eta plus ELC X6-60 Technical Documentation Manual

Uv-technology
Hide thumbs
Table of Contents

Advertisement

Quick Links

UV-
TECHNOLOGY
Technical Documentation
ELC
X-Series
®
GB
eta plus electronic gmbh
Lauterstraße 29, D-72622 Nürtingen, Telefon +49 (0) 70 22 - 60 02-80, Fax +49 (0) 70 22 – 6 58 54
Postfach 1411, D-72604 Nürtingen, e-mail: info@eta-uv.de
––––––––––––––––––––––––––––
Eingetragen unter HRB 724321 AG Stuttgart, USt.-Id.-Nr. DE 146267800
Geschäftsführer: Dr. Peter Schwarz-Kiene

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELC X6-60 and is the answer not in the manual?

Questions and answers

Summary of Contents for eta plus ELC X6-60

  • Page 1 TECHNOLOGY Technical Documentation X-Series ® eta plus electronic gmbh Lauterstraße 29, D-72622 Nürtingen, Telefon +49 (0) 70 22 - 60 02-80, Fax +49 (0) 70 22 – 6 58 54 Postfach 1411, D-72604 Nürtingen, e-mail: info@eta-uv.de –––––––––––––––––––––––––––– Eingetragen unter HRB 724321 AG Stuttgart, USt.-Id.-Nr. DE 146267800...
  • Page 2 („Electronic Lamp Control“) is a registered trademark of ® IST Metz GmbH. ELC X-Series-V1.5-06.18-GB subject to technical alterations...

  • Page 3: Table Of Contents

    Contents page I Contents 1 Safety ....................1 1.1 Definition of symbols ................... 1 1.2 Safety advice ....................1 1.3 Correct operation ..................2 1.4 Extended use ....................2 2 Description of functions ..............3 3 Installation ..................4 3.1 Mounting of casing ..................4 3.1.1 Mounting of single ELC ..................
  • Page 4 Contents page II 4 Operation of the ELC ............... 36 4.1 Initial operation ..................36 4.2 Switching on the ELC .................. 36 4.3 Activating the safety circuits ..............36 4.4 Switching on the lamp ................37 4.5 Dimming operation..................39 4.6 Switching off the lamp ................

  • Page 5: Safety

    Safety page 1 1 Safety 1.1 Definition of symbols Stop (Stop Danger). This symbol warns of serious danger of severe injury to persons. It must be strictly observed. Attention (Warning). This symbol indicates information the non-observance of which can lead to extensive damage to property. The safety warning must be strictly observed.

  • Page 6: Correct Operation

    Safety page 2 The ELC causes a leakage current given in chapter 6. Safeguarding by means of leakage current protection type A and type AC according to IEC 60755 is not permitted! The ELC operates in principle as a frequency converter and is equipped with a mains filter whose leakage current could trip the earth leakage detector RCD.

  • Page 7: Description Of Functions

    Description of functions page 3 2 Description of functions The electronic ballast ELC is designed to operate medium pressure discharge lamps as described in chapter 6. In contrast to conventional ballasts (inductive lamp ballast or transformer or transformer with transductor), with an ELC the lamp is operated with high frequency (approx. 100 kHz). The lamp does not flicker and dimming is infinitely adjustable within a wide power range (see chapter 6).

  • Page 8: Installation

    Installation page 4 3 Installation 3.1 Mounting of casing  The ELC may only be installed as described in 3.1.1 and in 3.1.2, allowing for at least minimum spacing shown Fig. Horizontal mounting upside down is not allowed. All vertical mounting orientations are possible.

  • Page 9: Mounting In A Stack

    Installation page 5 Fig. 3: Mounting of the ELC, horizontal orientation 3.1.2 Mounting in a stack Up to 12 ELC may be mounted on top of each other. To fasten the ballasts onto each other a custom-built stacking connector has to be used (available as accessories): Fig.

  • Page 10: Connection

    Installation page 6 3.2 Connection To gain access to the electrical contacts the front hood has to be removed. Loosen the screwing (according to model 4 or 6 x TX20-screw) and detach the front hood. The following paragraphs describe the electrical connections. 3.2.1 Connection overview of ballast types X4 –...

  • Page 11: Profile Of The Cable Gasket X4 - X8

    Installation page 7 3.2.2 Profile of the cable gasket X4 – X8 The IP protection level given in chapter 6 is only guaranteed if every cable’s lead-in is completely sealed. For this purpose the following preconditions have to be fulfilled: Use cables of the nominal diameters given in Table 1.
  • Page 12 Installation page 8  Place the cables into the rubber surrounds and fix them onto the clamp with cable straps: Slide the front hood onto the sealing lip  and pay attention to a tight connection of the front hood. ...

  • Page 13: Overview Power Connections X4 - X8

    Installation page 9 3.2.3 Overview power connections X4 – X8 Fig. 6: Power connection X4-X8 Fig. 6 shows the electrical wiring. Please consider the following aspects: Voltage balancing: on installing several ELCs the ballasts have to be equally distributed on all phases (e.g.

  • Page 14: Connection Overview Of Ballast Types X12 - X36

    Installation page 10 3.2.4 Connection overview of ballast types X12 – X36 Cable gasket Lamp Mains connection Control connections connection Fig. 7: Overview of electrical connections X12-X36 3.2.5 Overview profile of the cable gasket X12 – X36 The IP protection level given in chapter 6 is only guaranteed if every cable’s lead-in is completely sealed.
  • Page 15 Installation page 11 Position Cable Connector Function Connector Connector Cable Plug contact (see diameter designation no. of pins type eta length Fig. 8) ID.: (gasket to connector) 6.8mm ± ferrule, stripping X806 Control 9535 130mm length 7mm 6.8mm ± ferrule, stripping X805 Control 9536...
  • Page 16 Installation page 12 Place the cables into the rubber  surrounds and fix them onto the clamp with cable straps:  On delivery the lead-ins are sealed with blank plugs (see Fig. 9). These can be removed as required. Note to the lead-in of mains supply (cf. position 13 in Fig.

  • Page 17: Overview Power Connections X12

    Installation page 13 3.2.6 Overview power connections X12 Fig. 10: Power connection X12 Please consider the following aspects: Voltage balancing: on installing several ELCs the ballasts have to be equally distributed on all phases (e.g. 1 ballast L1/L2, 2 ballast L2/L3, 3 ballast L3/L1 etc.).

  • Page 18: Overview Power Connections X16 - X36

    Installation page 14 3.2.7 Overview power connections X16 – X36 Fig. 11: Power connections X16 – X36 Please consider the following aspects: Connecting the lines: The Slave module has only to be connected to power supply including PE on X100. The Master module has to be connected to power supply and PE on X100, and additionally to all bus-, control- and lamp cables.

  • Page 19: X100: Mains Connection

    Installation page 15 3.2.8 X100: Mains connection X4-X8: Fix the mains connection cables within the cable holder beneath the heat sink with cable straps. The cables have to be laid behind the control connectors to reach the cable gasket. X12-X36: Fix the mains connection cables within the cable holder with cable straps. The cables have to be laid beneath the board to reach the cable gasket.

  • Page 20: X600: Connecting The Lamp Feeder Cable

    Installation page 16 3.2.9 X600: Connecting the lamp feeder cable  The lamp feeder cable must correspond with the cable parameters described in chapter 6. X4-X8 use a plug for the connection: PE may be collected of pin 2 of the connector in order to earth the lamp housing.
  • Page 21 Installation page 17 Laying in cable gasket: The shield clamp is provided for the shield of the lamp feeder cable. For this cable the cable strap is not necessary. The lamp feeder cable between the switch cabinet and lamp assembly must be laid in a protected way.

  • Page 22: Overview Of Control And Bus Connections

    Installation page 18 3.2.10 Overview of control and bus connections The control cables are connected by means of the plug connections available as accessories. All control circuits must be earthed upon installation. The connector positions are shown in Fig. 12 or Fig. 13 and will be explained in the following tables.

  • Page 23: X1 / X2: Bus Connections

    Installation page 19 3.2.11 X1 / X2: BUS connections  To ensure secure data transmission the use of a BUS-specific cable is recommended. Connector pin assignment: 390 Ω 220 Ω 390 Ω Fig. 14: BUS-termination The shield has to be put on Pin 1 = BUS GND. Insulate with shrunk-on sleeve. The contacts of X1 and X2 are internally connected.

  • Page 24: X3: Bus T-Coupler

    Installation page 20 3.2.12 X3: BUS T-coupler Connector pin assignment: The shield has to be put on Pin 1 = BUS GND. Insulate with shrunk-on sleeve. Pin assignment X3: Designation Number Description technical BUS GND X3.1 GND insulated for BUS Shield connection BUS BUS A X3.2...

  • Page 25: X805 And X806: Control Cables

    Installation page 21 3.2.13 X805 and X806: Control cables Fig. 16 on page 24 shows the interconnection of X805 and X806. Comments on the wiring are given in the following tables. X806: Connector pin assignment: Connection torque: min. 0.22 Nm max.
  • Page 26 Installation page 22 X805: Connector pin assignment: Connection torque: min. 0.22 Nm max. 0.25 Nm PIN-assignment X805: Designation Number Description technical Interconnection X805.1 Continuous contact, connected max. 1A, 24V to X806.1 Safety NC 1 X805.2 Feedback contact 1 safety relay Normally closed contact 24V / 1A Safety NC 2 X805.3...

  • Page 27: X808/X300: Service Interface

    Installation page 23 NB: X805.8 to X805.11: the contacts which are normally open (cf. Fig. 16) will be closed as soon as the corresponding bit is set in Register [Lamp Control] of the BUS output-data (cf. paragraph 3.4). Bit 6 closes UV Select, Bit 7 closes UV Ready. Use if required, not essential for operating the ELC.
  • Page 28 Installation page 24 Fig. 16: Circuit diagram of the control connectors X805 and X806 ELC X-Series-V1.5-06.18-GB subject to technical alterations...

  • Page 29: Comments On The Safety Functions Of The Elc

    Installation page 25 3.3 Comments on the safety functions of the ELC In addition to the safety functions included in all previous ELC-types such as earth fault detection, temperature limit, safe operation in both short-circuit and open circuit at the lamp output, the ELC X-Series includes an additional function in the form of the definite lamp shutdown.

  • Page 30: Configuration

    Installation page 26 3.4 Configuration Communication between ELC and installation control is carried out via PROFIBUS DPV0 or MODBUS RTU. The ELC represents a non-modular DPV0-Slave, the installation control functions as the Master. For configuration, control and monitoring of the ELC 16 input registers (Master receiving data from ELC) were implemented, as well as 6 output registers (Master sending data to ELC).
  • Page 31 Installation page 27 → FIELDBUS-output-data (Master ELC) Modbus 0x100 0x101 0x102 Address Byte-Nr. Name [Power [Installed [Lamp [Special Lamp Control] Function] Value] Power] Additional communication parameters for MODBUS: The supported function codes are “Write Single Register” (0x06), “Write Multiple Register” (0x10) and “Read Holding Register”...

  • Page 32: Setting Up The Bus Address

    Installation page 28 3.4.1 Setting up the BUS address To set up the address the display and the pertaining SET button are used. The address space extends from 01hex to 7Dhex (corresponding to 1 to 125). Each address may be used only once per installation.

  • Page 33: Modbus

    Installation page 29 3.4.1.2 MODBUS To increment the address, the SET-button is used: Hold > 5sec If the SET-button is pressed longer than 5 seconds, the menu item to choose the bus connection type will be entered. Profibus To change the bus connection type press the SET- Press <...

  • Page 34: Checking The Bus Connection And Error Indication

    Installation page 30 3.4.2 Checking the BUS connection and error indication The display may be used to check the successful connection of ELC and Master and furthermore the existence of an error (ELC not ready for operation). It is also possible to read out error messages within the [Error Register] see paragraph 5.3.1 (detailed explanations may be found there).

  • Page 35: Setting Lamp Power Via Bus

    Installation page 31 3.4.3 Setting lamp power via BUS → BUS-output-data (Master ELC) Byte- Name [Power [Installed [Lamp [Reserved] Lamp Control] Value] Power] The set value for lamp power has to be written into the register [Power Set Value]. The ELC’s output power is defined by the control characteristic of Fig.
  • Page 36 Installation page 32 → BUS-output-data (Master ELC) Byte- Name [Power [Installed [Lamp [Reserved] Lamp Control] Value] Power] To limit the maximum output power, use the register [Installed Lamp Power] (see Fig. 19). This function is appropriate if the nominal power of the lamp is lower than the nominal power of the ELC.

  • Page 37: Extended Temperature And Power Range

    Installation page 33 3.4.4 Extended temperature and power range The ambient temperature range for standard operation is T_A = 5°C to 45°C. At a temperature of 47°C the lamp is switched off automatically. → BUS-output-data (Master ELC) Byte- Name [Power [Installed [Lamp [Reserved]...
  • Page 38 Installation page 34 Fig. 20: Mains voltage and temperature dependant power reduction (exemplarily for X6 and X8) Mains voltage temperature dependant power reduction (exemplarily for X12 and X16) Mains voltage temperature dependant power reduction (exemplarily for X24 and X36) ELC X-Series-V1.5-06.18-GB subject to technical alterations...

  • Page 39: To Read Out Elc Serial Number And Software Version

    Installation page 35 3.4.5 To read out ELC serial number and software version These data may be accessed via display or BUS and may be of interest e.g. for service and in case of a defect. 1. Display ELC ready Bus connected Shortly press the SET-button to reach the next menu Press <...

  • Page 40: Operation Of The Elc

    Operation of the ELC page 36 4 Operation of the ELC 4.1 Initial operation The operative parameters of the ELC, such as the scope of the trigger pulse when switching  on the lamp, are set by the manufacturer. You must always ensure that the correct lamp type is used (see chapter 6) and that all ...

  • Page 41: Switching On The Lamp

    Operation of the ELC page 37 4.4 Switching on the lamp → BUS-output-data (Master ELC) Byte- Name [Power [Installed [Lamp [Reserved] Lamp Control] Value] Power] ↓ Name Extended Clear Start Ready Select Range Error Lamp Before starting the lamp it is necessary to write the desired lamp power into the register ...
  • Page 42 Operation of the ELC page 38 1. Display ELC ready Bus connected Shortly press the SET-button to get the lamp Press < 5sec operation data. Lamp operation data on display: PLamp: 5200 W [Actual Power]: actual power in Watts  PSet: 5200 W ...

  • Page 43: Dimming Operation

    Operation of the ELC page 39 4.5 Dimming operation After having reached nominal operation the desired lamp power can be infinitely adjusted within the dimming range given in chapter 6.  Enter the desired power in Watts in register [Power Set Value]. ...

  • Page 44: Monitoring, Warning, Error, Repair

    Monitoring, warning, error, repair page 40 5 Monitoring, warning, error, repair 5.1 Mains voltage monitoring The mains voltage (L1, L2 of connector X100) is monitored during lamp operation.  In case of continuous input undervoltage the lamp power is reduced by the ELC in order to prevent an overcurrent on the input side (see output power reduction in chapter 6).
  • Page 45 Monitoring, warning, error, repair page 41 Bit 0: The {Lamp Voltage Low}-bit is set if the lamp voltage is lower than the threshold voltage given in chapter 6. A possible reason is a strong lamp cooling especially in dimming operation. This could cause a long run up time to regain the nominal power.

  • Page 46: Error

    Monitoring, warning, error, repair page 42 5.3 Error 5.3.1 Error messages Effects of an error: The lamp will be immediately shut down,   In case of an error the display is blinking and the error is shown in clear text. In case of several error messages they will be displayed on a rolling basis.
  • Page 47 Monitoring, warning, error, repair page 43 Display message Bit set in Description Detection Corrective action error {Bit-name in error register} only in register lamp operation {DC-Link-Undervoltage}: Check fuses  internal dc link voltage is low Bit 0 DC Link due to low mains voltage, blown ...
  • Page 48 Monitoring, warning, error, repair page 44 Display message Bit set in Description Detection Corrective action Error {Bit-name in error register} only in register lamp operation {Measurement}: problems with Bit 9 Check for short in lamp Measurement the internal measurement circuit. (0x0200) circuits.

  • Page 49: Earthfault Indication Via Special Function Register In Modbus Control

    Monitoring, warning, error, repair page 45 Display message Bit set in Description Detection Corrective action Error {Bit-name in error register} only in register lamp operation PLamp: xxxxx Indication of actual power in Watts PSet: yyyyy Indication of required power in Watts Replace a blown fuse only by fuses of types authorised by the manufacturer (see chapter 6).

  • Page 50: Resetting The Error Register

    Monitoring, warning, error, repair page 46 5.3.4 Resetting the error register Each error has to be acknowledged by setting the {Clear Error} bit in register [Lamp Control] to “1”. First of all set the {Start Lamp} bit in register [Lamp Control] to 0. Then only the transgression of the {Clear Error} bit from “0”...
  • Page 51 Monitoring, warning, error, repair page 47 Procedure:  Disconnect the ELC from the mains. Verify whether the ELC is de-energised and secured from unintentional restart.  Remove front hood. Disconnect all incoming cable plugs (see chapter 3.2) from the board. ...
  • Page 52 Monitoring, warning, error, repair page 48 Pull out main board with respect to the following rules:  Attention with ELC X16-36: At first pull out the board for less than 10cm. Carefully pull the marked connectors through the slot: Then extract the whole board. Non-observance can lead to damage to the cables in the form of cable breaks.

  • Page 53: Maintenance

    After removal of the front hood the cooler is accessible: 5.5 Repair ELC Only the manufacturer is permitted to repair the ELC. In case of failure please contact the following address: eta plus electronic gmbh Lauterstraße 29 D-72622 Nürtingen Tel: +49 7022 / 6002-80 Fax: +49 7022 / 65854 e-mail: Info@eta-uv.de...

  • Page 54: Disposal Of Elc

    Monitoring, warning, error, repair page 50 5.6 Disposal of ELC Dispose of the ELC according to the national law in force. ELC of type X providing powers of 12kW or more contain a lithium battery. Mind the following hints at disposal of the ballast: Lithium batteries are save when adequately ...

  • Page 55: Technical Data

    Technical Data page 51 6 Technical Data 6.1 ELC X4 Output power characteristics Type ELC X4-40 Power factor typ. > 97% Power efficiency typ. 94% Nominal power range 800 W – 4000 W Electrical characteristics Type ELC X4-40 Nominal supply voltage 400 V - 480 V Operating supply voltage range 400 V - 480 V...
  • Page 56 Technical Data page 52 Lamp characteristics Type ELC X4-40 Nominal lamp power 4 kW Nominal lamp voltage 400 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 300 V voltage low} warning bit Ignition voltage / period approx.
  • Page 57 Technical Data page 53 Mechanical characteristics Type ELC X4-40 Dimensions 125 x 470 (±1mm) x 260 mm (approx. H x W x D) 11 kg Weight (approx.) vertical or horizontal as described in 3.1 Installation position Control characteristics Type ELC X4-40 2.2 A max.
  • Page 58 Technical Data page 54 Certification Type ELC X4-40 IP 54 Protection of front fan IP x4 Protection Note: protection is only guaranteed if cables of the given diameters are used (see paragraph 3.2.2) EN 55011 EN 61000-3-3 EN 61000-6-2 Safety EN 50178 E349667 Marine approval...

  • Page 59: Elc X6, X6B, X6I

    Technical Data page 55 6.2 ELC X6, X6B, X6i Output power characteristics Type ELC X6-60 ELC X6B-60 ELC X6i-60 Power factor typ. > 97% Power efficiency typ. 94% Nominal power range 840 W – 6050 W Electrical characteristics Type ELC X6-60...
  • Page 60 Technical Data page 56 Lamp characteristics Type ELC X6-60 ELC X6B-60 ELC X6i-60 Nominal lamp power 6 kW Nominal lamp voltage 600 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 450 V voltage low} warning bit...
  • Page 61 Technical Data page 57 Mechanical characteristics Type ELC X6-60 ELC X6B-60 ELC X6i-60 Dimensions 125 x 470 (±1mm) x 320 mm (approx. H x W x D) Weight (approx.) 14 kg 15 kg 14 kg Installation position vertical or horizontal as described in 3.1...
  • Page 62 Technical Data page 58 Certification Type ELC X6-60 ELC X6B-60 ELC X6i-60 IP 54 Protection of front fan IP x4 Protection Note: protection is only guaranteed if cables of the given diameters are used (see paragraph 3.2.2) EN 55011 EN 61000-3-3...

  • Page 63: Elc X8, X8B, X8 Extended Range, X8I, X8F

    Technical Data page 59 6.3 ELC X8, X8B, X8 extended range, X8i, X8F Output power characteristics ELC X8-80 ELC X8-80 Type ELC X8B-80 ELC X8i-80 ELC X8F-80 extended range Power factor typ. > 97% Power efficiency typ. 94% Nominal power range 1600 W –...
  • Page 64 Technical Data page 60 Lamp characteristics ELC X8-80 ELC X8-80 Type ELC X8B-80 ELC X8i-80 ELC X8F-80 extended range Nominal lamp power 8 kW Nominal lamp voltage 800 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 600 V voltage low} warning bit Ignition voltage / period...
  • Page 65 Technical Data page 61 Mechanical characteristics ELC X8-80 ELC X8-80 Type ELC X8B-80 ELC X8i-80 ELC X8F-80 extended range Dimensions 125 x 470 (±1mm) x 420 mm (approx. H x W x D) Weight (approx.) 18.5 kg 19.5 kg 18.5 kg 18.5 kg Installation position vertical or horizontal as described in 3.1...
  • Page 66 Technical Data page 62 Certification ELC X8-80 ELC X8-80 Type ELC X8B-80 ELC X8i-80 ELC X8F-80 extended range IP 54 Protection of front fan IP x4 Protection Note: protection is only guaranteed if cables of the given diameters are used (see paragraph 3.2.2) EN 55011 EN 61000-3-3...

  • Page 67: Elc X12, X12B, X12I, X12F

    Technical Data page 63 6.4 ELC X12, X12B, X12i, X12F Output power characteristics ELC X12-110 Type ELC X12B-110 ELC X12i-110 ELC X12F-110 Power factor typ. > 97% Power efficiency typ. > 94% Nominal power range 2400 W – 12000 W Electrical characteristics ELC X12-110 Type...
  • Page 68 Technical Data page 64 Lamp characteristics ELC X12-110 Type ELC X12B-110 ELC X12i-110 ELC X12F-110 Nominal lamp power 12 kW Nominal lamp voltage 1100 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 800 V voltage low} warning bit Ignition voltage / period approx.
  • Page 69 Technical Data page 65 Mechanical characteristics ELC X12-110 Type ELC X12B-110 ELC X12i-110 ELC X12F-110 Dimensions 125 x 470 (±1mm) x 420 mm (approx. H x W x D) Weight (approx.) 20.5 kg 21.1 kg 20.5 kg Installation position horizontal as described in 3.1 Control characteristics ELC X12-110 Type...
  • Page 70 Technical Data page 66 Certification ELC X12-110 Type ELC X12B-110 ELC X12i-110 ELC X12F-110 IP 54 Protection of front fan IP x4 Protection Note: protection is only guaranteed if cables of the given diameters are used (see paragraph 3.2.5) EN 55011 EN 61000-3-3 EN 61000-6-2 Safety...

  • Page 71: Elc X16, X16B, X16I, X16F

    Technical Data page 67 6.5 ELC X16, X16B, X16i, X16F Output power characteristics ELC X16-140 Type ELC X16B-140 ELC X16i-140 ELC X16F-140 typ. > 97% Power factor typ. > 94% Power efficiency Nominal power range 3200 W – 16000 W Electrical characteristics ELC X16-140 Type...
  • Page 72 Technical Data page 68 Lamp characteristics ELC X16-140 Type ELC X16B-140 ELC X16i-140 ELC X16F-140 Nominal lamp power 16 kW Nominal lamp voltage 1400 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 700 V voltage low} warning bit Ignition voltage / period approx.
  • Page 73 Technical Data page 69 Mechanical characteristics ELC X16-140 Type ELC X16B-140 ELC X16i-140 ELC X16F-140 Dimensions 250 x 470 (±1mm) x 420 mm (approx. H x W x D) Weight (approx.) 37 kg 38.2 kg 37 kg Installation position horizontal as described in 3.1 Control characteristics ELC X16-140 Type...
  • Page 74 Technical Data page 70 Certification ELC X16-140 Type ELC X16B-140 ELC X16i-140 ELC X16F-140 IP 54 Protection of front fan IP x4 Protection Note: protection is only guaranteed if cables of the given diameters are used (see paragraph 3.2.5) EN 55011 EN 61000-3-3 EN 61000-6-2 Safety...

  • Page 75: Elc X24, X24B, X24I, X24F

    Technical Data page 71 6.6 ELC X24, X24B, X24i, X24F Output power characteristics ELC X24-210 Type ELC X24B-210 ELC X24i-210 ELC X24F-210 typ. > 97% Power factor typ. > 94% Power efficiency Nominal power range 4800 W – 24000 W Electrical characteristics ELC X24-210 Type...
  • Page 76 Technical Data page 72 Lamp characteristics ELC X24-210 Type ELC X24B-210 ELC X24i-210 ELC X24F-210 Nominal lamp power 24 kW Nominal lamp voltage 2100 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 1050 V voltage low} warning bit Ignition voltage / period approx.
  • Page 77 Technical Data page 73 Control characteristics ELC X24-210 Type ELC X24B-210 ELC X24i-210 ELC X24F-210 4.4 A max. for ELC control circuitry 5.4 A max. for ELC control circuitry Current requirement of 24V- supply (X805.5) output currents of X806 Pins 5 + 6 have to be added PROFIBUS: 500 kBit Baud rate MODBUS: Baud rate 19200, 8 Databits, even...

  • Page 78: Elc X36, X36B, X36F

    Technical Data page 74 6.7 ELC X36, X36B, X36F Output power characteristics ELC X36-300 Type ELC X36B-300 ELC X36F-300 typ. > 97% Power factor typ. > 94% Power efficiency Nominal power range 7200 W – 36000 W Electrical characteristics ELC X36-300 Type ELC X36B-300 ELC X36F-300...
  • Page 79 Technical Data page 75 Lamp characteristics ELC X36-300 Type ELC X36B-300 ELC X36F-300 Nominal lamp power 36 kW Nominal lamp voltage 3000 V Tolerance lamp voltage nominal voltage ± 5 % Threshold voltage of {lamp 1400 V voltage low} warning bit Ignition voltage / period approx.
  • Page 80 Technical Data page 76 Control characteristics ELC X36-300 Type ELC X36B-300 ELC X36F-300 6.6 A max. for ELC control circuitry Current requirement of 24 V- Output currents of X806 Pins 5 + 6 have to be supply (X805.5) added PROFIBUS: 500 kBit Baud rate MODBUS: Baud rate 19200, 8 Databits, even parity, 1 Start/Stop Bit...
