- Page 1 250 Industrial Tower Double Width Tower Assembly Guide Product Information and Assembly Guide...
- Page 2 This document will provide all users of Lewis Access Towers with Additional items, such as steps or conventional ladders, must a complete guide to the erection of the Lewis SW (Double Width) never be used to gain further height from the platform. The tower Aluminium Tower, employing the 3T (Through the Trap) method.
- Page 3 Assembly Procedure Double Width Tower Assembly Instructions Prepare the frame adjacent to the frame in 1.2. Prepare the frame for assembly. Insert the adjustable leg, then the castor into the bottom of the frame. Insert the Adjustable Leg, and then the castor into the bottom of the frame. Clip the horizontal brace onto the frame.
- Page 4 Assembly Procedure Clip the second brace in the same position, on the other side of the frames. Make sure the Clip the diagonal braces onto the lowest rungs. base is level using a sprit level. Any alterations needed, can be adjusted on the legs. Make sure the Trigger is facing the outside of the frame.
- Page 5 Assembly Procedure 1.12 When fitting the stabilisers, position ach one in opposing directions, Adjust all four castors 1.15 o ensure the tower is square and level – You can use a spirit level here to check. 1.13 1.16 Stabilisers must be in opposing directions to ensure full stability of tower. 1.14 1.17 Ensure spring clips are located in the locked position.
- Page 6 Assembly Procedure 1.18 Attach the trap door platform approx. 2.2m above ground level. This will be on the 8th 1.21 Climb internally up the rungs of the frame through the trap door platform. site with feet through Rung, if you started to build the tower with an 8 Rung Section. If you started to build the the platform, so they are resting on the rung of the frame.
- Page 7 Assembly Procedure 1.24 1.27 At this point, a platform height of 2.2m has now been built. 1.25 Clip the diagonal braces into position. 1.28 To continue building higher, fit the next set of frames on either side. 1.26 Stand on the platform and ensure the guardrail are securely in place, at the opposite end 1.29 Clip the diagonal braces into place.
- Page 8 Assembly Procedure 1.30 Ensure the frame clips are securely in place. 1.33 Climb through the trap door, as you did at point 1.21m. stay sitting on the platform, with feet rest on the rung below. 1.34 Place the handrails securely into place whilst sitting. 1.31 Insert the platform, once the braces are securely in place.
-
Page 9: Further Information
Dismantling Unit 1 Bellingham Trading Estate To dismantle the LEWIS Double Width tower, first remove the toeboard set and send safely down the tower. Remove the furthest Franthorne Way of the four guardrails and diagonal brace. Go directly to the trapdoor platform next to the ladder frame to remove the braces completely.
