Lfos - Modal CRAFTsynth 2.0 User Manual

Modulation
CRAFTsynth 2.0 has a comprehensive Modulation Matrix with 8 Modulation Sources and 36
Modulation destinations.
These Mod slots can be used to assign a fixed combination of modulation sources to
destinations, 8 modulation sources can be assigned to a single destination, or any other
combination thereof.
The Mod Matrix is additive - Modulation values are added or subtracted from the modulated
parameter value and limited to the parameter range. If a parameter is at 0, negative
modulation values will not be audible until the parameter value is increased. The opposite is
true for parameters at max value.
All modulation depths are bipolar, meaning sources can be inverted using negative depths.
When multiple mod slots are assigned to the same destination, the modulation from all
assigned slots is summed and limited before being applied.
LFO-1, LFO-2 & the MOD-EG can all be assigned to destinations from the front panel by
holding their buttons on the touch pad and turning the desired encoder in a positive or
negative direction. Depths for these 3 assignments can also be adjusted using PRESET + either
ATTACK, DECAY or SUSTAIN for Mod Slot Depth 1,2 or 3 respectively.
Note, Velocity, Modwheel, Expression and Aftertouch can all be assigned within MODALapp
when your device is connected.
Valid combinations are listed here:
Parameter LFO1 LFO2 MOD-EG
Wave 1
Wave 2
Mix
Global Pitch
Osc2 Pitch
Osc-Mod
LFO1 Rate X
LFO2 Rate X
LFO1 Shape X
LFO2 Shape X
Cutoff X
32
NOTE VELO AFTT MODW CC
Modulation
Parameter LFO1 LFO2 MOD-EG
Reso
Morph
FEG Amount
FEG Attack X
FEG Decay X
FEG Sustain X
FEG Release X
AEG Amount X
AEG Attack X
AEG Decay X
AEG Sustain X
AEG Release X
MEG Amount X
MEG Attack X
MEG Decay X
MEG Sustain X
MEG Release X
Distortion
Delay
Time
Feedback
Spread
Glide X
LFO1-Depth X
LFO2-Depth X
MOD-EG-Depth X
Scaling
LFO1 and LFO2 are scaled such that if they are assigned with maximum depth and the
modulated parameter is at it's centre value, the full parameter range will be modulated.
All other modulation sources are scaled such that if they are assigned with maximum positive
depth and the modulated parameter is at 0, the full parameter range will be modulated.
NOTE VELO AFTT MODW CC
33
