3.3

Technical data of QV II Quench Valve

Compressed-air connection:
Compressed-air supply:
Compressed-air monitoring:
Commissioning pressure:
Minimum operating pressure:
Voltage supply:
®MINI
4. EXKOP
4.1

Installation notes

®

The EXKOP

Safety Controller is delivered completely wired in a housing with
lockable door. The controller should be installed in an easily visible location in a dry,
heated room.
Supply voltage variations (24 VDC) in the range of +/-10 % are acceptable. Power
consumption approx. 100 W.
In the case of higher voltage supply variations or extreme transient spikes, the use of
a main filter and/or voltage stabilizer is recommended.
The connecting cables to the transformer isolated barrier KFD2-ST2-Ex1.LB are
monitored for open-circuit and short-circuit.
Faults are indicated by means of LED's cause the immediately closing of QV II
Quench Valve.
For trouble-free operation, we recommend the use of shielded cables at the inputs of
®MINI
the EXKOP Safety Controller, since disturbing pulses can be produced in
industrial plants through the use of high-current or high-voltage cables and high
inductance or capacitance.
The maximum cable length between the EXKOP
control components (QV Quench Valve, bursting disc,
®
Q-Rohr etc.) must not exceed 600 m.
The regulations of VDE100 (or equivalent) must be observed.
Safety Controller
page 9 of 25
G1/4" at pressure reducer
Minimum 6 bar
Via pressure switch at tank,
®MINI
signal to EXKOP
5.5 bar
5.0 bar
®MINI
24 V DC via EXKOP
Safety Controller (max 100 W)
®
Safety Controller and individual
Safety Controller
GBB-EXKOM-08157/3
