- Page 1 OWNER’S MANUAL CQ SERIES SEQUENCED POWER CONTROL COVERS MODELS CQ-1515 , CQ-1520 , CQ-1 , CQ-2200 CQ-3000 and CQ-PD1-4 FEBRUARY 2015 File: 3176209DEN-001 Standard: UL508...
- Page 2 Since individual applications can be subject to extreme variation Juice Goose makes no representation or guarantee as to the suitability of a CQ product for any generally described application.
-
Page 3: Safety Precautions
15 amps, 20 amps or 30 amps depending on the CQ model being considered. All CQ Series products can be remote activated. Several CQ devices can be connected to form a power sequencing system that includes multiple circuits in multiple locations. -
Page 4: Detail Specifications
DETAIL SPECIFICATIONS DIMENSIONS (H x W x D inches) CQ 1515 & CQ 1520……..………………….……………..…..………...1.72 x 19.00 x 7.00 CQ 1(Including 3 Gang Utility Box).............4.50 x 6.50 x 3.75 CQ 2200 ....……………….......……………………………5.50 x 6.40 x 3.75 CQ 3000.....................9.00 x 6.00 x 4.00 CQ PD1-4.…..……………………………………………..………………...32.00 x 3.50 x 2.00 WEIGHT (lbs) CQ 1515 &... -
Page 5: Installation
CQ device in case alternate power connection is necessary. These two CQ Series models have front panel and a back box construction that are held together with seven screws. To begin installation, remove the screws that hold these two pieces together. - Page 6 The interconnecting CQ Series devices requires eight wire, RJ-45 cable. While this is the same component used to assemble CAT5 and CAT6 ca- bles, orientation of the connectors on the CQ Series cable is slightly differ- ent than for the CAT data networking cable. Therefore, standard CAT5 or CAT6 cables will not work with CQ Series devices.
-
Page 7: Remote Switch Connection
In the illustration below, connecting a single pole, double throw (SPDT) switch to the signal input line of a CQ Series device will control the se- quence up and down activity. Closing Pin 3 to Pin 7 will begin a sequence UP. -
Page 8: Pin Assignments
OPERATION These versatile CQ devices can be controlled by way of either another CQ device, a remote latching contact closure, a Juice Goose RC5 accessory unit or the switch on the CQ device itself (except the CQ 1). CQ DEVICES - Any CQ device can operate in concert with others. Each... - Page 9 MONITORING Each CQ Series device has a number of LEDs on the chassis to allow real time monitoring of the device’s operation. On all CQ models, one LED indicates the processor is running the CQ control program.
- Page 10 IN CASE OF MALFUNCTION The Juice Goose CQ Series of products are ruggedly constructed and contain quality components. There are no user serviceable parts inside a CQ device. Unauthorized service will void all existing warranties and may result in equipment damage and personal injury.
- Page 11 RACK MOUNTED POWER DISTRIBUTION - Nineteen inch horizontal power distribution with several optional levels of AC power protection AC LINE FILTRATION - The Juice Goose RX Series Hybrid Filter tech- nology provides very high levels of protection against damaging power surges and high frequency interference on hot, neutral and ground..
- Page 12 Since 1983...
