to a guarantee, and who operate the product entitled to the warranty itself ("operator entitled to guarantee") The proof is deemed to have been provided if Power-Blox... - Page 34 In the event of a defect of the warranted products during the warranty period - at the option of Power-Blox - a free repair or replacement by a product which has at least the same or better specifications. The repair or replacement is carried out exclusively at the Power-Blox plant or at the authorized service centers of Power-Blox.
- Page 35 Power-Blox AG. In addition, Power-Blox AG will in no event be liable for indirect damage or loss of income. Subject to any mandatory statutory provisions, Power-Blox AG shall not be liable for damages other than those for which Power-Blox AG has expressly acknowledged its liability.
- Page 36 Claims of the guarantor of the guarantee-entitled operator from this manufacturing guarantee shall only be assignable to third parties with the prior written consent of the Power-Blox. Should a provision of this manufacturing guarantee be or become invalid, the effectiveness of the remaining provisions of the manufacturing guarantee shall remain unaffected.
-
Page 37: How To Contact With
For complaints and faults, please contact your local dealer where you bought the product. This will help you in all matters. Dealer: ................. Street, No: ................. Zip Code: .................................. Telephone: ................. Email: ................. Website: ................. Installation and Operating Instructions PBX-200 PB / Li page 37... -
Page 38: Notes
17 Notes Type: .......... Serial-No: .......... Installation and Operating Instructions PBX-200 PB / Li page 38...
