different than a solenoid-type valve that closes with spring action.
To install a Raven 440 control or the Spraying Systems 744 control on a unit that is not already
equipped with the unit, refer to the
specific instructions that follow.

Raven 440 Controller

Overview
The control valve used with
the Raven 440 Control system is
placed in an in-line location. In
addition, the Raven control may be
equipped with either a wheel
drive or a radar speed sensor.
Installation
The Raven installation
manual should provide most of
the installation information
required. However, the follow-
ing instructions are intended to
help when mounting the Raven flow meter
into the existing plumbing on the Field-Pro II
sprayer.
1. Remove a 7" section of hose from the existing system as illustrated in
Figure 1.
Figure 2.
C9
Figure 1.
