- Page 1 Mozart One User Manual TMB 24/7 Technical Support US/Canada: +1 818.794.1286 Toll Free: 1 877.862.3833 (877.TMB.DUDE) UK: +44 (0)20.8574.9739 Toll Free: 0800.652.5418 e-mail: techsupport@tmb.com...
-
Page 2: Product Overview
0-100% switch. When powered up, the fixture name and software version will show on the 7-segment display. Solaris Mozart One user manual version 1.2 041719 - 2 -... -
Page 3: Fuse Replacement
1. With a screwDriver turn the fuse cap counter-clockwise to remove fuse cap with fuse. 2. Replace fuse attached to fuse cap. 3. Reinsert fuse cap with new fuse and tighten clockwise. Solaris Mozart One user manual version 1.2 041719 - 3 -... -
Page 4: Dmx Connector Configuration For The Mozart Drive
DMX optically isolated splitter may result in deterioration of the digital DMX signal. Maximum recommended DMX data link distance between fixtures: 300 meters (984 ft.) DMX C ONNECTOR ONFIGURATION FOR THE OZART RIVE Solaris Mozart One user manual version 1.2 041719 - 4 -... -
Page 5: Fixture Linking
3. Proceed to connect from the Drive output as stated above to the input of the following Drive and so on. 4. Continue linking until the last fixture is conected in your DMX chain. IXTURE INKING Solaris Mozart One user manual version 1.2 041719 - 5 -... -
Page 6: Pixel Map
Follow these steps to set the internal fixture ID of Mozart One fixtures (1-10 in Regular mode, or 1-5 in HiPower mode) Press and hold <Set Address> button located at the back of the Mozart. Solaris Mozart One user manual version 1.2 041719 - 6 -... - Page 7 Using “DMX 1” for a starting address on the Mozart Drive, following are examples of the Mozart One fixture FIXTURE ID DMX CH 1 PIX FIXTURE ID DMX CH 1 PIX FIXTURE ID DMX CH 1 PIX Continue as necessary . . . Solaris Mozart One user manual version 1.2 041719 - 7 -...
-
Page 8: Rdm Functionality
RDM F UNCTIONALITY Mozart Drives have RDM functionality. Below are the RDM functions available in these devices. TMB has many options for RDM control of your devices: ProPlex RDMigo and IQ RDM Manager Software; ProPlex Striker; and ProPlex MasterFade. Additionally, ProPlex RDM Opto-Splitters and the ProPlex IQ product range offer many means of RDM over DMX data distribution. -
Page 9: Limited Warranty
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Please contact TMB and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 10: Specifications
-20°C - +40°C Control/Power Connectors In/Out - Amphenol M12 Dimensions (HxWxD) 4.6 x 5.6 x 6.3 in (118 x 141 x 160 mm) Weight 3.74 lb. (1.7 kg) Inches (mm) Solaris Mozart One user manual version 1.2 041719 - 10 -... - Page 11 5.3 x 7.9 x 10.7 in (135 x 202 x 272 mm) Dimensions w/o yoke (HxWxD) 3.4 x 7.7 x 10.7 in (87 x 196 x 272 mm) Weight 9.85 lb (4.5 kg) Solaris Mozart One user manual version 1.2 041719 - 11 -...
