Denver DSB-4010 User Manual

Operating Introduction

a.
Place the Soundbar on a flat and solid surface. Alternatively, you can wall mount the Soundbar with the
screws provided. You can hear audio through the Soundbar using ONE of the following connections.
1.
Connect to your television using one of the connectors.
HDMI-ARC connector on the TV (using an HDMI cable)

 Optical output connector on the TV (using an optical cable)

Headphone jack (using the supplied audio cable with 3.5mm plug)
2. Connect to a Bluetooth enabled device.
3.
Connect to a USB drive (stick) loaded with music files
b. Illustration of the Soundbar connectors for different connections
EN
OPTICAL IN
LINE IN
DC 19V IN
Note: To hear TV audio through the Soundbar via Optical or HDMI-ARC connection,
make sure that the LINE IN jack on the Soundbar is not plugged in.
Sound Bar User Manual
EN
OPTICAL IN
LINE IN
DC 19V IN
