Maxim Integrated MAX4684 Series General Description Manual

Low-voltage, dual spdt analog switches in ucsp

Advertisement

Quick Links

19-1977; Rev 3; 2/03

General Description

The MAX4684/MAX4685 low on-resistance (R
voltage, dual single-pole/double-throw (SPDT) analog
switches operate from a single +1.8V to +5.5V supply.
The MAX4684 features a 0.5Ω (max) R
switch and a 0.8Ω (max) R
+2.7V supply. The MAX4685 features a 0.8Ω max on-
resistance for both NO and NC switches at a +2.7V
supply.
Both parts feature break-before-make switching action
(2ns) with t
= 50ns and t
ON
tal logic inputs are 1.8V logic-compatible with a +2.7V to
+3.3V supply.
The MAX4684/MAX4685 are packaged in the chipscale
package (UCSP)™, significantly reducing the required
PC board area. The chip occupies only a 2.0mm
1.50mm area. The 4
spaced with a 0.5mm bump pitch.
________________________Applications
Speaker Headset Switching
MP3 Players
Power Routing
Battery-Operated Equipment
Relay Replacement
Audio and Video Signal Routing
Communications Circuits
PCMCIA Cards
Cellular Phones
Modems
UCSP is a trademark of Maxim Integrated Products, Inc.
Rail-to-Rail is a registered trademark of Nippon Motorola, Ltd.
TOP VIEW
Continued at end of data sheet.
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim's website at www.maxim-ic.com.
0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT
ON
for its NC
ON
for its NO switch at a
ON
= 40ns at +3V. The digi-
OFF
3 array of solder bumps are
Pin Configurations/Functional Diagrams/Truth Table
MAX4684/MAX4685
GND
C1
B1
A1
NC1
NC2
C2
A2
IN1
IN2
COM1
C3
A3
COM2
NO1
NO2
C4
B4
A4
V+
UCSP
Analog Switches in UCSP
12-Bump, 0.5mm-Pitch UCSP
), low-
NC Switch R
0.5Ω max (+2.7V Supply) (MAX4684)
0.8Ω max (+2.7V Supply) (MAX4685)
NO Switch R
0.8Ω max (+2.7V Supply)
R
Match Between Channels
ON
0.06Ω (max)
R
Flatness Over Signal Range
ON
0.15Ω (max)
+1.8V to +5.5V Single-Supply Operation
Rail-to-Rail
1.8V Logic Compatibility
Low Crosstalk: -68dB (100kHz)
High Off-Isolation: -64dB (100kHz)
THD: 0.03%
50nA (max) Supply Current
Low Leakage Currents
1nA (max) at T
PART
MAX4684EBC
MAX4684ETB
MAX4684EUB
MAX4685EBC
MAX4685ETB
MAX4685EUB
Note: Requires special solder temperature profile describing
the Absolute Maximum Ratings section.
*UCSP reliability is integrally linked to the user's assembly
methods, circuit board material, and environment. Refer to the
UCSP Reliability Notice in the UCSP Reliability section of this
data sheet for more information.
1
V+
NO1
2
MAX4684/MAX4685
3
COM1
IN_
NO_
NC_
IN1
4
0
OFF
ON
1
ON
OFF
NC1
5
SWITCHES SHOWN FOR LOGIC "0" INPUT
ON
ON
®
Signal Handling
= +25°C
A

Ordering Information

PIN/BUMP-
TEMP RANGE
PACKAGE
-40°C to +85°C
12 UCSP*
10 Thi n Q FN
-40°C to +85°C
( 3 3)
-40°C to +85°C
10 µMAX
-40°C to +85°C
12 UCSP*
10 Thi n Q FN
-40°C to +85°C
( 3 3)
-40°C to +85°C
10 µMAX
MAX4684/MAX4685
10
NO2
9
COM2
8
IN2
7
NC2
6
GND
µMAX
Features
TOP
MARK
AAF
AAG
AAG
AAH
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAX4684 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Maxim Integrated MAX4684 Series

  • Page 1: General Description

    Modems Note: Requires special solder temperature profile describing the Absolute Maximum Ratings section. UCSP is a trademark of Maxim Integrated Products, Inc. *UCSP reliability is integrally linked to the user’s assembly Rail-to-Rail is a registered trademark of Nippon Motorola, Ltd.
  • Page 2: Absolute Maximum Ratings

    0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP ABSOLUTE MAXIMUM RATINGS (All Voltages Referenced to GND) Continuous Power Dissipation (T = +70°C) V+, IN_..............-0.3V to +6V 12-Bump UCSP (derate 11.4mW/°C above +70°C) ...909mW COM_, NO_, NC_ (Note1) ......-0.3V to (V+ + 0.3V) 10-Pin µMAX (derate 5.6mW/°C above +70°C) ..444mW Continuous Current NO_, NC_, COM_ ......
  • Page 3 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP ELECTRICAL CHARACTERISTICS—+3V SUPPLY (continued) (V+ = +2.7V to +3.3V, V = +1.4V, V = +0.5V, T to T , unless otherwise noted. Typical values are at +3V and +25°C.) (Notes 3, 9, 10) UNITS PARAMETER...
  • Page 4: Typical Operating Characteristics

    0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Typical Operating Characteristics = +25°C, unless otherwise noted.) MAX4684 MAX4685 NC ON-RESISTANCE vs. COM VOLTAGE NC ON-RESISTANCE vs. COM VOLTAGE NO ON-RESISTANCE vs. COM VOLTAGE V+ = +1.8V V+ = +1.8V V+ = +1.8V V+ = +2.0V V+ = +2.0V...
  • Page 5 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Typical Operating Characteristics (continued) = +25°C, unless otherwise noted.) TURN-ON/TURN-0FF TIMES TURN-ON/TURN-0FF TIMES SUPPLY CURRENT vs. SUPPLY VOLTAGE vs. SUPPLY VOLTAGE vs. TEMPERATURE V+ = +3V TEMPERATURE (°C) SUPPLY SUPPLY MAX4684 LOGIC THRESHOLD VOLTAGE...
  • Page 6: Pin Description

    0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Pin Description NAME FUNCTION UCSP µMAX A1, C1 5, 7 Analog Switch—Normally Closed Terminal A2, C2 4, 8 Digital Control Input COM_ A3, C3 3, 9 Analog Switch—Common Terminal A4, C4 2, 10 Analog Switch—Normally Open Terminal...
  • Page 7 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP UCSP Package Consideration Mechanical stress performance is a greater considera- For general UCSP package information and PC layout tion for a UCSP package. UCSPs are attached through direct solder contact to the user’s PC board, foregoing considerations, please refer to the Maxim Application the inherent stress relief of a packaged product lead Note (Wafer-Level Ultra-Chip-Board-Scale Package).
  • Page 8 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Test Circuits/Timing Diagrams (continued) ∆V MAX4684 MAX4685 COM_ OR NO_ TO V Q = (∆V IN DEPENDS ON SWITCH CONFIGURATION; INPUT POLARITY DETERMINED BY SENSE OF SWITCH. Figure 4. Charge Injection 10nF OFF-ISOLATION = 20log NETWORK...
  • Page 9: Package Information

    0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Package Information (The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.) _______________________________________________________________________________________...
  • Page 10 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Package Information (continued) (The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.) 4X S INCHES MILLIMETERS 0.043 1.10...
  • Page 11 0.5 Ω /0.8 Ω Low-Voltage, Dual SPDT Analog Switches in UCSP Package Information (continued) (The package drawing(s) in this data sheet may not reflect the most current specifications. For the latest package outline information, go to www.maxim-ic.com/packages.) PIN 1 ID C0.35 [(N/2)-1] x e PIN 1...
  • Page 12 Maxim reserves the right to change the circuitry and specifications without notice at any time. ____________________Maxim Integrated Products, 120 San Gabriel Drive, Sunnyvale, CA 94086 408-737-7600 © 2003 Maxim Integrated Products Printed USA is a registered trademark of Maxim Integrated Products.
