Honda BF15D Technical Information

Honda Technical Information
M : BF15D / BF20D
ODEL
S : F L
UBJECT UEL EAK
S :
YMPTOM
Fuel may leak slightly out of the outboard motor under
the following conditions:
1. Engine is stopped after widely open throttle
operation.
2. The outboard motor is fully tilted up and tipped
to the right-turn position.
3. It is kept in that position for 1.5~8 minutes.
C :
AUSE
Due to vaporised Gasoline in the fuel pump, the
internal pressure of the fuel pump rose, allowing
liquid gasoline in the fuel chamber flow into the
carburettor. And the gasoline that flowed into the
carburettor leaked out of the carburettor through the
main nozzle.
C :
OUNTERMEASURE
1. The installation direction of the fuel pump has been
changed 180 degrees to prevent fuel from flowing
out even if it vaporizes.
2. The installation direction of the fuel chamber has
been changed not to drain liquid gasoline to the
carburettor, but to let vapour gasoline flow into the
chamber.
3. As the installation direction of the two above
components was changed, the length and shape of
the fuel hoses have been changed, too.
A
PPLICATION ON
M S
ODEL ERIAL
BF15D3 BALJ
BF20D3 BAMJ
W A
ARRANTY PPLICATION
M C P :
AIN AUSAL ART
W D C
ARRANTY EFECT ODE
QIS N :
UMBER
D N :
EALER OTICE
N :
OTES
101, 120, 130, 23D, 231, 235, 237, 240, 25F, 26E, 267,
272, 28R, 350, 374, 41C, 430, 460, 504, 507, 522, 550,
741, 776
W F T
HEN IN ULLY ILT
P L
RODUCTION INE
P S N .
REFIX ERIAL O
1002828
1002875
:
Ordinary
16700-ZW9/16790-ZY1
:
060
AP2002090611151
Bulletin
U P
P OSITION
M T
ARKET REATMENT
If the symptom mentioned on the left is confirmed,
replace the part with the countermeasure part listed
below.
I
LLUSTRATION
After C/M
P N
ARTS
16861-ZY1-010
17702-ZY1-010
FRT 17701-ZY1-010
0.5 90503-ZV4-000
0.5 95005-1100130M
90679-SG9-E01
(91303-ZW9-000)
P A
ARTS VAILABILITY
Will be available in the middle of November.
P T
ARTS REATMENT
Necessary
Orally Not necessary
Issued by
T. Warabi
Power Product Service Division
D
ISTRIBUTION
P
ROVISIONAL
HTI N : TI-62002082
UMBER
D I : 2002/10/24
ATE OF SSUE
D R :
ATE OF EVISION
Y R
OUR EFERENCE
N/A
:
S P I
ERVICE ARTS NFORMATION
P
UMBER ARTS
Fuel tube B
Fuel tube C
Fuel tube D
6mm washer
11x20 tube (Cutting to use)
Tie wrap
