GB/US . . . . LP8 Lifting platform
Vers . 4 .00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LP8 and is the answer not in the manual?

Questions and answers

Related Manuals for Stepless LP8

Summary of Contents for Stepless LP8

  • Page 1 GB/US . . . . LP8 Lifting platform Vers . 4 .00...

  • Page 2: Table Of Contents

    LP8 Lifting platform Item no .: 3091xx 1 .00 . . . . . . . . Purpose and use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 1.01 .

  • Page 3: Purpose And Use

    Purpose of the manual The manual describes the standard model with a lifting height from 0-3 metres. The LP8 is a vertical lifting platform designed for permanent installation indoors and outdoors. The lifting platform may be used in temperatures from -40° to +50°C.

  • Page 4: Important/Warnings

    Important/warnings • Read the instructions carefully before using the product. • The LP8 must be assembled by the Guldmann Service Team or by an engineer approved by Guldmann. • The accompanying safety bar must be used when the service engineer moves around beneath the lifting platform.

  • Page 5: Components

    1 .04 Components 1 Lower door 2 Upper door 3 Access ramp 4 Control panel 5 Emergency lowering valve behind cover (adjusting screw for emergency lowering) 6 Production sign 7 Tower 8 Lift basket 9 Base frame 10 Exit ramp 11 Safety cut-out board 12 Motor housing...

  • Page 6: Description Of Functions

    2 .00 Description of functions 2 .01 Control panel The lifting platform is operated by means of a control panel. The lifting platform is logical and unprob- lematic to operate and use, even with no prior knowledge. 1. Raise 2. Emergency stop 3.
  • Page 7 Emergency lowering device: (It is not possible to activate the emergency lowering device from the lift basket.) 1. Ensure that no one is situated below the platform, as the safety board does not work during emergency lowering. 2. Open the motor housing with the key. Open the hatch, and press and hold the red button until the platform reaches the lower level.

  • Page 8: Markings And Symbols On The Product

    Disabled label. Parking instructions PARKING. The lift basket must be parked in the lower position after use. Manufacturer’s sign Manufacturer’s sign with CE label Lifting Platform LP8 max 350 kg / 770 lbs V. Guldmann A/S Part no. 3091xx Graham Bells Vej 21-23A Serial no.

  • Page 9: Connections

    3 .00 Connections 3 .01 Electrical connections The lifting platform is delivered with a cable and plug connected to the lifting platform’s motor housing. This is only a temporary solution in order to be able to run the lift during assembly, until an authorised electrician connects the lift- ing platform permanently.

  • Page 10: Installation Of Accessories

    4 .00 Installation of accessories Heating cables: The lifting platform is delivered as standard without heating cables. In the base frame space has been made for a heating cable cassette. For outdoor assembly, it is recommended that heating cables are always built into the lifting platform’s base.
  • Page 11 Safety cut-out board . A safety cut-out board has been fitted under the lift basket, which means that the lifting platform stops if it comes into contact with anything. If an object appears below the lift basket and the lifting platform has stopped, the lifting platform must be taken slightly up in order to remove the object before the lifting platform can be operated normally again.

  • Page 12: Maintenance

    Heating cable . Lifting platforms installed outdoors are normally fitted with a heating cable of 220 Watt. This should be left on whenever there is a danger of frost. The following points must be adhered to: • There is a risk of getting jammed at the moving parts of the platform, for instance the automatic doors.
  • Page 13 Cleaning: The lifting platform can be cleaned with soap and water. NB: High-pressure washers and scourers cannot be used. Service inspection: The LP8 must be inspected in accordance with the national law and at least once a year. The platform must be inspected by a qualified technician or by Guldmann Service Team.

  • Page 14: Troubleshooting

    7 .00 Troubleshooting Fault Possible cause Solution None of the electrical functions The emergency stop button Turn all emergency stop but- works. has been pressed. tons to the right. The main power switch has Turn the switch on. been turned off. The fuse has blown.

  • Page 15: Technical Specifications

    8.00 Technical specifications Data The lifting platform’s net weight 650 kg Highest speed 0.08 m/s Average lifting speed 0.07 m/s Lifting height in mm 0–3000 Max. load, one person incl. wheelchair 350 kg Materials Aluminium and powder coated / electro- galvanized / hot-galvanized steel Noise level 65 dB(A)

  • Page 16: Usa And Countries Outside The Eu

    USA and countries outside the EU Users guide Before using the product, read the entire operation manual including warranty. WARRANTY Guldmann warrants its equipment is free from material defects under normal use, and will perform substantially in accordance with the specifications set forth in documentation provided with the equipment.
  • Page 20 V . Guldmann A/S Tlf. +45 8741 3100 +45 8741 3131 E-mail info@guldmann.com www.stepless.com...
