Summary of Contents for Geckodrive G213V
- Page 1 G203V / G213V MANUAL STEP MOTOR DRIVE...
-
Page 2: Product Dimensions
PRODUCT DIMENSIONS PHYSICAL AND ELECTRICAL RATINGS Minimum Maximum Units Supply Voltage Motor Current Power Dissipation Short Circuit Trip Temperature °C Humidity Motor Inductance Input Frequency Step Pulse “0” Time Step Pulse “1” Time Direction Setup (Before step rising edge) Direction Setup (Hold after pulse rising edge) Signal Voltage Weight... - Page 3 Thank you for purchasing the G203V drive. The G203V is Geckodrive’s new generation CPLD-based microstep drive. It has short- circuit protection for the motor outputs, over-voltage and under-voltage protection, over-temperature protection, reversed power supply polarity protection and will survive accidental motor disconnects while powered-up.
- Page 4 TERMINAL 10 Common Connect the controller’s GROUND to this terminal. TERMINAL 11 Current Set Connect one end of your current set resistor to this terminal. TERMINAL 12 Current Set Connect the other end of your current set resistor to this terminal. POWER SUPPLY WIRING TERMINAL 1 Power Ground...
- Page 5 CAUTION! Avoid shorting the motor leads to each other or to ground or the G203V will enter protective shut-down. 4-wire, 6-wire and 8-wire motor may be used. If 6-wire motors are used, they may be connected in half winding or full winding. This is equivalent to an 8-wire motor connected in parallel or series.
-
Page 6: Other Considerations
OTHER CONSIDERATIONS: HEATSINKING: The G203V needs heatsinking for current settings greater than 3 amps. The case temperature (measured on the bottom plate) should not exceed 70 degrees C, and for best life should be kept at 50C degrees or less. Use heatsink compound between the G203V and your heatsink. -
Page 7: Troubleshooting
The fuse used is manufactured by Littelfuse with manufacturer part number 0251005.MXL and can be purchased from Digi-Key (www.digikey.com) or you can contact Geckodrive and we can send you some. EVERYTHING IS CONNECTED, RED INDICATOR STAYS LIT: If the RED and GREEN indicator LEDs are lit then the motor is miswired, the motor has a wire shorted to ground, is shorted to another motor wire or the motor is bad. -
Page 8: Technical Support
This section applies only if you purchased a G213V or have installed a G901X step pulse multiplier. A G203V without a step pulse multiplier has a fixed 10 microstep resolution. ADJUSTING MICROSTEP RESOLUTION The G213V has an onboard step pulse multiplier called the G901X that allows the drive to operate in full step, half step, 5 microstep and 10 microstep modes. - Page 9 (714) 832-8874 Email: support@geckodrive.com An extensive library of application notes and FAQs is located on the Geckodrive website under the “Support” tab. If you have a suggestion for an application note please email the above address. DISCLAIMER CERTAIN APPLICATIONS USING POWER PRODUCTS MAY INVOLVE POTENTIAL RISKS OF DEATH, PERSONAL INJURY OR SEVERE DAMAGE TO PROPERTY.
