- Page 1 SM 1690 SM1690T for line 3 x 400V SM1690U for line 3 x 480V SWITCHING POWER GENERATOR WITH EMBEDDED MICROCONTROLLER FOR 10 KW MAGNETRON H 0915 TECHNICAL NOTE (issue December 2013)
- Page 2 (Cover Rear)
-
Page 3: Ce Declaration
SM 1280 SM 1690 SM 1690 CE Declaration of Conformity Dichiarazione di Conformità CE Manufacturer’s Name: ALTER s.r.l Nome del Costruttore: Manufacturer’s Address: Via Curie, 8 - 42122 Reggio Emilia - Italy Indirizzo del Costruttore: Declare that the microwave generator: Dichiara che il Prodotto: product name: SM1690 (power supply) and TM100 (microwave generator head) -
Page 4: Rohs Conformity
SM 1690 Alter’ policy about Reduction on Hazardous Substances (RoHS) and Waste Electrical and Electronic Equipment (WEEE) Law Reference • Directive 2002/96/EC of European Parliament (WEEE) • Directive 2002/95/EC of European Parliament (RoHS) • Decreto Legislativo D.L. n. 151 – 25/07/2005 (WEEE and RoHS) At the present date 99% of components in our stock is RoHS compliant. -
Page 5: Table Of Contents
SM 1280 SM 1690 SM 1690 Contents General Informations Alarm troubleshooting 16, 17 This equipment satisfy the European Standard EN 61010-1 With reference to EN 61010-1 standard, note: Bit alarm table 13 this appliance must be installed and serviced only by qualified personnel. -
Page 6: General Description
SM 1690 Handling Warnings MICROWAVE ON (BLUE): ON when microwave is emitted (Enabling command The SM1690x has two handles on the front panel to help is ON) unpacking and handling operations: never use only the ALARM (RED): ON when an alarm state is handles to lift the equipment but support the weight with present. -
Page 7: Equipment Ratings
SM 1280 SM 1690 SM 1690 SM 1690 Ratings & Specifications Description Units Value Function Note SM1280T: Line input nominal: 3x400 Power input, 3 phase + GND CONN #1, pin 2-3-7 Working voltage range 360÷440 See wiring schematic Max Absolute voltage: Input Current, max: @400V input, full power SM1280U: Line input nominal:... -
Page 8: Cleaning
SM 1690 Fuses specifications Environmental & Physical Characteristics: Use: Indoor use only, within industrial The SM1690x has 2 fuses installed on the rear panel (look at enclosure the drawing on page 4, pos. 8): both fuses, labelled F1 and Working temperature range 5÷40°C [41÷104°F], Min-Max F2, protect the output line powering the remote head. -
Page 9: Equipment Installation
SM 1280 SM 1690 SM 1690 Equipment installation Wiring instructions The SM1690x cannot operate on a bench: it must be installed The SM1690x must be installed and serviced only by quali- into a proper cabinet like a commercial 19” standard enclo- fied personnel acquainted with the regulations covering the sure. -
Page 10: Power-Up Procedure
SM 1690 XIII) The external circuit breaker must be marked as the At power on the unit enters into a “BOOTLOADER” state for disconnecting device for the SM1690x. few seconds to allow firmware upgrade, then it goes imme- XIV) The connector #1 must never be used as a switch-off diately into “STAND-BY”... -
Page 11: Firmware Upgrade
SM 1280 SM 1690 SM 1690 : starts microwave emission at the presetted power level Important remark: at power-on, even if a program is already while the led “MW ON” is lighted up. stored, the microprocessor enters a “BOOTLOADER” status, The unit exits from this mode in case of: lasting 2 seconds, during which it is possible to overwrite, * the enabling command is set OFF: enters into Ready state, or... -
Page 12: Internal Settings
SM 1690 Internal settings M416.1 CONNECTORS, TEST-POINTS, LEDS The SM1690x comes in the default settings with all TRIMMERS, DIP-SWITCHES, JUMPERS the SW1 switches= OFF and switch 3 of SW2= OFF: nevertheless some working parameters can be modifyed RS232 INTERFACE using internal dip-switches. CPU POWER DIP-SWITCH#2 DIP-SWITCH #1 (on board M416.x: see position on next... -
Page 13: Conn.# 1 Wiring
SM 1280 SM 1690 SM 1690 Connector # 1 wiring 1690T id32273156 pdfMachine by Broadgun Software - a great PDF writer! - a great PDF creator! - http://www.pdfmachine.com http://www.broadgun.com RS232 connector wiring 1690 File: SM1690_r5eng - Dec. 2013 - Technical note: SM1690 page 11 of 18... -
Page 14: Conn.# 3, 4, 5 Wiring
SM 1690 Connector # 3,4,5 wiring page 12 of 18 File: SM1690_r5eng - Dec. 2013 - Technical note: SM1690... -
Page 15: Bit Alarm Table
SM 1280 SM 1690 SM 1690 Connector # 6 wiring BIT 3 BIT 2 BIT 1 BIT 0 Description [22] [ 9] [21] [ 8] No alarm Magnetron Overtemperature Rack Overtemperature MONITOR SIGNALS Arc Detection (on head) valid for all versions Overcurrent Overvoltage On the “D”... -
Page 16: Components Layout
SM 1690 COMPONENT LAYOUT page 14 of 18 File: SM1690_r5eng - Dec. 2013 - Technical note: SM1690... -
Page 17: Components List
SM 1280 SM 1690 SM 1690 Component list (See drawing pag.14) Description Note Pos. Q.ty CPU board M416 800000416/1690 Driver board M311 800000311/1690 Power board M409 800000409 Fan, 230V VE2GRE120/6221R Fan capacitor 2µF CR202A450 Not present LED board M417 800000417 Magn. -
Page 18: Alarm Troubleshooting
SM 1690 ALARM TROUBLESHOOTING Code Description Cause/Solution a) Check water flow and incoming water temperature b) Check magnetron thermoswitch (contact grounded=OK, open=alarm) Magnetron Over c) Check setting of magnetron thermocouple: if latter isn’t Temperature present the alarm threshold must be set = 0 d) Check air flow. -
Page 19: Alarm Troubleshooting
SM 1280 SM 1690 SM 1690 ALARM TROUBLESHOOTING Code Description Cause/Solution Low Air If it isn’t used the related input must be grounded. Pressure If used, contact grounded=OK, open=alarm Check head air filter. from head If it isn’t used the related input must be grounded. Low Water Flow If used, contact grounded=OK, open=alarm from head... -
Page 20: How To Order
SM 1690 How to order Power supplies: SM1690x.yyy1b, where: T for 400V, U for 480V yyy: don’t care, it’s the code we use for customized unit; j (version code): 1 : BUS (standard) version fol- lowed by the type of bus b (bus type) MTCP= Modbus-TCP CAN= CANOpen...
