Introduction

6
Modal CRAFTsynth 2.0 is a portable monophonic 8 oscillator wavetable synthesiser.
It features 45 morphable waveforms, 16 oscillator modifiers, a state-variable filter, a
36 destination modulation matrix with 8 modulation slots, two audio rate LFOs and a
programable sequenced arpeggiator.
SPECIFICATION:
• Monophonic wavetable synthesiser
• 8 oscillators in total with 2 selectable waveforms and mixer stage
• 40 unique waveforms available split into 8 banks of 5 morphable waveform sets plus a
sine/noise bank available on Wave 2 only
• VA, digital and generative waves are available along with selections from the Modal 002
• Process and cross modulate waveforms with 1 of 16 oscillator modifiers including
Frequency / Phase Modulation, Hard / Window Sync, Ring / Amp Modulation, Derez /
Bitcrush, Wavefolders and Waveshapers - Oscillator modifiers are applied to Wave 1. In
some cases, such as for FM or AM, Wave 2 is used as the modulating signal for Wave 1
• Multi option Unison / spread to detune the 8 oscillators for a huge sound
• 3 x envelope generators for Filter, Amplitude and Modulation
• 2 x audio rate LFOs
• 8 slot modulation matrix with 8 sources, each source can have 1 destination. (LFO1,
LFO2 and MOD-EG assignable from CRAFTsynth, Velo, Note, ModW, AftT and Expression
assignable from MODALapp)
• Program and transpose patterns with the built in sequenced arpeggiator
• 2-pole resonant filter that can be morphed from low pass, through band pass, to high
pass
• Delay and distortion (waveshaping overdrive, not bitcrushing) effects
• Optional MIDI clock sync for LFOs and Delay
• 64 preset storage locations
• 8 key touch MIDI keyboard with 8 selectable scales and root note selection
• MIDI DIN in and out
• Analogue clock sync in and out (configured to the KORG / Teenage Engineering
specification)
• Class compliant MIDI provided over USB connection to host computer or tablet
• Headphone and line output Powered by USB or 3 x AA batteries
• Optional software editor available for macOS, Windows, iOS and Android
• Portable and compact design
• Dimensions: 150mm x 135mm x 68mm (6"x5 1/2"x 3")
