- Page 1 4212 PC SOFTWARE PROGRAMMING GUIDE WE RECOMMEND 4212 PC SOFTWARE PROGRAMMING GUIDE EN-UK This equipment be installed by a V.1.0 Competent Electrician, Security 17/09/15 Installation or Communications Engineer.
-
Page 2: Table Of Contents
4212 PC SOFTWARE PROGRAMMING GUIDE CONTENTS INTRODUCTION SOFTWARE INSTALLATION 4 - 5 • USB Driver Installation • 2X00PC Software Installation 4 - 5 HARDWARE INSTALLATION 5 - 6 TERMINALS, JUMPERS AND SWITCHES TECHNICAL SPECIFICATION USING THE SOFTWARE 7 - 37 •... - Page 3 4212 PC SOFTWARE PROGRAMMING GUIDE • Enable; Clear CODE + FOB WINDOW • Code and Fob Setup on the Code + Fob Window PROGRAMMER SCREEN TOP MENU 28 - 36 • FILE 29 - 31 • New; Open; Open Recent •...
-
Page 4: Introduction
INTRODUCTION This programming guide is intended to give an introduction on the additional programming features found in the 2X00PC software (version 7.0.0.14 or later) for programming the 4212 series digital door panel. The connection to the device is via a micro USB cable between the PC and the 4212 panel. The software can also be used to program both 2200 and 2300 digital panels as well as the UIM-138 display and voice annunciation module. -
Page 5: Hardware Installation
: Exit out of the start up program. EMAIL TECHNICAL : This will open your default email program so that you can send an email to the Videx Technical Support. EMAIL SALES : This will open your default email program so that you can send an email to the Videx Sales Department. -
Page 6: Terminals, Jumpers And Switches
4212 PC SOFTWARE PROGRAMMING GUIDE TERMINALS, JUMPERS AND SWITCHES CONNECTION TERMINALS 4212 Digital Panel +12Vdc camera power supply input. 0V camera power supply input and connect the USB cable into the GNDV video ground on coax video system. the micro USB connection Balanced video signal sync- (V2) or coax V2/V video signal (V). -
Page 7: Using The Software
4212 PC SOFTWARE PROGRAMMING GUIDE USING THE SOFTWARE Launching the Software Launch the 2X00PC software by double clicking on the desktop icon. The initial launch window will appear (as shown on the right). At the top of the window the software will show that it is checking for any devices connected to the PC or laptop. -
Page 8: Settings Window
4212 PC SOFTWARE PROGRAMMING GUIDE Before programming the 4212 digital panel the correct system type must be selected from the top menu. To do this select ‘System’ from the top menu bar and then from the drop down menu highlight and select ‘VX2200 Graphical Display’ , (as shown to the right). -
Page 9: Screen Switch Time; Lock Time; Speech Time; Master Code; Admin Code; Trade Code And Setup
4212 PC SOFTWARE PROGRAMMING GUIDE Screen Switch Time Just below the three text line fields is the screen switch time field, as shown on the right. This is the time (in seconds) that the main display will switch between the three lines of text (entered in the text fields) and a display logo. -
Page 10: Trade Features; Setting Up A Trade Button
4212 PC SOFTWARE PROGRAMMING GUIDE with the ‘trade start’ and ‘trade end’ fields using the up/down (▲▼) scroll buttons to the right hand side of the respective fields, as shown on the right, (the time format is hours: minutes: seconds). When the trade times are set the trade code will only operate the panel’s relay within these times and will operate the relay for the lock time duration, (e.g. -
Page 11: Speech Playback; Door No.; Language; Door Mode
4212 PC SOFTWARE PROGRAMMING GUIDE Speech Playback In the top right corner of the ‘settings’ window is the speech playback drop down menu with three available options; None, Individual and Combined. This setting is used to set the onboard speech board in the 4212 digital panel. -
Page 12: Master Or Slave; Date Format; Mode; Security Level
4212 PC SOFTWARE PROGRAMMING GUIDE Master or Slave Below the door mode selection is the master or slave drop down menu. Use this menu to set the 4212 panel as a master or slave panel. Date Format Below the master or slave setting is the date format selection. -
Page 13: Wiegand Format; Fob Format; Prox Type; Set The Time And Date
4212 PC SOFTWARE PROGRAMMING GUIDE Wiegand Format Next is the Wiegand format, as shown on the right. From the drop down menu two Wiegand formats are available; Wiegand 26 bit or Wiegand 34 bit. The Wiegand format selection will depend on the requirements of the external access control CPU and is only relevant if an external controller is used. -
Page 14: Check Time And Date; Direct Call; Home2 Present; Rfid Enabled
4212 PC SOFTWARE PROGRAMMING GUIDE Check Time and Date Below the set time and date button is the check time and date button, as shown on the right. Pressing this button will confirm the current time and date setup on the 4212 panel. After pressing this button a confirmation window will appear showing the current time and date, as shown on the right. -
Page 15: Apartments Window
4212 PC SOFTWARE PROGRAMMING GUIDE APARTMENTS WINDOW The next tab on the main programmer screen is for the apartments window, as shown below. This column is the memory location where the user’s data is stored in the 4212 digital panel. It is already completed and ‘grayed’... -
Page 16: Block Id; Access Code; Name; Floor
4212 PC SOFTWARE PROGRAMMING GUIDE Block ID By default this column will be ‘grayed’ out if the initial Door Mode setting in the settings window is set to Local mode and therefore cannot be altered. If an Art.2206N bus exchange device is being used, however, then the block ID can be entered into this field. -
Page 17: En (Enable/Disable)
4212 PC SOFTWARE PROGRAMMING GUIDE EN (enable/disable) Just to the right of the floor column is the EN check box column. This check box can enable (ticked) or disable (unticked) each individual line of programming. When first opening the apartments window this column will NOT FOUND have all the check boxes ticked as default. -
Page 18: Erase Icon; Draw Box Icon; Erase Box Icon; Import Image Icon
4212 PC SOFTWARE PROGRAMMING GUIDE Erase Icon Selecting the erase icon on the right will allow the user to erase individual pixels one at a time. Draw Box Icon Selecting the draw box icon on the right will allow the user to draw an entire box larger than an individual pixel (with no size contraints other than the size of the main 128x64 editing window itself ). -
Page 19: Reverse Icon; Justify Image Icons; Text Icons
Fig.7A with a dark background and light logo and text and if the reverse icon is pressed it will appear as shown in Fig.7B with a light background and dark logo and text. VIDEX VIDEX TECHNICAL... -
Page 20: Clear Icon; Vertical And Horizontal Adjustment Bars
4212 PC SOFTWARE PROGRAMMING GUIDE Clear Icon Clicking on the clear icon will delete everything in the image editing area. Vertical and Horizontal Adjustment Bars The vertical and horizontal adjustment bars allow the user to select a specific region on the main 128x64 pixel editing area and move a specific image, part of an image or text within that specified region by creating ‘pixel zones’... -
Page 21: Coded Access Window
4212 PC SOFTWARE PROGRAMMING GUIDE After a ‘pixel zone’ has been created along each adjustment bar (areas highlighted in white) any image, part of an image or text that is within this region will be fixed in position. Any image, part of an image or text that is not within this region (areas ‘grayed out’) can be moved using the four justify image icons (as described on page 19). -
Page 22: Mem; Name; Apt No; Access Code
4212 PC SOFTWARE PROGRAMMING GUIDE Like on the apartments window this column is the memory location where the user’s data is stored in the 4212 digital panel. It is already completed and ‘grayed’ out. Name The name column for each memory location row has a drop down menu where an optional trade code or user’s name can be selected, as shown on the right. -
Page 23: Enable; Clear
4212 PC SOFTWARE PROGRAMMING GUIDE Enable The enable check box column is next. The enable check box on each row of data will enable or disable the individual user’s access code, as shown below. If the check box is ticked it will enable the user’s access code, and if left unticked will disable the user’s access code. -
Page 24: Proximity Access Window
4212 PC SOFTWARE PROGRAMMING GUIDE PROXIMITY ACCESS WINDOW The next tab on the main programmer screen is the proximity access window, as shown below. The proximity access tab will only be available if the security level on the settings window was set to ‘fob or code’... -
Page 25: Apt No.; Fob/Card Number; Understanding The Fob Format And Car Number
4212 PC SOFTWARE PROGRAMMING GUIDE Apt No. Next is the Apt No. column and like on the coded access window the apartment information in this field will appear once a name has been selected from the drop down menu in the name column. Again the apartment information is taken from apartment number that was entered in the Apt No. -
Page 26: Using The Proxe Deskmount Reader For Programming Fobs/Cards; Code
4212 PC SOFTWARE PROGRAMMING GUIDE Using the PROXE Deskmount Reader for Programming Fobs/Cards When programming with a PROXE deskmount reader the PROXE icon column in the proximity access tab will be highlighted, as shown below. Before using the PROXE deskmount reader to program fobs/cards ensure that it has been setup correctly (refer to page 39 for PROXE setup). -
Page 27: Enable; Clear
4212 PC SOFTWARE PROGRAMMING GUIDE Enable The enable check box column is next. The enable check box on each row of data will enable or disable the individual user’s key fob or card, as shown below. If the check box is ticked it will enable the user’s key fob or card, and if left unticked will disable the user’s key fob or card. -
Page 28: Code + Fob Window
4212 PC SOFTWARE PROGRAMMING GUIDE CODE + FOB WINDOW The code + fob tab will only appear at the top of the main programmer screen if the code + fob option was selected from the security level drop down menu on the settings window (refer to security level selection on page 12). -
Page 29: File
4212 PC SOFTWARE PROGRAMMING GUIDE FILE From the top menu on the main programmer screen when File is selected the following drop down menu will appear, as shown to the right, and the following options are available; New, Open, Open Recent, Save, Save As, Print, Import Old Dat and Exit. -
Page 30: Save; Save As; Print
4212 PC SOFTWARE PROGRAMMING GUIDE • Save - select this option from the drop down menu to save the database file that is open. • Save As - select this option from the drop down menu to save the database file in a specific file location (a specified file path and location can be selected as shown below). -
Page 31: Exit
4212 PC SOFTWARE PROGRAMMING GUIDE • Exit - select this option when all programming is finished and exiting out of the programmer software. (please note that when exiting out of the programmer software a prompt window will appear asking if you want to save the current file before exiting, click on the required button. If saving the file again it will be saved in the same file location as described under the Save As function). -
Page 32: Download Logo
4212 PC SOFTWARE PROGRAMMING GUIDE • Download Logo - select this option to download any logo stored on the 4212 digital panel. UPLOAD From the top menu on the main programmer screen when upload is selected the following drop down menu will appear, as shown on the right. -
Page 33: Upload Code + Prox; Upload Logo; Speed
4212 PC SOFTWARE PROGRAMMING GUIDE • Upload Code + Prox - if the security level has been set to Code + Fob then the Upload Code + Fob option will appear on the drop down menu as shown on the right (refer to page 12 for security level setup). -
Page 34: Apartment No.; Phone Id; Block Id
4212 PC SOFTWARE PROGRAMMING GUIDE • Apartment No. - select this option from the drop down menu, as shown to the right, to set the auto fill parameters (From Mem; To Mem; From Apt No.; Odds or Evens Only and Start) to input the apartment number programming in the Apt No. -
Page 35: Name; Floor
4212 PC SOFTWARE PROGRAMMING GUIDE • From Mem - is the first memory location where the block ID information will be stored. • To Mem - is the last memory location where the block ID information will be stored. • Block ID - is the block ID (from 1 to 15) and is only required if the 4212 panel is connected to a 2206N bus exchange device. -
Page 36: Communication
4212 PC SOFTWARE PROGRAMMING GUIDE COMMUNICATION Next from the top menu on the main programmer screen is the Communication drop down menu, as shown on the right, from which the following options are available; Comm Port, Refresh List, Check Connection and Manually Connect. •... -
Page 37: Detected; Opened File; Saved File; Downloading Settings; Uploading Settings
4212 PC SOFTWARE PROGRAMMING GUIDE If the Check Connection option is then selected from the Communication drop down list the programmer software will then search for the COM port that the 4212 panel is connected to and re-establish a link. This can be seen to the right to the progress bar as shown below. Once the COM port has been found by the programmer software the status bar will update. -
Page 38: No Response
4212 PC SOFTWARE PROGRAMMING GUIDE • No Response - this status is shown when the programmer software has tried to make 3 attempts to upload or download any information from the 4212 panel. The status and progress bar at the bottom of the programmer screen will change and the ‘no response’ window will appear, as shown below. -
Page 39: Connection Diagram
4212 PC SOFTWARE PROGRAMMING GUIDE CONNECTION DIAGRAM PC or Laptop 4212 PC Software Programming Guide EN-UK - V.1.0 - 17/09/15... -
Page 40: Quick Software Setup Guide
4212 PC SOFTWARE PROGRAMMING GUIDE QUICK SOFTWARE SETUP GUIDE 1. Insert the 2X00PC software CD into the PCs CD/DVD rom drive. 2. Select ‘RUN’ from the start menu. 3. Type in ‘D:\setup’ then press the ‘OK’ button. 4. Follow the on screen instructions to complete the setup. 5. - Page 41 4212 PC SOFTWARE PROGRAMMING GUIDE 4212 PC Software Programming Guide EN-UK - V.1.0 - 17/09/15...
- Page 42 4212 PC SOFTWARE PROGRAMMING GUIDE 4212 PC Software Programming Guide EN-UK - V.1.0 - 17/09/15...
-
Page 43: Software Updates
4212 PC SOFTWARE PROGRAMMING GUIDE SOFTWARE UPDATES Date Software Version Revision 25/07/2015 7.0.0.13 Update of PC software to include VX2200 Graphical Display (4212) programming 12/10/2015 7.0.0.14 Update PC software to include additional Logo editing features 19/10/2015 7.0.0.15 Update PC software to include ‘floor’ auto fill feature FIRMWARE UPDATES Date Software Version... - Page 44 Southern Office Videx Security Ltd. 1 Osprey, Trinity Park Trinity Way’ London E4 8TD Northern Office Videx Security Ltd. Unit 4-7 Chillingham Industrial Estate Newcastle Upon Tyne NE6 2XX 4212 PC Software Programming Guide EN-UK - V.1.0 - 17/09/15...
