Safran EVBA 2.0 Technical Note

VS1000: Evaluation Kit EVBA_2.0
EVBA_2.0 - is a "plug and play" Evaluation Kit for Safran Colibrys VS1000 accelerometers line.
To facilitate the integration in user environment and easily verify the excellent performances of VS1000 sensors,
EVBA_2.0 integrates a VS1000 sensor with the user specified range, an ultra-low-noise, high-accuracy 3.3V voltage
reference, the decoupling capacitors and output buffers.
Features:
- Low noise power supply management converting +5V to 3.3V
- Output signal conditioning:
 buffers to enable the use of long lines between the sensor and the user electronic
 low-pass filters with a cutting frequency
- Easy integration into system: 4 fixing holes
- Industrial interface
Contents
1 EVBA_2.0 description: ......................................................................................................................................... 2
2 Evaluation board function .................................................................................................................................... 4
3 Operation ............................................................................................................................................................. 7
4 Ordering Information ............................................................................................................................................ 9
5 Disclaimer ............................................................................................................................................................ 9
VS1000: Evaluation Kit EVBA_2.0
Document number
Document revision
Date of revision
Note
Safran Colibrys reserves the right to change these data without notice
30N.EVBA_2.0.A
V1.0
06 September 2016
Safran Colibrys reserves the right to change these data without notice
TECHNICAL NOTE
