Page 1
12V or 24V Models (Input voltage range: -15% ~ +25%) Output voltage regulation: ±10% Output waveform: Pure Sine Wave Frequency: 50Hz±1% CE and RoHS Approved 12 months warranty Thank you for purchasing the Voltech Pure Sine Wave Inverter. Carefully read, understand and comply with all instructions before use.
Table of contents 1. Introduction………………………………………………..……3 What is an inverter?……………………………..….…..3 Pure Sine Wave Inverter……………………….……….3 2. Main Components………………………………………….…...3-6 Front panel………………………………………….…..3-4 Rear panel………………………………………..….…..5 3. How to Use Inverter….…………………………………….……6 Load consideration………………………..………….…6 Configuring the Battery Bank …………………………7 Battery wiring examples………………………..………7-8 Placement of the inverter………………………..……..8 Mounting position of the inverter………………...……9 Connections……...…………………………………..….9 4.
INTRODUCTION 1.1 What is an Inverter? Power inverter is an electronic device that converts DC (Direct Current) battery power to standard AC (Alternating Current) power. DC is the power that is stored by a battery while AC is the standard power needed to run electrical equipment. A Power Inverter can be used in places and situations where AC power is not available.
Page 4
C. AC Output Receptacle: Australia (10Amp) D. Vent Outlet. Allows hot air pushed from the rear cooling fan to exit. Therefore it MUST be kept clear whenever the power inverter is to be used. E. Chassis Ground (some models) Properly grounds the Inverter to vehicle grounding system or to earth ground. G.
Rear Panel The rear panel view shows the inverter’s Cooling fan, DC Battery Terminals, Fuses, Chassis Ground (some models). A. Temperature and Load controlled Multi-Speed Cooling Fan Quiet, efficient fan prolongs equipment service life. 1. Load <40% or inner temperature less than 30 ℃, = fan(s) don’t run. 2.
C. Fuse Fuses for DC Input have been fitted to the rear panel. So as to be easily accessible in order to facilitate checking & replacing if required. Depending on the installation this maybe possible without removing the inverter. 3. HOW TO USE INVERTER 3.1 Load consideration When an appliance with a motor starts, it requires a momentary surge of power.
3.2 Configuring the Battery Bank To determine the approx’ minimum battery amp-hour rating that you will need to operate appliances from the inverter and any DC appliances powered by the battery bank, follow these steps: 1. List the maximum continuous wattage that the inverter has to supply. 2.
3.4 Placement of inverter The location where to install inverter must be: A. DRY: Do not allow water to drip or splash onto it. B. COOL: Ambient air temperature should be between 0º C and 40º C - ideally between 15º C and 25º.Do not place the inverter on or near a heating vent or any piece of equipment which is generating heat above room temperature.
3.5 Mounting position of the inverter The inverter may be mounted on a horizontal or vertical service. Away from heat sensitive materials & flammable items. (Follow All Safety Instructions). 3.6 Connections Follow the connection sequence described below. Step 1: Ensure that the ON/OFF switch on the Inverter is in the OFF position. If the power source is a DC power supply, switch it OFF as well.
12. Disconnect all AC and DC connections before working on any circuits associated with the inverter. Turning the ON/OFF switch on the inverter to off position may not entirely remove dangerous voltage. 13. Keep the Inverter,Batteries & all cabling away from children. 5.
6. TROUBLESHOOTING TV Interference You can sometimes get interference on TV & Radio receivers. This may be improved through use of a filter(s) but most problems occur because of Weak Signal to the TV. On some occasions when there is interference on every station, you can try the following: Place the inverter farther from the TV and TV antenna and cable.
Page 12
1.Check that the battery is fully charged. Recharge, if low Voltage at the DC input 2. Check that the battery cables Buzzer sounds 3 times terminals reads below; are thick enough to carry the and Red LED blinks 3 10.2±0.2VDC(12V version) required current over...
7. SPECIFICATIONS – (KS models are not available) Model Item KS500P KS600P KS2000P TS-300-12/24 TS-800-12/24 TS-1500-12/24 Rated Power 300W 500W 600W 800W 1500W 2000W Surge Power 120%<Load<150% Rated power for 10s,150%<Load<200% Rated power for 2s 100V/110V/115V/120Vac or 220V/230V/240Vac AC Voltage AC output regulation: 10% Frequency:50Hz±1%...
Dimension((L*W*H)cm 44.5*22*9 36*22*15 41*22*15 36*22*15 36*22*15 PCS/CTN Packing KGS/CTN 10.5 11.5 14.5 MEAS(L*W*H)cm 50*32*36 56*35*26 56*35*26 67*34*24 67*34*24 AC Out Receptacle USA, UK, Germany, France, Australia, Brazil, Italy, South Africa, etc. Cooling Temperature and Load Controlled Operating Temperature -15 ° C to 40° C Environment Storage Temperature -40 to 85°C...
Appendix I: Remote Control Remote Control Switch ● Power ON/OFF Switch Power ON/OFF switch is to turn the inverter on or off. ● Battery Capacity/Load Voltage indicator Load: Slow flash, 1time per second. Show the approximate connected equipment load level. Five Levels---20%,40%,60%,80%,100%.
Appendix II: Recommendations For correct operation, the battery voltage should be between 0.9xVnom and 1.29xVnom where Vnom is 12V, 24V or 48V depending on model, and must be able to supply sufficient current to your inverter. The following table displays the recommended things(battery cable, Fuse, Battery Capacity) per inverter type : Inverter type Input Voltage...
