- Page 1 MegaSpartan User Manual MegaSpartan User Manual, Release Date: Aug 22 2018...
- Page 2 The Lambda Sensor gets very hot during normal operation, be careful when handling it. • While the Lambda Sensor is in an active exhaust stream it must be controlled by MegaSpartan. Carbon from an active exhaust can easily build up on an unpowered sensor and ruin it.
-
Page 3: Lambda Sensor Installation
For normally aspirated engines the sensor should be installed about 2ft from the engine exhaust port. For Turbocharged engines the sensor should be installed about 3ft from the engine exhaust port after the turbocharger. For Supercharged engines the sensor should be installed 3ft from the engine exhaust port MegaSpartan User Manual, Release Date: Aug 22 2018... - Page 4 TunerStudio Configuration for MegaSquirt 2 In TunerStudio under “Basic Setup” select “EGO Control”. For MegaSpartan with single Lambda, set “EGO Sensor Type” to “Single Wide Band”, set “1 EGO sensor port” to “Remote ADC0”. “Burn” the settings to your MegaSquirt.
- Page 5 For MegaSpartan with dual Lambda, set “EGO Sensor Type” to “Dual Wide Band”, set “1 sensor port” to “Remote ADC0”, set “2 EGO sensor port” to “Remote ADC1”. Burn the settings to your MegaSquirt. Under “Tools” select “Calibrate AFR Table”...
- Page 6 For each Lambda sensor, set the “EGO X Port” to “CAN EGO”. Set “MS3X Inj A” to “MS3X Inj H” to the appropriate EGO#. EGO1 is MegaSpartan Lambda 1 … EGO8 is MegaSpartan Lambda 8. For example, if you set “MS3X Inj A” to “EGO1” then MegaSquirt will assign MegaSpartan Lambda 1 to Injector A.
-
Page 7: Hardware Dip Switches
Warranty does not cover user error and abuse. Disclaimer 14Point7 is liable for damages only up to the purchase price of its products. 14Point7 products should not be used on public roads. MegaSpartan User Manual, Release Date: Aug 22 2018...
