- Page 1 PX 163 MATRIX DRIVER 48 x 500mA Manual...
-
Page 2: Table Of Contents
8. Technical data......................9. Declaration of Conformity ..................Manufacturer reserves the right to make modifications of the product in order to improve device operation. tel.: +48 12 626 46 92 PXM s.c. fax: +48 12 626 46 94 ul. Przemysłowa 12 E-mail: info@pxm.pl... -
Page 3: Safety Conditions
1. General desription The PX163 is a 48-channel driver for RGB matrix systems. Matrix Driver 48 x 500mA is perfect device to control of illumination of big areas composed of many modular elements. The facades - LED screens or illuminated floors can be used as an example. -
Page 4: Product Description
3. Product description DMX CHANNEL Control outputs: 48 (OUTPUTS) DMX output (DMX OUT) DMX input (DMX IN) GND input: 4 (GND IN) Power supply input: 5 (VCC IN) Power supply outputs: 16 (VCC OUT) Power and DMX status LEDs... -
Page 5: Connection Scheme
4. Connection scheme 12V power supply 12V DC power supply Receivers are connected to the outputs and power supply, as shown in the figure above. For each line you can determine number of light sources, depending on the wattage and the carrying capacity of each line is 500mA max. -
Page 6: Dmx Address Setting
5. DMX address setting DMX CHANNEL PX 163 is using 48 consecutive DMX channels. Address of the first channel is set in binary code using a switch DMX CHANNEL. Setting the value is accomplished by adding the value of component bits. Here are some examples of setting the start address. -
Page 7: Dimensions
7. Dimensions 1 2 3 4 5 6 7 8 9 8. Technical Data DMX channels: power supply: 7 - 24V DC current consumption: 24A max. number of output channels: outputs load capacity: max. 0,5 A / channel dimensions: width: 158 mm height: 140 mm depth: 35 mm... -
Page 8: Declaration Of Conformity
PXM s.c. Address of producer: ul. Przemysłowa 12 30-701 Kraków, Poland declares that the product: MATRIX DRIVER 48 x 500mA Name of product: PX 163 Type: answers the following product specifications: EMC: PN-EN 55103-1 PN-EN 55103-2 Additional informations: 1. GND wire of the power cable must be connected to an efficient grounding system.
