Field Pro II
Effective May 2002
Last Edit May 2002
1000
OPERATOR'S MANUAL
A DIVISION OF RHS, INC.
2005 West Oregon Street • P.O. Box 394
Hiawatha, Kansas 66434 USA
Phone (785) 742-2949 • FAX (785) 742-7174
Call Toll Free 1-800-247-3808
www.rhs-inc.com
DOM-BW010
Revision D

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Field Pro II 1000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bestway Field Pro II 1000

Summary of Contents for Bestway Field Pro II 1000

  • Page 1 Field Pro II 1000 OPERATOR’S MANUAL A DIVISION OF RHS, INC. 2005 West Oregon Street • P.O. Box 394 Hiawatha, Kansas 66434 USA Phone (785) 742-2949 • FAX (785) 742-7174 Call Toll Free 1-800-247-3808 www.rhs-inc.com Effective May 2002 DOM-BW010 Revision D Last Edit May 2002...
  • Page 2 GENERAL INFORMATION Congratulations on your purchase of a BESTWAY sprayer. We at RHS wish to thank you for your patronage and appreciate your confidence in BESTWAY equipment. Your BESTWAY Field- Pro II 1000 sprayer has been carefully designed and ruggedly built to provide many years of dependable service in return for your investment.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction ......A3 Maintenance......E1 Serial Number .

  • Page 4: Introduction

    INTRODUCTION Serial Number The serial number provides important information about your BESTWAY sprayer and may be required to obtain the correct replacement part(s). The serial number plate for the sprayer is located on the right side of the mainframe near the front.
  • Page 5 TAKE NOTE! THIS SAFETY ALERT SYMBOL FOUND THROUGHOUT THIS MANUAL IS USED TO CALL YOUR ATTENTION TO INSTRUC- TIONS INVOLVING YOUR PERSONAL SAFETY AND THE SAFETY OF OTHERS. FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN INJURY OR DEATH. THIS SYMBOL MEANS - ATTENTION! - BECOME ALERT! - YOUR SAFETY IS INVOLVED!
  • Page 6 the following warning symbols. Carefully read and follow the instructions provided. Indicates and imminently hazardous situation that, if not DANGER: avoided, will result in death or serious injury. This signal word is to be limited to the most extreme situations typically for machine components which, for functional purposes, cannot be guarded.

  • Page 7: Warranty

    Warranty RHS, Inc. ("RHS") warrants each new Bestway product to be free from defects in RHS manu- factured components and workmanship. This warranty is applicable only for the normal service life expectancy of the product or components, not to exceed twenty-four (24) consecutive months from the date of delivery of the new Bestway product to the original purchaser.
  • Page 8 Except as set forth above, RHS shall have no obligation or liability of any kind on account of its equipment and shall not be liable for special or consequential damages. RHS makes no other warranty, expressed or implied, and, specifically, RHS disclaims any implied warranty or merchantability or fitness for a particular purpose.

  • Page 9: Specifications

    SPECIFICATIONS...
  • Page 10 Overall Dimensions Capacities (A) Total length 220 in. (5488 mm) Sprayer tank 1,000 gal. (3785.5L) Rinse system tank 50 gal. (189.3 L) Chemical induction tank 4 gal. (15.2 L) (B) Hitch to axle length 136 in. (3455 mm) Fresh water tank 5 gal.

  • Page 11: Safety Sign Locations

    Safety Sign Locations P/N 67657 P/N DEC-HAZ01...
  • Page 12 P/N 67673 P/N SW001 P/N/ 67671 P/N 67672 P/N DEC-HAZ02 P/N SW900 P/N 60962...

  • Page 13: Safety Sign Care

    Safety Sign Care • Keep safety signs clean and legible at all times. • Replace safety signs that are missing or have become illegible. • Replaced parts that displayed a safety sign should also display the current sign. • Safety signs are available from your Distributor or Dealer Parts Department or RHS, Inc. How to Install Safety Signs: •...

  • Page 14: Safety Information

    SAFETY INFORMATION As the manufacturer of your BESTWAY Field-Pro II sprayer, we care about your safety. In fact, this machine and its systems have been designed to provide maximum safety. Unfortunately, no machine design can prevent operator error or carelessness.
  • Page 15 pesticide use instructions. When re-entering the cab, remove protective equipment and store either outside the cab in a closed box or some other type of sealable container, or inside the cab in a pesticide resistant container, such as a plastic bag. •...

  • Page 16: Equipment Safety

    mal consumption. Equipment Safety • Make sure no person or object is in the path of the sprayer booms, especially when retract- ing or extending the wings. • Always retract and lock booms in the storage position, except during application. •...

  • Page 17: Lighting And Marking

    Lighting and Marking • It is the responsibility of the customer to know the lighting and marking requirements of the local highway authorities. • REMEMBER: If Safety Signs have been damaged, removed, become illegible or parts are replaced without decals, new decals must be applied. New decals are available from RHS, Inc at 1-800-247-3808.

  • Page 18: Highway And Transport Operations

    Highway and Transport Operations • Comply with state and local laws governing highway safety and movement of farm machinery on public roads. • Always operate equipment in a position to provide maximum visibility at all times. Make allowances for increased length and weight of the equipment when making turns, stopping the unit, etc...

  • Page 20: Initial Preparation And Setup

    INITIAL PREPARATION AND SETUP Tractor Preparation and Hookup 1. Check and adjust tractor drawbar as shown so that it is located 13 to 17 inches above the ground. Then adjust the drawbar to a stationary position so that the hitch pin is directly below the center line of the PTO shaft.
  • Page 21 bumper frame. 4. Attach quick disconnect fittings to ends of hydraulic hoses to match tractor ports. Then con- nect hydraulic hoses to tractor ports in a sequence that is both familiar and comfortable to the operator. It is suggested that the hydraulic hoses for the hydraulic pump be connected to the num- ber one outlet, while the boom control hoses are connected to the number two outlet or to the outlet that corresponds to the outermost control lever on the tractor’s hydraulic control console.
  • Page 22 Some tractors use two 6-volt batteries as a power NOTE: source. Make sure there is a total of 12 volts delivered to the controller by connecting to the Positive (+) terminal of one battery and the Negative (-) terminal of the other battery. Reliable operation of the controller depends on a clean power supply.
  • Page 23 Make certain the red wire is connected to the positive IMPORTANT: side and the black wire to negative while attaching the power leads. Damage to the unit can occur if the leads are reversed. 8. Install the joystick boom control on the #2, or outer hydraulic remote control lever as described and illustrated on the fol- lowing page (Except John Deere 8000 Series...
  • Page 24 choosing the appropriate function. Each button on the joystick represents a different function (Refer to Boom Control Section under Operation). To install the joystick boom control: a. Remove handle grip or ball from appropriate hydraulic lever. b. For round lever, use round U-bolts, washer plate, lock washers and nuts to connect joystick to lever.

  • Page 25: Initial Preparation Of The Sprayer

    To install the footpad: a. Plug the footpad control into the power accessory outlet on the tractor’s control console. b. Connect the footpad con- trol to the main wiring harness from the sprayer. Footpad control for John Deere 8000 Series and Case IH MX Magnum Series.
  • Page 26 Failure to regulate oil flow to the pump will cause IMPORTANT: motor damage. 5. Follow the directions in the sprayer control operating manual to calibrate and set the controller. 6. Fill the sprayer half full of water using the quick fill port (see filling the sprayer in the “Operation”...

  • Page 27: Controller Installation

    preprogrammed in the controller. 10. Turn on the master switch to direct water to the spray nozzles. At this point, the sprayer will be activated and spray tip performance can be visually checked. However, it is recommended that you also use a calibrated container and a stop watch to manually check and calibrate each spray nozzle prior to initial operation.

  • Page 28: Raven 440 Controller

    different than a solenoid-type valve that closes with spring action. To install a Raven 440 control or the Spraying Systems 744 control on a unit that is not already equipped with the unit, refer to the specific instructions that follow. Figure 1.
  • Page 29 2. Attach flow meter mount to valve plate as illustrated in Figure 2 using two 5/16” x 3/4” bolts and 5/16” locknuts provided. 3. Locate flow meter and hose clamps supplied in the control kit and install flow meter in the line where the 7"...
  • Page 30 Raven 440 Spray Wiring Diagram...

  • Page 31: Spraying Systems 744 Controller

    Spraying Systems 744 Controller Overview The Spraying Systems 744 controller allows the operator to adjust the spray pressure from the console. The control valve is placed in a bypass location which dumps unwanted pressure back to the inlet of the pump. Hence, it is important that you do not use an in-line configuration for the control valve.
  • Page 32 DESCRIPTION 150-G GASKET, 2" MANIFOLD FITTING FC200 CLAMP, 2" MANIFOLD (NOT SHOWN) M200100TEE TEE, 2" x 1" MANIFOLD, POLY M100G GASKET, 1" MANIFOLD FITTING FC100 CLAMP, 1" MANIFOLD (NOT SHOWN) M100FPT FTG, 1" MANIFOLD x 1"FPT M-1034PP NIPPLE, 3/4”MPT X 1”MPT METERING VALVE (INCLUDED WITH CONTROLLER) EL-3410PP...
  • Page 33 Figure 6.
  • Page 34 Spraying Systems 744 Wiring Diagram 3 Section Plumbing Figure 7.

  • Page 35: Raven Radar Mount

    Raven Radar Mount Raven Radar Mount DESCRIPTION SU12.6.312 U-bolt, Sq. 1/2NC x 3-1/2 x 6 LW12 Lock Washer, 1/2” ZP Nut, 1/2”NC ZP 74231 Wment, Radar Mount - FP Trailers B38.1 Bolt, 3/8NC x 1 FW38 Flat Washer, 3/8” LW38 Lock Washer, 3/8”...

  • Page 36: Operation

    Main tank Quick-Fill, “on” position OPERATION Filling The Tank The 1,000 gallon tank on the Field-Pro II sprayer can be filled in one of two ways – through the top hatch using auxiliary equipment, or through the Quick-Fill valve auxiliary equipment. To fill the tank through the Quick-Fill valve: 1.

  • Page 37: Using The Optional Flow Max 110 Fill Meter

    7. Open Quick-Fill valve to begin filling. 8. When fill meter registers desired amount, or tank is full, close Quick-Fill valve and reverse the previous steps. Using the Optional Flow Max 110 Fill Meter The Flow Max 110 Fill Meter, available as optional equipment on the Field-Pro II sprayer, can be used to monitor a variety of functions including: Function Display Title...
  • Page 38 Entering Data 1. Turn on console by depressing ON. 2. Toggle to the desired function category by depressing the key labeled 3. Depress ENTER key. Display will flash "E". 4. Enter data one digit at a time, starting with the left digit. To increment through the numbers, depress the key labeled until the correct number is reached.
  • Page 39 Inductor Sparge valve, “on” position Pump inlet Inductor rinse valve, selector valve, “off” position Induction valve, Inductor discharge valve, “off” position “off” position Adding and Mixing Chemicals Although chemicals can be added directly to the main tank through the hinged tank lid, the sprayer has been equipped with a chemical induction system for quick loading and thorough mix- ing.

  • Page 40: Boom Operation

    6. Open inductor discharge valve to transfer chemical to main tank. 7. Rinse chemical container and inductor tank using handgun provided. Close inductor dis- charge valve when inductor tank is empty. 8. Close induction valve and raise inductor tank to transport position. Pull outward and upward on inductor handle to unlock scissors lift mounting bracket.

  • Page 41: Boom Control With John Deere 8000

    boom or rearward to raise the boom. Reversing the hydraulic hoses will reverse the control operation. Smoothest operation is attained by first depressing the NOTE: button and then moving the remote control lever. When only a small amount of movement is desired, hold the button and feather the hydraulic lever in the appropriate direction.

  • Page 42: Extending The Boom Wings

    Extending Boom Wings. 1. Remove transport pin from center section to let boom pivot freely (X-Fold only). 2. Unfold wings until boom cylinders are fully extended 3. Lower center section to desired spray height (X-Fold only). Make sure no person or object is in the path of the DANGER: wings, especially when folding or unfolding.
  • Page 43 2. Activate tractor hydraulic valve to start sprayer pump. 3. Toggle boom switches to their "on" position for each of the boom sections. 4. If controller is equipped with an Auto/Manual function, make sure it is switched to "Auto." 5. As you enter the field to the point where you will begin spraying, turn Master boom switch to the "on"...

  • Page 44: Foam Marker Operation

    Foam Marker Operation Refer to the Operator’s Manual of your Foam Guidance System for operating instruc- tion. 30 gallon foam solution tank Foam Guidance Pump Unit Controlling Drift Drift can be defined as the movement of spray droplets outside the intended target. It is one of the biggest environmental concerns chemical applicators face.

  • Page 45: Types Of Drift

    Although some products have a greater tendency to drift than others, due to their volatility, the potential for drift exists with any chemical. Unfortunately, with the advent of genetically altered crops like Roundup Ready soybeans, and Liberty Link corn, the potential damage that can occur as a result of chemical drift is greater than ever before.

  • Page 46: Managing Drift

    too high obviously favors drift, since droplets have farther to fall, thus having more time and opportunity to drift off course. Doubling the boom height, in effect, doubles the length of time required for droplets to reach the target canopy. That, in turn, doubles the horizontal distance droplets can travel during their fall.

  • Page 47: Spray Nozzle Selection

    Spray Nozzle Selection Nozzle, or spray tip, selection is often based upon droplet size, which refers to the diameter of an individ- ual spray droplet. In addition to its importance in controlling drift, droplet size from a nozzle becomes important when the efficacy of a particular crop chemical is dependent on coverage.

  • Page 48: Rinsing The Sprayer

    Rinsing The Sprayer It's important that you rinse the sprayer after each use, and every time you change chemical solutions in the tank. In most cases, it's best to rinse and flush the sprayer in the field, to minimize handling issues, with rinse water. In some cases, you may also want to add a commercial tank cleaner to the rinse water to help dissolve or neutralize certain chemicals.

  • Page 50: Maintenance

    Taking the time to clean the sprayer after each use is the most important thing you can do to improve the performance and longevity of your BESTWAY Field-Pro II sprayer. This is particularly important after the use of suspension type chemicals, which can crystalize and plug the flowmeter, lines and/or spray tips.

  • Page 51: Lubrication

    Lubrication Grease Fittings Proper lubrication will help insure efficient operation of your BESTWAY sprayer and prolong the life of friction producing parts. Those parts equipped with grease fittings should be lubricated at the frequency indicated with an SAE multi-purpose type grease. Be sure to clean the fitting thor- oughly before using any grease gun.
  • Page 52 12 Hours 12 Hours...
  • Page 53 12 Hours (both sides of boom center section) 12 Hours...

  • Page 54: Line Strainer Maintenance

    Bestway dealer or RHS, Inc. Sprayer Nozzle Maintenance Spray Tip Care Careful cleaning of clogged spray tips can mean the difference between a clean field and one with weed streaks.

  • Page 55: Tip Replacement

    be removed and washed in clean water and detergent each time the sprayer is cleaned, or as needed. To remove the tip and screen, simply twist the collar which holds the screen in place and remove the tip from the nozzle.

  • Page 56: Tire Pressure

    • Ceramic - Superior wear life and is highly resistant to abrasive and corrosive chemicals. • Hardened stainless steel - Very good wear life, good durability and chemical resistance. • Stainless steel - Good wear live, excellent chemical resistance and a durable orifice. •...

  • Page 57: Tread Width Adjustment

    7. Pack bearings with heavy-duty wheel bearing grease, thoroughly forcing grease between roller cone and bearing cage. Also fill the space between the bearing cups in the hub with grease. 8. Place inner bearing in hub and press in new grease seal with lip pointing toward bearing. 9.

  • Page 58: Preparation For Storage

    b. If the preceding step does not provide enough adjustment, remove the mounting strap from its inboard or outboard position and reattach it in the alternate position. c. After strap has been repositioned, but left loose, continue to slide the spindle in or out on the axle as needed.
  • Page 59 Glycol is a primary component of antifreeze and is poi- WARNING: sonous if ingested. Follow all precautions as if it were any pesticide. Be especially careful to avoid puddles that pets or other animals can get to. 10. Drain the personal wash tank completely. Wash the interior with a detergent solution, rinse and dry by hand.

  • Page 60: Troubleshooting

    TROUBLESHOOTING GUIDE Field-Pro II Operation Problem - Probable Cause. Action No pressure in spray system √ Pump not running. Make sure hydraulic hoses are hooked up correctly. Verify that impeller is turning. √ Pump not primed. Turn on tank valve. Make sure the pump volute is flooded. √...
  • Page 61 Boom valves won’t turn on √ Valved not hooked up to 12 volts. Valves require 12-volt power in addition to the signal from the controller. √ Fuse has blown. Check tractor fuse panel for blown fuse. √ Wiring connection bad. Check all wiring connections. Individual nozzles turning on and off erratically √...

  • Page 62: Parts Listing

    PARTS LISTING 1000 Gallon Frame and Tank Assembly...
  • Page 63 Gasket, Fillwell - 16" (HyTek) 69617 Tank, Eyewash 1000/1200 gal. Replacement w/lid TLS-6SL Tank Lid, 6" - Snyder Tanks TLA-5T Tank Lid, 5” - Ace Tank (with Bestway Logo) 60146 Valve, Fresh Water 73807 Wment, Fresh Water Valve Mtg Bracket STS14.34SS...
  • Page 64 69616 J-Bolt, 1/2"NC ZP - 1000/1200 Gal.Tank Hoop FW12 Washer, Flat - 1/2" ZP Nut, 1/2NC Gr5 ZP DEC-BW003 Decal, Bestway - 18"W x 4-1/2"T, Black SW001 Decal, Warning - Read Manual SW900 Decal, Danger - Toxic Chemicals 67672 Decal, Caution - Chemical Safety, 3" x 5"...
  • Page 65 Bolt, 1/4NC x 3/4 FW14 Flat Washer, 1/4” LN14 Lock Nut, 1/4NC DEC-BW007 Decal, Bestway Logo DEC-OM001 Decal, Operators Manual * ladder(item 34) shown on left side of trailer is optional and required only if sprayer does not include factory installed chemical inductor.

  • Page 66: Base Plumbing Details

    Base Plumbing Details...
  • Page 67 Base Plumbing Details DESCRIPTION EL-200112PP Elbow, 2"mpt x 1-1/2"hb EPDM112 Hose, EPDM 1-1/2", 300psi, 6" Lg HC-112TB Clamp, T-Bolt - 1-1/2" Hose, S.S. 73728 Tube, Sparge - 1000/1200 MBF200 Bolted Tank Flange, 2" Manifold x 2"mpt, Polypro 150-G Gasket, 1-1/2" Coupler, EPDM FC200 Clamp, 2"...

  • Page 68: X-Fold Boom Center Section

    X-Fold Boom Center Section...
  • Page 69 X-Fold Boom Center Section DESCRIPTION 73700 Wment, Outer - Xfold 73600 Wment, Inner - Xfold 73604 Wment, Frame - Xfold 73606 Wment, Slider - Xfold 72427 "Wear Strip - 24"" Lift 72428 Wment, Lift Tie Rod - Xfold 73611 Wment, Frame Brace Mnt - Xfold 73605 Bar, Brace - Xfold SU12.6.312...

  • Page 70: X-Fold Boom Inner Wing Detail

    X-Fold Boom Inner Wing Detail...
  • Page 71 61538 Plug, 1.75sq x 10-14ga. Black X-Fold Boom Inner Wing Detail DESCRIPTION (see previous page) Center Section Assembly 73671 Wment, 1st Section Left - Xfold 73672 Wment, 1st Section Right - Xfold 73620 Wment, Wing Brace - Xfold 73689 Bar, Fold Link - Xfold 73687 Wment, Fold Yoke - Xfold 73623...

  • Page 72: X-Fold Boom Outer Wing Detail

    X-Fold Boom Outer Wing Detail...
  • Page 73 X-Fold Boom Outer Wing Detail DESCRIPTION 73671 Wment, 1st Section Left - Xfold 73672 Wment, 1st Section Right - Xfold 73663 Wment, 2nd Section Left - Xfold50 73664 Wment, 2nd Section Right - Xfold50 73661 Wment, 2nd Section Left - Xfold60 73662 Wment, 2nd Section Right - Xfold60 73612...

  • Page 74: X-Fold Boom Hydraulic Detail

    X-Fold Boom Hydraulic Detail...
  • Page 75 X-Fold Boom Hydraulic Detail DESCRIPTION 61626 Cylinder, Hyd. - 2" Bore x 30" Stroke x 1-1/8" Rod 639572 Repair Kit, Red Lion Hyd. Cylinders-2"Bore x 1-1/8"Rod 203-425 Repair Kit, Chief Hyd. Cylinders-2"Bore x 1-1/8"Rod 61825 Cylinder, Hyd. - 2-1/2"Bore x 20"Stroke x 1-1/4"Rod 639574 Repair Kit, Red Lion Hyd.

  • Page 76: X-Fold Boom Plumbing Schematic

    X-Fold Boom Plumbing Schematic...
  • Page 77 X-Fold Boom Plumbing Schematic DESCRIPTION EPDM10 Hose, 1”EPDM x 35 feet EPDM10 Hose, 1”EPDM x 18 feet EPDM34 Hose, 3/4”EPDM x 24” EPDM34 Hose, 3/4”EPDM x 48” EPDM34 Hose, 3/4”EPDM x 19” 22252312750NYBV Nozzle Body, “T” 3/4”HB 22251311750NYBV Nozzle Body, “L” 3/4”HB QJ111SQ114303SS Clamp, Nozzle Body - Square 1-1/4”...

  • Page 78: Flex-Pro Boom Center Section Assembly G17

    Flex-Pro Boom Center Section Assembly...
  • Page 79 Bolt, 3/8NC x 3-1/2 Gr5 ZP B38.34 Bolt, 3/8NC x 3/4 Gr5 ZP DEC-HAZ02 Decal, Danger - Electrocution Hazard 60962 Decal, Warning - Overhead Hazard 60986 Decal, Reflective - Red 60987 Decal, Reflective - Amber DEC-BW004 "Decal, Bestway - 13-7/8""W x 3-1/2""T, Yellow...

  • Page 80: Flex-Pro Boom Wing Assembly

    Flex-Pro Boom Wing Assembly...
  • Page 81 Flex-Pro Boom Wing Assembly DESCRIPTION 73273 Wment, 1st Wing 73261 Wment, Pivot L Plate 73299 PLG 60167-Plate, Pivot L 73260 Wment, Pivot Plate 73304 Plate, Bolton Pivot (see wheel assy) Wheel Assembly 67343 Tire, B78-13 4PLY 6.5 73297 Wment, 2nd Wing 73272 Wment, Link Arm 73271...

  • Page 82: Flex-Pro Boom Transport Stand

    Flex-Pro Boom Transport Stand Flex-Pro Boom Shocked Wheel...
  • Page 83 B34.5 Bolt, 3/4”NC x 5” Gr5 ZP Flex-Pro Boom Transport Stand DESCRIPTION 72465 Wment, Trans Stnd 71046 Wment, Cross Mnt - FlexPro 71052 Tube, Wingrest Cross - FlexPro 71061 Wing Rest w/Wear Strip - FlexPro 72424 Wear Strip - FlexPro B14.34FSC Bolt, 1/4NC x 3/4, Flat Head Socket Cap LN14...

  • Page 84: Flex-Pro Boom Hyddraulic Schematic

    Flex-Pro Boom Hydraulic Schematic...
  • Page 85 Flex-Pro Boom Hydraulic Schematic DESCRIPTION 60963 Hose, Hyd. - 3/8" x 108", 3/8”mpt x 1/2”mpt 60261 "Hose, Hyd. - 3/8"" x 72"", 3/8mpt Both Ends 6MP-6FPS-R047 Adapter, Hyd. - 3/8"mpt x 3/8"fpsw, 0.047"restrictor 6MP-6FPS-6FPS Adapter, Hyd. Tee - 3/8"mpt x 3/8"fpsw x 3/8"fpsw 60260 Hose, Hyd.

  • Page 86: Flex-Pro Boom Hydraulic Hose Routing . G25

    Flex-Pro Boom Hydraulic Hose Routing...
  • Page 87 Flex-Pro Boom Hydraulic Hose Routing DESCRIPTION 60261 Hose, Hyd. - 3/8" x 72", 3/8”mpt Both Ends 60260 Hose, Hyd. - 3/8" x 96", 3/8”mpt Both Ends 60965 Hose, Hyd. - 3/8" x 156", 3/8”mpt Both Ends TS-14 Tie Strap, 14"...

  • Page 88: Quick Fill Meter Kit

    Quick Fill Meter Kit DESCRIPTION 71878 Mount Bracket, Flow Meter - Quick Fill A-200 Barb, 2 mpt x 2 hb Polypro B14.34 Bolt, 1/4NC x 3/4 Gr5 ZP FW14 Washer, Flat - 1/4" ZP LW14 Washer, Lock - 1/4" ZP Nut, 1/4NC Gr5 ZP HC-200TB Clamp, T-Bolt - 2"...

  • Page 89: Wheel / Hub Assembly

    Wheel / Hub Assembly DESCRIPTION 69123 Tire, 12.4-38-8PlyBias /w 8 Bolt Wheel & Sensor Holes W38-05100 Rim Only, 12.4 x 38, 8 bolt 69145 Hub Assembly, W60-8 68171 Hub, Studded w/Cups - W60-8 68176 Stud, 5/8 x 2-1/4 W60-8 Hub 69173 Bearing Cup, W60-8 inner 69171...
  • Page 90 Outback Foam Guidance System, Model 6 or 10...

  • Page 91: Outback Foam Guidance System, Model 6 Or 10

    Outback Foam Guidance System, Model 6 or 10 DESCRIPTION TLA-5T Tank Lid, 5" - 14,19,&25 gal. ACE Tanks ACE003 Tank, 33 Gal Suitcase AA719 Wment, 33gal Tank Stand B12.3 Bolt, 1/2NC x 3 Gr5 ZP FW12 Washer, Flat - 1/2" ZP LN12 Nut, Lock - 1/2NC ZP SU12.6.312...

  • Page 92: 9303C-Hm1C Pump Kit

    9303C-HM1C Pump Kit...
  • Page 93 9303C-HM1C Pump Kit DESCRIPTION 9303C-HM1C Pump, Hyd. Centrifugal - 1 1/2"fpt x 1 1/4"fpt, Black 1 69826 Hose, Hyd. - 3/8" x 72", 1/2"mpt x 1/2"mpt Elbow 69266 Hydra Grip - One Pair (Red Grip) 69266 Hydra Grip - One Pair (Black Grip) 8FP-QM Adapter, Hyd.

  • Page 94: Inductor Kit

    Inductor Kit...
  • Page 95 Inductor Kit DESCRIPTION 71897 Weldment, Inductor Mount Bracket 71894 Weldment, Upper Mount Arm 71895 Weldmnt, Lower Mount Arm 71891 Weldment, Inductor Tank Bracket B12.1 Bolt, 1/2NC x 1” FW12NYL Washer, Nylon Flat - 1/2” B12.112 Bolt, 1/2NC x 1-1/2” B12.6 Bolt, 1/2NC x 6”...

  • Page 96: Rinse System Assembly

    Rinse System Assembly...
  • Page 97 Rinse System Assembly DESCRIPTION 61809 Tank, 50 gallon PCO TLS-6SL Tank Lid - Snyder Tanks TLA-5T Tank Lid - Ace Tanks (with Bestway Logo molded in) 71920 Tank Strap 69553 Tank Buckle B38.5FT Bolt, 3/8NC x 5 Full Thread FW38 Flat Washer, 3/8"...

  • Page 98: Deluxe Plumbing Plate W/ 3-Valve Stack Assembly

    Deluxe Plumbing Plate with 3 Valve Stack Assembly...
  • Page 99 Deluxe Plumbing Plate with 3 Valve Stack Assembly DESCRIPTION HC-114TB Clamp, T-Bolt - 1-1/4" Hose, S.S EPDM114 Hose, EPDM 1-1/4", 300psi, 48” Long MLST150-50 Strainer, 2" Manifold, "T", 50 mesh M200125BRB90 Elbow, 2" Manifold x 1-1/4" hb, Polypro 150-G Gasket, 1-1/2" Coupler, EPDM MV200CF Ball Valve, 2"...

  • Page 100: Electrical Wiring Details

    ELECTRICAL WIRING DETAILS Field Pro II Wiring Diagram...
  • Page 101 Field Pro II 1000 Wiring Diagram DESCRIPTION 69691 Harness, Wire - Fasse Joystick Control 69684 Harness, Wire - Fasse Hyd. Block 69692 Harness, Extension - 17', Fasse 3 Function AB363 Wiring Harness, Complete -OBK10 (AB474 & AB473) AB474 Wiring Harness, Main Cable - OBK10...

  • Page 102: Field Pro Ii Wiring Diagram For 3 Section Ball Valve Plumbing

    Field Pro II Wiring Diagram for 3 Section Ball Valve Plumbing...
  • Page 103 Field Pro II 1000 Wiring Diagram ( for 3 Section Ball Valve Plumbing) DESCRIPTION AB453 Control Valve Wiring - 3 Section Control TS000 DIN Connector AB455 Control Valve Wiring - Replacement Harness 32902 Ring Connector, #10 x 12-10ga, Heat Shrink 37052 Male Tab, #10 - 1/4"...
