- Page 1 Operating Manual Neptun SC1...
-
Page 2: Important - Read First
Ensure that any contact between (household) animals Intended use and the machine is excluded. HEUTE® sole cleaning machine Neptun SC1 is used to clean closed For safety reasons please pay attention that during shoes and boots outside by means of an electrical driven brush and use of the rolling brush no laces and straps will touch hand brush as well. -
Page 3: Table Of Contents
Transport and assembly Water connection The manufacturer herewith confirms that the following machine Waste water connection of type Neptun SC1 complies with the directives listed below: Electrical connection - EC Machinery Directive (2006/42/EC) Precaution while commissioning - EC EMV Directive (2004/108/EC) -
Page 4: Overview
Overview Control cabinet Dimension: 250 x300 x 150 mm Hand brush with flexible PVC hose and ball valve 1/2" Power supply 400 V, 3-phase + grounding 50Hz P=0,18kW PVC hose to protect electrical cables (length 2 m) Brush ø 150 mm, can be easily removed without any tool for cleaning Access to dosing system of detergent /... - Page 5 Water connection for hand brush 755 mm nylon roller brush grid, when closed lockable ø 150 mm, length 330 mm by bracket clamping platform to store detergent canister Inlet for PVC hose (to protect electrical cables) Inlet for transparent silicone hose / dosing system Water inlet 1/2"...
-
Page 6: Installation And Commissioning
Installation and commissioning Waste water connection - Outlet ø 38 mm (Fig .2) - Provided with an access flap at the piping General information Please follow below mentioned advices to protect the stainless Fig. 2 steel housing of the sole cleaning machine during storing, before installation, commissioning and use. -
Page 7: Operation
Operation Adjustment of water quantity The requested water quantity is adjustable by the valve (Fig. 6). The medium position allows a water flow of about 4 litres/minute. How to clean - Cleaning of shoes/boots with horizontal roller brush (Fig. 3) Fig. -
Page 8: Use Of Hand Brush
(Fig. 9). Medium opening allows service technicians. To secure optimal functioning of the sole clean- a water flow of abt. 6 litres/minute. ing machine, it should be contolled in regularly intervalls. HEUTE sole cleaning machines are service reduced and reliable. However, there Fig. 8 are some components which will wear after long period of time and/ or reduce the cleaning result. -
Page 9: Recommended Service Intervals
Recommended service intervals Cleaning surfaces Below mentioned intervals are based on our experience. However, The surface is made of stainless steel type 304. any single case could vary from each other. That is the reason why Cleaning should be done with intensive water rinsing. you have to adapt the intervals according to your own experience. -
Page 10: Disassembling Of Brush Axle
Disassembling of brush axle Access to the gear motor Remove roller brush (see section "Service and maintenance" > The cover at the rear is not fixed. Change of roller brush) Just remove the cover vertical up. No tools are required (Fig. 16). Remove inbus screw placed at the long side in front of the brush with suitable tool (Fig. -
Page 11: Dosing System - Access
The dosage of detergent/disinfectant is done by nozzles in different Dosing system – access sizes – supplied with the machine (Fig. 18). To achieve the desired Remove the cover by opening the bracket clamping – no tools concentration choose the corresponding nozzle (see below scheme). required (Fig. -
Page 12: Dosing System - Activation
Dosing system – activation Activation of detergent/disinfectant happens by water rinse of the system During initial operation put the filter device located at the end of the transparent silicone hose into the detergent canister (Fig. 19) – not belonging to the machine. Detergent/disinfectant should not contain chlorine bleaching ingredients because it could damage the surface, brushes and other components. -
Page 13: Trouble Shooting
Trouble-shooting only by qualified personnel Machine does not work Power supply interrupted or malfunction of components. Contact qualified personnel Canister is empty Take a full one Liquid is semifluid Try to absorb clear water. If the machine runs properly, dilute the liquid before the canister and/or take a different nozzle... -
Page 14: Technical Data
Trouble-shooting only by qualified personnel Machine operates without water Water supply is closed or interrupted Check water supply Machine does not drain off waste water Water outlet is blocked Check water outlet - if necessary remove blockage Motor stops or runs unproperly Foreign objects inside Unplug immediately the machine from power supply. -
Page 15: Wiring Diagrams
Wiring diagrams Neptun SC1 Wiring diagram I 56010020 GV2ME04 0,4-0,63A 10x38 NO/03-9 0.5aM 230+400V ABL6TS04B 40VA LC1K0610B7 -KM1 03-9 56015005 10x38 Motor NSYPLM3025 Power 0.18KW SCHNEIDER ELECTRIC Power connection Current rating ..A 24V AC Motor for brush push button Wiring diagram II... - Page 16 Configuration clamping strip I -ALIM IG:1 Conductor 1 02-1 IG:3 Conductor 2 Power supply 02-2 IG:5 Conductor 3 02-2 Conductor 4 Configuration clamping strip II AU:21 Conductor 1 03-5 Conductor 2 Emergency push button 03-5 Conductor 3 -FDC FDC:1 Conductor 1 03-9 Conductor 2 Safety switch (grid)
-
Page 17: Parts Drawing
Part drawings Neptun SC1 Item Article Article No. Coupling stainless steel + spring, 6 x 6 x 30 mm 06800101 Axle for brush, ø 150 x 330 mm, stainless steel 304 06800102 Brush blue, ø 150 mm, length 330 mm PBT... - Page 18 Authoritative is, unless otherwise specified, only the technical base, at the time of delivery of the goods in combination with this manual, by Maschinenfabrik HEUTE GmbH & Co. KG. The products and their design are subject to constant changes / improvements. We reserve the right to apply technical changes, anytime.
