INSTRUCTION MANUAL FOR PURE SINE WAVE INVERTER
NOTE: This is a general manual.
Safety Guidelines (Please read through this manual before installing)
WARNING:
· Risk of electrical shock and energy hazard. All failures should be examined by a qualified technician. Please do
not remove the case of the inverter yourself.
· Do not install the inverter in places with high moisture or near water. (warranty is void if liquid damage occurs)
· Do not install the inverter in area with high ambient temperature, in direct sun or near a flame source.
· Only connect batteries with the same size and type in one battery bank. Using batteries from different
manufacturers or different capacity is strictly prohibited.
· Never allow a spark or flame in the vicinity of the batteries as this may ignite explosive gases when opperating.
· Make sure the air flow from the fan is not obstructed at both sides (front and back) of the inverter. Allow at least
15cm of space from both sides.
· Do not place any objects ontop of the inverter
WARNING:
Batteries may have a performance issue over time. It is recommended to perform regular checks and maintanance
(e.g. every year). If the batteries have failed or are no longer performing, the batteries should be changed by a
professional technician, otherwise, the failed batteries may cause a fire or other hazard.
Product Introduction
The TS inverters (Or Trade Series) are pure sine wave inverters that are CPU controled. They convert DC power
into AC power. They do not produce power, but only convert.
They are durable and can run for long periods at a time, however they are not designed for continuous use.
Peak power is double the continuous power output for start up.
They are designed for most loads. However, they are not recommended for induction cookers.
Features
·Pure sine wave output（THD<3%）
·High efficiency up to 92%
·Optional remote purchased sepperately
·LED indicator and buzzer
·Can be used for most electronic products with AC input.
·Battery low alarm and indicator
·Compliance to CE / FCC / LVD / RoHS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Voltech TS-300 Series
Summary of Contents for Voltech TS-300 Series
- Page 1 INSTRUCTION MANUAL FOR PURE SINE WAVE INVERTER NOTE: This is a general manual. Safety Guidelines (Please read through this manual before installing) WARNING: · Risk of electrical shock and energy hazard. All failures should be examined by a qualified technician. Please do not remove the case of the inverter yourself.
- Page 2 Main Specifications Output Waveform Pure Sine Wave (THD<3%) Model TS-300-XX TS-600-XX TS-1000-XXTS-1500-XXTS-2000-XX TS-2500-XX TS-3000-XX Continuous Power 300W 600W 1000W 1500W 2000W 2500W 3000W Peak Power 600W 1200W 2000W 3000W 4000W 5000W 6000W ＜ 0.5A ＜ 0.5A ＜ 0.7A ＜ 0.7A ＜...
- Page 3 Fault Indication LED and Buzzer Condition Buzzer sounds once and LED This indicates normal operation. This occurs when the unit starts up. flashes green once Buzzer sounds 3 times (LED Low voltage protection: These units have three stages of UVP; flashes red 3 times) 1) WARNING: Single slow warning beep &...
- Page 4 Suggested Battery Bank Capacity A battery bank that is of larger capacity than needed should be installed. (to meet the discharge time and load requirements) The time that a load can run for is NOT determined by the inverter, rather than by battery capacity. Note: this is a guide only.
- Page 5 Installation Diagram Inverter Components Please note the following labels are the same for all units. FRONT a. ON/OFF switch: This switch controls ON/OFF operation of the unit. b. AC OUT: Australian socket c. Ventilation outlet: to cool the inverter. Do not obstruct d.
