Comfort Flame Westerly32ZMN Installation And Operation Instructions Manual

Vent-free remote control gas fireplace system
Hide thumbs Also See for Westerly32ZMN:

Advertisement

P/N 900568-00 REV. B 04/2018
P900568-00
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
This is an unvented gas-fi red heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Air for Combustion and Ventilation
section on Page 5 of this manual.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other
appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer, service agency or the gas supplier.
Installation and Operation Instructions
Vent-Free Remote Control Gas Fireplace System
PFS
Models
®
US
Report No. F12-047
Westerly32ZMN
Westerly32ZMP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Westerly32ZMN and is the answer not in the manual?

Questions and answers

Summary of Contents for Comfort Flame Westerly32ZMN

  • Page 1 Installation and Operation Instructions Vent-Free Remote Control Gas Fireplace System P/N 900568-00 REV. B 04/2018 Models ® Westerly32ZMN Westerly32ZMP P900568-00 Report No. F12-047 INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not prohibited by local codes.
  • Page 2: Table Of Contents

    Thank you for your purchase. We appreciate your Unpacking ..................4 Product Features ................4 business! Air for Combustion and Ventilation ..........5 Please carefully read and follow all instructions in this manual. Pay Installation ..................7 special attention to all warnings and safety information. Operation ..................
  • Page 3 SAFETY Continued 1. WARNING: This appliance is only for use with the type of gas WARNING: Do not use a blower insert, heat ex- indicated on the rating plate. This appliance is not convert- changer insert or other accessory not approved for ible for use with other gases.
  • Page 4: Product Identifi Cation

    PRODUCT IDENTIFICATION COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS These appliances are approved for installation in the US state of Massachusetts if the following additional requirements are met: 4-Piece • Un-vented Room Heaters shall be installed in accordance with Log Set 527 CMR 30. •...
  • Page 5: Air For Combustion And Ventilation

    AIR FOR COMBUSTION AND VENTILATION hour (4.8 m per kw) of the aggregate input rating of all appliances WARNING: This heater shall not be installed in a installed in that space. Rooms communicating directly with the space room or space unless the required volume of indoor in which the appliances are installed*, through openings not furnished with doors, are considered a part of the unconfi...
  • Page 6 AIR FOR COMBUSTION AND VENTILATION Continued A. Rework worksheet, adding the space of an adjoining room. If the Ventilation Air From Outdoors extra space provides an unconfi ned space, remove door to adjoining Provide extra fresh air by using ventilation grills or ducts. You must room or add ventilation grills between rooms.
  • Page 7: Installation

    INSTALLATION NOTICE: This appliance is intended for supplemental WARNING: This appliance is equipped for either heating. Use this heater along with your primary heat- natural gas or propane/LP gas but not both. Gas type ing system. Do not install this heater as your primary is indicated on the rating plate.
  • Page 8 INSTALLATION Continued ASSEMBLING AND ATTACHING BLACK TRIM INSTALLATION CLEARANCES IMPORTANT: If you are recessing the fi rebox in a wall, do not attach WARNING: Maintain the minimum clearances. If you trim at this time. See Page 11. can, provide greater clearances from fl oor, ceiling and NOTE: The instructions below show assembling and attaching trim to fi...
  • Page 9 INSTALLATION Continued CONVENTIONAL FIREPLACE INSTALLATION 7. Break off nailing fl anges (see Figure 11) with hammer or pliers. Conventional installation of this fi replace involves installing fi replace 8. Place cardboard or other protective material on top of hearth along with the corner, face or cabinet mantel with hearth base acces- base.
  • Page 10 INSTALLATION Continued BUILT-IN FIREPLACE INSTALLATION 4. Connect wires from the electrical box to duplex outlet. Match wire colors to those indicated on duplex outlet. Be sure to connect Built-in installation of this fi replace involves installing fi replace into a ground wire.
  • Page 11 INSTALLATION Continued Mantel Clearances for Built-In Installation Support Bracket If placing mantel above built-in fi replace, you must meet minimum clearance between mantel shelf and top of fi replace opening. NOTICE: If your installation does not meet the minimum clearances shown, you must do one of the following: •...
  • Page 12 INSTALLATION Continued INSTALLING GAS PIPING TO FIREPLACE LOCATION Check your building codes for any special requirements for locating equipment shutoff valve to fi replaces. WARNING: This appliance requires a 3/8" NPT Apply pipe joint sealant lightly to male NPT threads. This will prevent (National Pipe Thread) inlet connection to the pres- excess sealant from going into pipe.
  • Page 13 INSTALLATION Continued CONNECTING FIREPLACE TO GAS SUPPLY Flexible Gas Line Log Base Installation Items Needed Assembly • 5/16" hex socket wrench or nut-driver • Phillips screwdriver • sealant (resistant to propane/LP gas, not provided) Screw 1. Remove 2 screws that hold fi replace screen in place for shipping. These screws are located near top of screen.
  • Page 14 INSTALLATION Continued CHECKING GAS CONNECTIONS PRESSURE TESTING FIREPLACE GAS CONNECTIONS 1. Open equipment shutoff valve (see Figure 22). WARNING: Test all gas piping and connections, 2. Open main gas valve located on or near gas meter for natural gas internal and external to unit, for leaks after installing or open propane/LP supply tank valve.
  • Page 15 INSTALLATION Continued INSTALLING LOGS 3. Locate the notches in bottom of front log (#3). Place front log on grate fi ngers. Make sure notches of front log line up with grate fi ngers (see Figure 27). CAUTION: Do not remove the data plates attached 4.
  • Page 16 INSTALLATION Continued Installing Cover Plate Onto Remote Receiver INSTALLING BATTERIES IN REMOTE CONTROL AND RECEIVER 1. Locate and remove cover plate from packaging. 2. Make sure sliding selector switch fi ts over switch on receiver. WARNING: Make sure your selector switch is in 3.
  • Page 17: Operation

    OPERATION FOR YOUR SAFETY WARNING: Damper handle will be hot if heater READ BEFORE LIGHTING has been running. WARNING: If you do not follow these instructions WARNING: Burners will come on automatically exactly, a fi re or explosion may result causing property within one minute when the control valve is in the ON damage, personal injury or loss of life.
  • Page 18 OPERATION Continued 9. Slightly push in and turn control knob counterclockwise TO TURN OFF GAS the ON position. TO APPLIANCE 10. Press the on/off key on the remote control to turn on appliance main burner. Wait at least 5 seconds before setting desired fl ame 1.
  • Page 19 OPERATION Continued FLAME HEIGHT This function allows you to control the height of the fl ames through 5 levels. Select manual fl ame height function by pressing MODE button until a fl ame is shown in lower left corner of display. Use the UP/DOWN arrow button to set desired fl...
  • Page 20 OPERATION Continued SMART THERMOSTAT CHILD SAFETY LOCK-OUT The Smart Thermostat adjusts fl ame height in accordance to dif- This function lets you deactivate the remote control buttons. It is ferences between set temperature and room temperature. As room active when the lock icon is lit on the display. temperature gets closer to set temperature the smart function will To activate, press MODE button and UP arrow button at the same modulate the fl...
  • Page 21: Inspecting Burners

    INSPECTING BURNERS Check pilot fl ame pattern and burner fl ame patterns often. MAIN BURNER Periodically inspect all burner fl ame holes with the fi replace running. All PILOT FLAME PATTERN slotted burner fl ame holes should be open with yellow fl ame present. All round burner fl...
  • Page 22: Cleaning And Maintenance

    CLEANING AND MAINTENANCE WARNING: Turn off fi replace and let cool before Primary Air Inlet Burner cleaning. Holes (Shape of Tube Holes May Vary by Model) CAUTION: You must keep control areas, burner and circulating air passageways of fi replace clean. Inspect these areas of fi...
  • Page 23: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off heater and let cool before servicing. Only a qualifi ed service person should service and repair heater. CAUTION: Never use a wire, needle or similar object to clean ODS/pilot. This can damage ODS/pilot unit. NOTE: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY...
  • Page 24 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Burner does not light after ODS/pilot is lit 1. Inlet gas pressure is too low 1. Contact local natural or propane/LP gas company 2. Burner orifi ce(s) clogged 2. Clean burner(s) (see Cleaning and Main- tenance, Page 22) or replace burner orifi...
  • Page 25 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •...
  • Page 26: Specifi Cations

    SPECIFICATIONS SERVICE HINTS Westerly32ZMN When Gas Pressure Is Too Low • Rating (Variable): 23/33,000 Btu/Hr • pilot will not stay lit • Gas Type: Natural Gas • burner will have delayed ignition • Ignition: Piezo • fi replace will not produce specifi ed heat •...
  • Page 27: Wiring Diagram

    WIRING DIAGRAM Black Connectors Receiver White To Thermopile CAUTION: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous opera- tion. Verify proper operation after servicing. 900568-00B ComfortFlame.us.com...
  • Page 28: Parts

    PARTS MODELS WESTERLY32ZMN AND WESTERLY32ZMP Cat. No. Model Description 32" with ProFlame F2506 Westerly32ZMN Remote,Millivolt, NG 32" with ProFlame F2507 Westerly32ZMP Remote,Millivolt, LP ComfortFlame.us.com 900568-00B...
  • Page 29 WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. Westerly32ZMP Westerly32ZMN KEY NO. CATALOG NO. DESCRIPTION F2506 F2507 QTY.
  • Page 30 PARTS FIREBOX WESTERLY32ZMN AND WESTERLY32ZMP ComfortFlame.us.com 900568-00B...
  • Page 31 PARTS FIREBOX WESTERLY32ZMN AND WESTERLY32ZMP This list contains replaceable parts used in your fi replace. When ordering parts, follow the instructions listed under Replacement Parts on Page 26 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 32: Accessories

    ACCESSORIES Purchase these accessories from your local dealer. If they can not supply these accessories contact IHP at ComfortFlame.us.com for information. CAT NO. MODEL DESCRIPTION BLOWER ACCESSORY KIT Manual variable control and automatic thermostat variable control. A blower will increase air fl...
  • Page 33 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 900568-00B ComfortFlame.us.com...
  • Page 34 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ _____________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ComfortFlame.us.com 900568-00B...
  • Page 35: Warranty

    Brand Gas Fireplace, Stove and Insert 20 Year Limited Warranty THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Comfort Flame ® Brand gas fi replace or insert ("Product") to be free from defects in materials and workmanship at the time of manufacture. The product body, fi rebox and barrier carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only.
  • Page 36 ComfortFlame.us.com Record the following important information about your appliance: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name IHP reserves the right to make changes at any time, without notice, in design, materials, specifi...

This manual is also suitable for:

Westerly32zmp
