Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
CORDLESS DRILL
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
20V MAX
Model # 49120
bit.ly/wenvideo
(M-F 8AM-5PM CST)
Advertisement
Related Manuals for Wen 49120
Summary of Contents for Wen 49120
- Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.
- Page 2 Electrical Information Know Your Drill Operation Maintenance Exploded View Parts List Warranty TECHNICAL DATA Model Number: 49120 Charger Input Voltage: 120V, 60 Hz, 0.5A, 60W Charger Output Voltage: 20V, 2.0A, 40W Battery Specs: 20V Max, 1.5 Ah Torque Settings: 19+1 Max Torque: 35 N.m...
-
Page 3: General Safety Rules
You know the drill. The purpose of the following safety symbols is to attract your attention to possible dangers. We don’t want any of our beloved WEN customers accidentally injuring themselves. The safety symbols and the explanations with them deserve your careful attention and understanding. The safety warnings do not by them- selves eliminate any danger. - Page 4 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, knowing how your item works, and not doing dumb stuff on purpose. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
- Page 5 GENERAL SAFETY RULES 15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-resistant rubber-soled foot- wear. Keep the floor clear of oil, scrap, and other debris. 16. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean and in good working order. Follow instruc- tions for lubricating and changing accessories.
- Page 6 SAFETY RULES FOR BATTERIES 10. Do not operate the charger or the battery if it has received a sharp blow, either from being dropped or damaged. Take it to a qualified service technician before attempting to use. 11. Do not disassemble the charger or the battery pack. Take these to a qualified service technician when service or repairs are required.
- Page 7 SAFETY RULES FOR CHARGERS CHARGER Protect the battery charger and its cord from damage. Keep the charger and its cord away from heat, oil and sharp edges. Electrical plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with grounded appliances.
-
Page 8: Grounding Instructions
ELECTRICAL INFORMATION GROUNDING INSTRUCTIONS IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides the path of least resistance for an electric current and reduces the risk of electric shock. This tool is equipped with an electric cord that has an equipment grounding conductor and a grounding plug. -
Page 9: Know Your Drill
KNOW YOUR DRILL Two-Speed Gear Switch Torque Ring Directional Switch & Safety Keyless Chuck Strap Work Light Trigger Metal Belt Clip Battery Power Indicator Battery Battery Release Quick Charger UNLESS OTHERWISE SPECIFIED: FINISH: DEBURR AND DO NOT SCALE DRAWING REVISION DIMENSIONS ARE IN MILLIMETERS BREAK SHARP SURFACE FINISH:... - Page 10 OPERATION INSTALLING OR REMOVING THE BATTERY Look, we both know that you understand how to put this battery into the drill. It’s not rocket science. I’m going to tell you anyway though because once these manuals stop needing to be written, then I’m out of a job. 1.
- Page 11 OPERATION CHUCK Your drill is equipped with a single sleeve keyless chuck, so you can quickly change bits with no extra tools re- quired. To install bits, place the reversing switch in the OFF position and unplug the battery from the tool. Rotate the chuck’s body counterclockwise to open the chuck jaws to a point where the opening is slightly larger than the desired bit size.
- Page 12 EXPLODED VIEW...
-
Page 13: Exploded View
EXPLODED VIEW No. Part Number Part Description Qty. No. Part Number Part Description Qty. 49120-001 Screw 49120-028 Planetary Gear 49120-002 Right Label 49120-029 Sun Gear 49120-003 Right Housing 49120-030 Planetary Gear 49120-004 Battery Power Indicator 49120-031 Sun Gear 49120-005 Light Bulb... - Page 14 LIMITED TWO YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
