- Page 1 User Manual SERIES II...
-
Page 3: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS ..................3 INTRODUCTION TO BRT PRODUCTS ..............7 ! ......................7 ELCOME VISUAL OVERVIEW OF THE SYSTEM ..............8 ........................ 8 N CAB ................8 YPES OF SUPPORTED SENSORS ................8 PTIONAL ACCESSORIES AVAILABLE THE BRT 5 MONITOR .................. - Page 4 ......................28 ROFILES ................29 DVANCED SCALE FUNCTIONS ......................30 DVANCED ............30 AVING AND LOADING THE CONFIGURATION – ....................32 PASTE ....................33 YSTEM TESTS ....................34 OMMUNICATION .................... 35 PECIAL FUNCTIONS CALIBRATION ....................38 ................... 39 MPTY ALIBRATION ..................
- Page 5 LIST OF PARTS ....................53 ......................53 ISPLAY ..................53 OMMUNICATION RT S ....................... 53 ENSOR ....................... 53 ENSOR ....................53 IGHT OPTIONS ....................53 RINTER OPTIONS .................... 53 OAD CELL OPTIONS ..............53 TRAILER INSTALLATION OPTIONS TECHNICAL SUPPORT ..................54 ..............
-
Page 7: Introduction To Brt Products
BRT 5 yourself, no problem. First consult your user manual. It contains all of the information needed to configure, calibrate and use your BRT. If you need technical support, please visit trackweight.com or contact your authorized dealer. Thank you again and enjoy your BRT 5! BRT 5 –... -
Page 8: Visual Overview Of The System
VISUAL OVERVIEW OF THE SYSTEM In cab Types of supported sensors Optional accessories available BRT 5 – User Manual V1.2.007... -
Page 9: The Brt 5 Monitor
THE BRT 5 MONITOR Front view Pictograms Main functions Menu Calibration and settings access Alarms Activate/deactivate the alarms Print Print a data ticket Units Change unit of measurement (KB, LB) Special Functions Standby Hold 3 secs to activate/deactivate standby mode Zero Hold 3 secs to set to zero function (if function activated) -
Page 10: Back View
Back view Start-Up screen | 10 BRT 5 – User Manual V1.2.007... -
Page 11: Initial Start-Up Procedure
Initial start-up procedure 1- Selecting the type of truck (p. 13) 2- Configuring the sensors (p. 14 to 12) 3- Configuring the display (p. 15 to 22) 4- Configuring the printer settings (p. 23 to 25) 5- Configuring the alarms, external lights (p. 26 to 27) 6- Calibration (p. -
Page 12: Basic Navigation Principles
Basic navigation principles To adjust/change an option: 1- Using the arrows, select the option you want to change ↵ Press 2- Using the arrows, adjust/change the option ↵ Press Note: For certain options, it is not required to do the step 2 if they are as simple “yes/no”, “on/off”,... -
Page 13: Set Up
SET UP MENU > SET UP Truck types [Menu/Setup/Truck Type] Note: This menu only appears when the advanced functions are activated. page Using the arrows, select the type of truck used. Press ↵ to save the selection. Truck types available Displayed Axle Group Steer –... -
Page 14: Sensors
Sensors [Menu/Setup/Sensors] Note: This menu only appears when the advanced functions are activated. page Configure the type of sensors installed, as well as their position on your truck and / or trailer. ↵ First, select a sensor using the arrows, press to activate the change. -
Page 15: Date/Time
Date/Time [Menu/Setup/Date/Time] Note: The date and time are displayed only if the "Show Time" option has been activated. See page Adjust the date and time, as well as the type of display (16 choices available). | 15 BRT 5 – User Manual V1.2.007... -
Page 16: Language
Language [Menu/Setup/Display/Language] Select the language you want to use. The choices are: English French | 16 BRT 5 – User Manual V1.2.007... -
Page 17: Inverting Lcd
Inverting LCD [Menu/Setup/Display/Inverting LCD] Selecting the inverted colour display mode. | 17 BRT 5 – User Manual V1.2.007... -
Page 18: Large Numbers
Large numbers [Menu/Setup/Display/Large numbers] When selecting the display mode with large numbers, there are two size options for the axle group numbers: large and small. | 18 BRT 5 – User Manual V1.2.007... -
Page 19: Resolution
Resolution [Menu/Setup/Display/Resolution] Select the value that the weights given on the main display will be rounded to. The resolution options are: - 10 - 50 - 100 Note: Rounding is performed in the unit used (kilograms, pounds). Note: The scale’s accuracy is not affected by this configuration. | 19 BRT 5 –... -
Page 20: Show Time
Show time [Menu/Configuration/Display/Show time] Enable the display of the date and time on the main screen. | 20 BRT 5 – User Manual V1.2.007... -
Page 21: Auto-Brightness
Auto-brightness [Menu/Setup/Display/Auto-Brightness] Select the display brightness desired. Note: Auto-brightness mode is used by default and adjust automatically the display brightness according to the ambient light. Disable this mode to choose the degree of brightness permanently. | 21 BRT 5 – User Manual V1.2.007... -
Page 22: Selection Of Axle Groups In The Main Display
Selection of axle groups in the main display [Menu/Setup/Display/Left|Right] In the big numbers display mode, you can select the axle groups displayed on the main screen. Note: The choice of axle groups available depends on the type of truck “Truck types”, p. selected. -
Page 23: Print Settings
Print Settings [Menu/Setup/Printer] Nbr of copies: The number of tickets to be printed. Next Ticket: Modifies the sequential number of the ticket Profile name: Determines whether the name of the active configuration (profile) will be printed. Ticket number: Determines whether the sequential ticket number will be printed. -
Page 24: Printer (Optional)
Printer (optional) [Menu/Setup/Printer] Half Ticket Standard Ticket Printing a standard ticket: Using the arrows, select the "Print" pictogram; Press button 1 once ("Print"); Perform the desired operation (loading, unloading); Press button 1 ("Finish") again. Printing an abridged ticket (half-ticket option must be activated): Using the arrows, select the "Print"... -
Page 25: Printer Header
Printer header [Menu/Setup/Printer/Printer Header] View/edit the header of printed tickets. Select “Edit” to make changes. ↵ Press to edit a line and select the item to be changed. Press the arrows to change the selected item. Select “Add line” or “Remove line” to add or remove lines. | 25 BRT 5 –... -
Page 26: Alarms/ Lights
Alarms/ Lights [Menu/Setup/Alarms (Lights)] Adjust the value of the alarms per axle group. Note: The choice of axle groups available depends on the advanced “Configuring the alarms”, p. alarm configuration. See Note: The trigger threshold corresponds to the difference between the alarm value and the value at which the alarm will activate. -
Page 27: Configuring The Alarms
Configuring the alarms [Menu/Setup/-Advanced-/Alarms Config.] Note: This menu only appears when the advanced functions are activated. page Select the axle group to use for the alarm. Menu information: Configuration page Axle group associated with the selectable alarm Trig: Selectable trigger threshold Note: The choice of axle groups available depends on the type of truck “Truck types”, p. -
Page 28: Profiles
Profiles [Menu/Profiles] Note: This menu only appears if the multi-profile option is activated. See page A backup record is a collection of data including: The truck type; The sensor type; The sensors position; The calibration; The alarms configuration; The display configuration. The active profile is surrounded by the “<”... -
Page 29: Advanced Scale Functions
ADVANCED SCALE FUNCTIONS Certain options and menus are only available if the advanced functions have been activated. To activate these functions, navigate to “Menu/Setup/Diagnostic” and press the following buttons in order: 2 - 3 - 2 - 2 - 1. Note: The advanced functions are automatically disabled when the device is turned on or after a period of inactivity. -
Page 30: Advanced
ADVANCED [Menu/Setup/-Advanced-] Saving and loading the configuration [Menu/Setup/-Advanced-/Config. backup] Note: This menu only appears when the advanced functions are activated. See page Save and restore the overall configuration as well as the current profile in the communication box. Note : Make sure you are on the profile you want to back up. To save the global configuration and the current profile, select “Save current config.”... - Page 31 The content of data sets A "profile" includes the following specific configurations: The truck type; The sensor type; The sensors position; The calibration; The alarms configuration; The display configuration. The overall configuration includes the following: The number of the profile in use; The print configuration (except the client header);...
-
Page 32: Copy - Paste
Copy – paste [Menu/System/-Advanced-/Config. backup/Copy/Paste] Note: This menu only appears when the advanced functions are activated. See page Duplicate the current profile’s specific configuration and apply them to all the other available profiles. This makes it easier to create multiple profiles with similar parameters. -
Page 33: System Tests
System tests [Menu/System/-Advanced-/System tests] Note: This menu only appears when the advanced functions are activated. See page Allows you to test the alarms, buzzer and printer. | 33 BRT 5 – User Manual V1.2.007... -
Page 34: Communication
Communication [Menu/System/-Advanced-/Communication] Note: This menu only appears if advanced functions are enabled. See page 29. Configure the two available RS-232 ports of the communication box. The available choices are: Printer Server (communicate with a terminal, for example, a PC) Bridge (communicate only with the monitor) Undefined (unused port) | 34 BRT 5 –... -
Page 35: Special Functions
Special functions [Menu/System/-Advanced-/Special functions] Note: This menu only appears when the advanced functions are activated. See page Configuration of the following advanced functions: Multi-profiles: Activates operating mode with multiple “Profiles”, p. configurations. See Number profiles: Adjusts the maximum number of profiles, from 1 to 25, when the "Multi-profile"... - Page 36 Enable units: Allows pounds to be selected as the unit of measurement. Dis. verif prnt.: Disables the check which makes it impossible to print during a calibration. Simul Prn Detect: Allows to set up the printer header despite its absence. Password: Requests password when accessing the Menu.
- Page 37 Enter Password: Allows configuration of a new password. | 37 BRT 5 – User Manual V1.2.007...
-
Page 38: Calibration
CALIBRATION MENU> CALIBRATION Before calibrating, make sure that: a) Take note of the condition of the truck (level of fuel tanks, cleanliness, weather conditions - since they may affect the calibration); b) The truck remains on a certified scale during data entry; c) The numbers (weight) in the monitor are stable;... -
Page 39: Empty Calibration
Empty Calibration VERY IMPORTANT: Make sure the truck is empty. Step 1 Press Menu. Step 2 ↵ Select Calibration and press Step 3 ↵ Select Empty and press Note: To perform the Full load truck calibration, go to step 11. | 39 BRT 5 –... - Page 40 Step 4 Note: The choice of axle groups available depends on the type of truck selected. “Truck types”, p. ↵ Select the first axle group and press (6 -10 -12 Wheels) (12 W 2 St) (Semi-trailer) Step 5 Using the arrows, adjust the weight to the value indicated by the certified scale.
- Page 41 Step 6 ↵ Press to confirm. Step 7 Repeat steps 4 to 6 for each available axle group in order. When “Total” step is completed, the following message will appear: Note: If the scale has never been calibrated before, the following message will appear: Step 8 Completely load the truck.
-
Page 42: Full Load Calibration
Full Load Calibration Step 9 Press Menu. Step 10 ↵ Select Calibration and press Step 11 ↵ Select Full and press Note: To perform the Empty truck calibration, return to step 3. | 42 BRT 5 – User Manual V1.2.007... - Page 43 Step 12 ↵ Select the first axle group and press Note: The choice of axle groups available depends on the type of truck “Truck types”, p. selected. See (6-10-12 Wheels) (12W 2FR) (Semi-trailer) Step 13 Using the arrows, adjust the weight to the value indicated by the certified scale.
- Page 44 Step 14 ↵ Press to confirm. Step 15 Repeat steps 12 to 14 for each available axle group in order. When the “Total” step is completed, the following message will appear: You are ready to work! | 44 BRT 5 – User Manual V1.2.007...
-
Page 45: Use
SCALE FUNCTIONS Alarms/ Lights Enable/disable the alarms, external lights. The alarms allow the loading equipment operator to know the loading state at all times. To activate the alarms: Press buttons 2 or 3 until the word and pictogram "Alarms” appears at top right. Press Button 1. -
Page 46: Printing
Printing To print a ticket: Press Button 2 or 3 until the word and pictogram “Print” appears at top right. Press Button 1 to start printing. The pictogram will blink to indicate that the first part is printed. Once loading / unloading completed, press Button 1 again to print the second part of the coupon. -
Page 47: Units
Units To change the unit of measure used: Press Buttons 2 or 3 until the word and pictogram “Units” appears at top right. Press Button 1 to change the unit of measure. Note: The kilogram (kg) is the default unit of measurement. | 47 BRT 5 –... -
Page 48: Zeroing
Zeroing Enable/disable the zero function. The zero function allows you to measure the net weight involved when loading or unloading. To enable the zero function: Hold Button 2 to activate zeroing. To disable the zero function: Press Button 2 again to deactivate the zeroing. | 48 BRT 5 –... -
Page 49: Diagnostic
DIAGNOSTIC MENU> SETUP> DIAGNOSTIC Checking the sensors [Menu/Setup/Diagnostic] View the data from all of the sensors connected to the system. When one or more sensors are in error, asterisks will flash on each side if the type and position of these have been defined. Normal working ranges* are: Table of working ranges depending on sensor type Sensor type... -
Page 50: System Information
System information [Menu/Setup/-Advanced-/Information] Note: This menu only appears when the advanced functions are activated. See page 29. View various technical system information: BRT5 NS: monitor serial number Version: version of the monitor software CBox NS: serial number of the communication box Version: software version of the communication box Input: Voltage supply Internal T.: Internal temperature... -
Page 51: Maintenance
Perform the scheduled mechanical maintenance. To avoid voiding the warranty, do not attempt to replace the RT sensor. Contact your TrackWeight representative to reinstall the RT sensor. Cleaning the monitor Make sure the monitor is turned off. -
Page 52: Specifications
SPECIFICATIONS BRT 5 Monitor Screen FSTN. Character height of 4 to 12 mm Dimensions 11.1 cm x 7.5 cm x 2.5 cm Operating temperature -20 °C to 70 °C Resolution 10, 50, 100, in KG or LB Voltage 8.0 V/DC 0.9W Weight 132 g Part Number... -
Page 53: List Of Parts
LIST OF PARTS Display BRT06100 BRT 5 Monitor BRT 6319 BRT 5 Support BRT 6136 2M Monitor Cable Communication Box BRT06500 Communication Box BRT 6137 Power Cable RT Sensor BRT 550M-XX RT mechanical sensor & assembled connector BRT 550-XX RT Mechanical sensor without connector BRT 5419P Sensor connector kit BRT 600... -
Page 54: Technical Support
TECHNICAL SUPPORT Instructions on the main screen If the scale has never been calibrated, messages may appear all over the main screen: If the scale has already been calibrated, the messages will scroll to the top left of the main screen: The possible messages to appear: Calibration required Calibration in progress... -
Page 55: Limited Warranty
TrackWeight documentation. For a period of three (3) years after delivery of the Equipment (“Warranty Period”), TrackWeight agrees to repair the Equipment or have it... - Page 56 You must pay the transportation costs for the return of the Equipment and the related parts, including customs and brokerage fees, if any. In the event that TrackWeight reasonably determines that the Equipment and parts were returned in an unacceptable condition for the Equipment’s type of use, TrackWeight reserves the right to refuse to repair the Equipment and to return it at the buyer’s expense.
-
Page 57: Calibration Sheet
CALIBRATION SHEET Truck/Tractor: ____________ Year: ____________ Unit: ____________ Date: Axle Empty weight Full weight Notes Group Date: Axle Empty weight Full weight Notes Group Date: Axle Empty weight Full weight Notes Group | 57 BRT 5 – User Manual V1.2.007... -
Page 58: Contact Us
Business hours Monday to Friday 8 am to 5 pm (Eastern Canada) TrackWeight products, RT Sensors, BRT 4 and BRT 5 are the property of TrackWeight Systems Inc. All rights reserved 2018. V1.0.004 | 58 BRT 5 – User Manual... -
Page 59: Update Notes
UPDATE NOTES V1.2.007 (BRT06331.1 User Manual EN TrackWeight BRT5): - Updating of screens - Added the Startup screen with details - Added "Date / Time" configuration - Added "Communication" section - Update of the "System Information" section | 59 BRT 5 – User Manual... - Page 60 DESIGN AND MADE IN Onboard truck and semi-trailer scales manufacturer CANADA...
