5.3 Indirect Cylinders

Figure 2: Indirect cylinders components & dimensions
DIMENSIONS
(A) Height (mm)
(B) Secondary return connection (mm)
(C) Primary coil upper connection (mm)
(D) Cold inlet connection (mm)
(E) Primary coil lower connection (mm)
OPERATING DATA
Cold water capacity (litres)
Weight when full (kg)
Standing heat loss (kWh/24h)
COIL PERFORMANCE (EN12897)
Primary coil rating @ 15L/min (kW)
Primary coil pressure drop @ 15L/min (mbar)
Heat up time by primary coil (mins)
FICHE DATA
Supplier Name
Supplier Model Identifier
Energy Efficiency Class
Standing Loss (W)
Storage Volume (litres)
Table 3: Indirect cylinder data
Hot Outlet (22mm)
Temperature & Pressure
Relief Valve (15mm)
Secondary Return (22mm)
Cold Inlet (22mm)
Immersion Heater
Primary Coil Thermostat
Primary Coil Connections (22mm)
952 1142 1327
n/a n/a n/a
462 462 532
412 412 482
362 362 432
120 150 180
140 180 210
1.15 1.31 1.40
17.5 17.2 21.3
54 54 67
19.1 24.9 24.7
IN120 IN150 IN180
A B B
36 55 58
115 146 175
Page 6 of 23
30°
30°
1517 1767
1223 1473
532 532
482 482
432 432
210 250
250 290
1.66 1.92
19.9 22.2
67 67
31.4 33.6
Warmflow
IN210 IN250
B C
60 84
205 245
Ø550
20°
2077
1783
532
482
432
300
350
2.07
20.4
67
41.4
IN300
C
86
290
