Before Applying Power
✓
Checklist
INTEGRATED SUPPRESSION MODULE
TM
Field Testing: Your ISM has been carefully tested before leaving the factory .
However, the performance of this unit as a surge suppression device can be
confirmed in the field prior to startup using a portable DTS-2 Tester .
The optional DTS-2 Tester may have been purchased along with your ISM or
Field Startup Testing Service may have been specified during the purchase of
the ISM . Check with the owner or owner's representative to see if this test is
required at your site .
If you have questions about Field Startup Testing or would like to
arrange for this service, call Current Technology
800.238.5000.
Confirm Pre-Installation Checklist: Confirm that the "Pre-Installation
Checklist" found in the beginning of this manual was completed correctly
before proceeding .
Confirm Line Voltage: Measure the line to line voltages feeding the
panelboard or disconnect and be sure they are within ±10% of the rated
line voltage of the ISM . Use the following table to determine the range of
acceptable voltages for each model of the ISM .
ISM
MODEL NO.
ISM-xxx-240-2G-x
ISM-xxx-208-3Y-x
ISM-xxx-380-3Y-x
ISM-xxx-480-3Y-x
ISM-xxx-600-3Y-x
ISM-xxx-240-3H-x
ISM-xxx-240-3D-x
ISM-xxx-480-3D-x
ISM-xxx-600-3D-x
Note: "X" specifies filtering option. None if blank.
W A R N I N G !
Do not apply power if the measured voltage is not within the range
specified for the ISM model being installed.
Table 3: Acceptable Voltage Ranges for All ISM Models
Technical Support at
®
NOMINAL -10% TO +10%
L-L VOLTAGE L-L VOLTAGE
240 216 to 264
208 188 to 228
380 342 to 419
480 432 to 528
600 540 to 660
240 216 to 264
240 216 to 264
480 432 to 528
600 540 to 660
