Summary of Contents for Medical Breakthrough 7
- Page 1 MASSAGE CHAIR USER MANUAL...
- Page 2 Please keep this manual for future use.
- Page 3 Congratulations on purchasing this massage chair. Please read and follow all safety and operating instructions listed in this user manual prior to use. Basic precautions should always be used when operating an electrical appliance. Note: We reserve the right to make changes to information published in this document, including without limitation to specifications and product descriptions, at any time and without notice.
- Page 4 Contents Safety precaution Parts name Methods of installation Pre-work before massage Features Bluetooth and APP Trouble shooting Specifications...
- Page 5 Return the appliance to the manufacturer for examination and repair. 7. Do not unplug the appliance by pulling on the power cord. To disconnect, turn the power switch to the Off position, and then remove the plug from the outlet. Do not use wet hands to unplug.
- Page 6 5.Do not insert your hand or foot along the paths of the massage rollers during use. 6.Stop immediately if you experience any discomfort. 7.Do not use when under the influence of prescription drugs, alcohol, or substances. 8.Do not apply massage rollers directly on the head, elbow, joints, or abdomen.
- Page 7 Safety Precaution Medical Conditions Please consult your physician prior to use if you: Are under medical rest. Have spinal disorders, an abnormal spinal condition or have suffered a spinal injury. Have excessive back pain and severe back conditions. Have diabetes, osteoporosis or sensory impairment. Have a malignant tumor.
- Page 8 Name of each component Pillow Shoulder massager Backrest Remote controller pocket Armrest Leg part Base cover...
- Page 9 Method of installation Installation (1) Step 1: Unpack the main body box. Carry out the main body, leg part and accessory box. When carrying out the main body, we suggest at least two people help. Main body Leg part Pillow Accessory box Step 2: Unpack the armrest box Take out the armrest and base cover.
- Page 10 Method of installation Installation (2) Step 4: Installation the wheels Insert the wheels into the iron tube which is on the lower back of the main body. Fix it with screws.
- Page 11 Method of installation Installation (3) Step 5: Install the lining iron of the leg part. Fix the front part of the iron with dowels as pictured. Fix the back part of the push rod with dowels in the same way. Connect the above part to the seat frame then fix with screws.
- Page 12 Method of installation Installation (4) Hung the leg part to the leg part adapter of the main body, and then fix it with pins and a blocker. Zip up the leather case between the leg part and cushion.
- Page 13 Method of installation Installation (5) Step 7: Install the base cover Insert the bottom of the base cover to the connector on the base frame of the main body from top to bottom. (Note: The whole base as below) Fix it with screws.
- Page 14 Method of installation Installation (6) Step 8: Install armrest Lift the front part, then aim the side parts card at the fixed axis of the main body (as part 1 in the picture). Pull the spring hook and push inward hardly to fix. Set the armrest closely to the main body (as picture 2).
- Page 15 Method of installation Installation (7) Connect the air hose and power cord to the main body. The correct method Finally, insert the fixed block (as picture 3) into the fixed axis of the main body from the top to the bottom.
- Page 16 Method of installation Installation (8) Connect the connecting line of the remote controller to the main body. Step 9: Install the back cushion Lay the back cushion flat on the main body (as the above picture), then close the zipper at the top.
- Page 17 Confirm and adjust before usage. Space needed. Make sure there is 10 cm of space from the back to the wall or another obstacle, and 25 cm of space from the front. Before using, make sure the power cord is not knotted, entangled with other stuff or crushed under the main body;...
- Page 18 Confirm and adjust before usage New features Zero gravity: By adjusting the angle of the backrest, seat and leg part, the chair can offer a zero gravity position, which makes the massage more powerful and maximizes the relaxation that you'll feel. Foot roller: Equipped with 3 rows of rollers, covers the whole sole, offers a real Thai scraping massage.
- Page 19 Remote controller instruction...
-
Page 20: Remote Controller Instruction
Remote controller instruction Instruction of the buttons Power: On/Off key to the whole chair. Press this key and the chair will start to work (default massage time is 20 minutes), press it again, and the chair will shut down and go back to the reset position. - Page 21 Remote controller instruction Lifting up the backrest By long pressing this key, the backrest will be lifted up Lifting down the backrest By long pressing this key, the backrest will be lifted down. Airbag key Turn On/Off the airbag massage system by pressing this key. Heating key Press this key, and the heating system will be turned on and the heating icon on the display will be lit up.
- Page 22 Remote controller instruction Manual mode Click the “Menu” button, then choose “Manual” to start the manual program. Use the Up/Down key to choose, and then press OK to confirm. Massage method: In this subdirectory, you can use the Up/Down key to choose. There are six massage methods: Kneading, Tapping, Knocking, Shiatsu, Rolling, and Combination.
- Page 23 Remote controller instruction Foot roller Choose roller in the subdirectory. You can adjust the roller speed, offering 3 grade as an option. Setting Press “Menu” key, choose “Setting,” then enter the subdirectory. Time: Setting Work time, offer 10 minutes, 20 minutes, 30 minutes for the option.
- Page 24 Remote controller instruction Tips: 1. Under auto/manual mode, the display will switch to the home page after 10 seconds without any operation. Home page while Home page while under manual mode under manual mode Tips: During working it, press “Menu” twice. It will go back to the home page immediately.
- Page 25 Bluetooth and APP The massage chair can be operated via a Bluetooth enabled Andriod or iOS device. Please scan the QR code listed below to install a remote App first. Android Display Music This chair allows you to display music on it via any Bluetooth enabled device.
- Page 26 Bluetooth and APP App Opera ng Guide Now that you've installed the remote app, and your device has connected to the massage chair successfully, the chair is almost available for wireless opera on. All you need to do is open the app, and press the Bluetooth icon on the home screen, and connect it to the "massager"...
