Operating Instructions
REOTRON MEW
Single Phase Power Controller
REO UK LTD
Units 8 -10 Long Lane Industrial Estate
Craven Arms, Shropshire SY7 8DU
Tel: 01588 673411
Fax: 01588 672718
http://www.reo.co.uk
eMail: main@reo.co.uk
ELEKTRONIK
ELEKTRONIK
ELEKTRONIK
ELEKTRONIK
Publication No.:
2022_GBANL.doc
08/99
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reo Elektronik REOTRON MEW
Summary of Contents for Reo Elektronik REOTRON MEW
- Page 1 ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK Operating Instructions REOTRON MEW Single Phase Power Controller REO UK LTD Publication No.: 2022_GBANL.doc Units 8 -10 Long Lane Industrial Estate 08/99 Craven Arms, Shropshire SY7 8DU Tel: 01588 673411 Fax: 01588 672718 http://www.reo.co.uk eMail: main@reo.co.uk...
- Page 2 ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions Technical Safety Information for the User This description contains the necessary information for the correct application of the product described below. It is intended for use by technically qualified personal. Qualified personnel are persons who, because of their training, experience and position as well as...
-
Page 3: Table Of Contents
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions Contents Page 1.0 General 2.0 Function Description 2.1 Effective Current Value 2.2 Effective Voltage Value 2.3 Current Regulation 2.4 Voltage Regulation 2.5 Pulse Generation 2.6 Temperature Monitoring 3.0 Control Inputs and Outputs 3.1 Setpoint Input U... -
Page 4: General
Operating Instructions 1.0 General The range of REOTRON MEW Thyristor Regulators are microprocessor based units for controlling the power to resistive and inductive loads. In essence the units comprise inverse parallel connected power semiconductors (thyristors) and the control and regulation electronics. The units have a regulated, AC output. -
Page 5: Effective Current Value
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 2.1 Effective Current Value The effective current value is measured inside the unit through a current transformer and a burden resistor. The internal microprocessor determines the effective value of the output current and adjusts this using a PI regulator. -
Page 6: Setpoint Input U
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions With power regulation here the power setpoint is determined 3.1 Setpoint Input U (switch S1/6=ON) The value of the output voltage is determined by the setpoint input U. The setpoint can be provided in the form of 0-10 V, 0-20mA, DC or with a 10kΩ... -
Page 7: Adjustment Facilities
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 5.0 Adjustment Facilities The following parameters can be adjusted on the unit:- Umax - Maximum Output Voltage Umin - Minimum Output Voltage Imax - Maximum Output Current Imin - Minimum Output Current... - Page 8 ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions Adjustment of the MIN - Values: Umin Trimmers P1 and P2 are used to adjust the MIN value, however these trimmers are used for various other functions. Below is the recommended adjustment procedure.
-
Page 9: Technical Data
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 7.0 Technical Data TYPE Rated Voltage Output Voltage Output Current 50/60 Hz MAX. MEW 10/230 230 V +6% -10% 0-230 V 10 A MEW 10/400 400 V +6% -10% 0-400 V 10 A... -
Page 10: Ordering Codes
REOTRON MEW 10/230 6311 10 A/230 V Standard unit REOTRON MEW 10/400 6312 10 A/400 V Standard unit REOTRON MEW 10/230 DA 6316 10 A/400 V with D/A-Module REOTRON MEW 10/400 DA 6317 10 A/400 V with D/A-Module REOTRON MEW 10/230 RS... -
Page 11: Adjustment Components
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 9.0 Adjustment Components LED Indicator Functions ERROR System fault TEMP Over temperature SYNC Mains synchronisation fault I-Max Current limit reached ie current regulator active LOAD Impedance fault / peak current reached ELEKTRONIK... -
Page 12: Fuse Change
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 10.0 Fuse change Switch unit off before changing fuse! The semiconductor fuse can be found in the left hand section of the front panel. To change the fuse the two screws marked "x" must be loosened. The cover can then be removed by sliding it to the right. -
Page 13: Connection Diagrams
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 13.0 Connection Diagrams Control Terminals +10V +10V Voltage setpoint Current setpoint Enable Enable 0 - 10V, DC 0 - 10V, DC (Power setpoint) Setpoint Voltage Setpoint Current (Setpoint power) Potentiometer setpoint source... -
Page 14: Dimension Drawing
ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 14.0 Dimensions ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK ERROR TEMP SYNC I-max LOAD INIT READY ENABLE U-max I-max RESET SETUP REOTRON Dimension MEW10 MEW20 MEW50 MEW80 MEW110 UK LTD... - Page 15 ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK REOTRON MEW Operating Instructions 14.1 Dimensions MEW 150/XXX ELEKTRONIK ELEKTRONIK ELEKTRONIK ELEKTRONIK ERROR TEMP SYNC I-max LOAD FOR CONTINU ED FIRE PROTECTION REPLACE M AX ONLY WITH SPECIFIED INIT TYPE AND RATED FUSE READY ENABLE O FF...
