Summary of Contents for King Canada Excelsior XL-1014
- Page 2 King Canada service center. Contact your retailer or visit our web site at www.kingcanada.com for an updated listing of our authorized service centers. In cooperation with our authorized serviced center, King Canada will either repair or replace the product if any part or parts covered under this warranty which examination proves to be defective in workmanship or material during the warranty period.
- Page 3 1. KNOW YOUR TOOL 12. ALWAYS WEAR SAFETY GLASSES. Read and understand the owners manual and labels affixed to Always wear safety glasses (ANSI Z87.1). Everyday eye- glasses only have impact resistant lenses, thet are NOT the tool. Learn its application and limitations as well as its spe- cific potential hazards.
- Page 4 GETTING TO KNOW YOUR OVERARM BLADE COVER 1. Dust collection hose. 9. Boom mount pin (1 of 2). 2. Hose clamp (1 of 2). 10. Boom mount. 3. Blade cover mounting bracket. 11. Diagonal brace (1 of 2). 4. 3” diameter inner telescopic boom. 12.
- Page 5 ASSEMBLY IMPORTANT NOTE This Overarm Blade Cover System is designed to fit 10” to 14” table saws which have a wood or melamine table extension installed. This system is uni- versal and may require minor modification and/or special mounting which may differ from the assembly instructions in this manual.
- Page 6 ASSEMBLY & ADJUSTMENTS Installing diagonal braces from boom mount to extension table continued... 4) Now that the diagonal braces are fully assembled, swing the diagonal braces to the underside of the extension table. Mount the 90 brackets to the inner sides of the extension table.
- Page 7 ASSEMBLY & ADJUSTMENTS Extending the telescopic inner boom 1) The main boom comes with a 3” diameter inner telescopic boom (A) Fig.9 which slides out of the main 4” boom. Loosen boom lock knob (B) and ex- tend the inner boom to the desired distance over the blade. Do not over- tighten the boom lock knob, very little pressure is needed to secure boom.
