- Page 1 User Manual “Modular” Seamless Multi-Format Switch Scaler with VGA, YPbPr, DVI and HDMI solutions HIT-3MF3HDMI-641RIPRO Поставщик: ПЕРВАЯ КАБЕЛЬНАЯ КОМПАНИЯ (495) 600-68-68, info@1-cable.ru, www.1-cable.ru...
-
Page 2: Copyright And Trademarks
COPYRIGHT AND TRADEMARKS All rights reserved by C&C TECHNIC TAIWAN CO., LTD. No part of this document may be reproduced in any form or by any means without written permission from the product manufacturer. Changes are periodically made to the information in this document. They will be incorporated in subsequent editions. -
Page 3: Before You Begin
BEFORE YOU BEGIN Follow all instructions marked on the device during using. Provide proper ventilation and air circulation and do not use near water. It is better to keep it in a dry environment. Place the device on a stable surface (example cart, stand, table, etc.). ... -
Page 4: Table Of Contents
Chapter 7 Switcher Application Software ................26 7.1 Software Introduction ....................26 7.1.1 Software Description ..................26 7.1.2 Software Activation ..................26 7.1.3 Connect HIT-3MF3HDMI-641RIPRO and PC ..........27 7.2 Switcher Configuration .................... 27 7.2.1 Main Operation Interface................28 7.2.2 Disconnect Function Key ................30 7.2.3 Options Function ................... - Page 5 7.3.1 Video Configuration ..................34 7.3.2 Device Status Information ................34 7.3.3 LAN IP Function .................... 35 7.3.4 Other Application................... 36 Chapter 8 Troubleshooting....................37 Appendix A IR Controller ....................... 39 Appendix B Firmware Upgrade .................... 40 Appendix C RS-232 Communication Protocol ..............43 D-1 Host Request ......................
-
Page 6: Chapter 1 Switcher System Overview
Through a standard TCP/IP connection with seamless integration in any existing network for easy remote access. With easy operation, the HIT-3MF3HDMI-641RIPRO Switcher allows you to use both pushbuttons and IR remote control to operate the device. Figure 1-1 HIT-3MF3HDMI-641RIPRO Switcher... -
Page 7: Packing
1.2 Packing HIT-3MF3HDMI-641RIPRO Switcher *1 RS-232 Communication Connected Cable *1 Power Cord *1 HDMI Cable *1 IR BOX*1 Female 1x5 Pole Captive Screw Socket * 1 Rack-Mount Bracket *2 Screws (for Brackets) *6 IR Remote Controller *1 Software CD *1 (Includes “AV Matrix Control Software”... -
Page 8: Chapter 2 Features
CHAPTER 2 FEATURES Supports seamless switching with zero second latency upon different resolutions. Flexible for having any combination of the preferred video (VGA, YPbPr, DVI or HDMI) modular cards and very easy to swap via 2 screws only. Up/down/cross converter equipped with VGA, YPbPr, DVI and HDMI inputs/ ... -
Page 9: Chapter 3 Specifications
CHAPTER 3 SPECIFICATIONS Hardware Flexible Input Modular Card 1 x VGA, 1 x YPbPr, 1 x DVI, 3 x HDMI Females Output Connector 1 x HDMI Type A Female, 1 x VGA HD15 Female RS-232 Connector 1 x DB9 Female RS-485 Connector LAN Connector 1 x RJ-45... -
Page 10: Chapter 4 Device Installation
CHAPTER 5 FRONT/REAR PANELS 5.1 Front Panel Figure 5-1 HIT-3MF3HDMI-641RIPRO Switcher Front Panel The HIT-3MF3HDMI-641RIPRO Switcher supports up to 6 switching keys on the Front Panel for indicating the connection status that allows you to switch connected sources quickly. Key1~6: Specifies the one of input channels that comes from VGA, YPbPr, DVI or HDMI1~4 interface to the HDMI or VGA output. - Page 11 Aspect: The HIT-3MF3HDMI-641RIPRO Switcher allows you to configure the Aspect ratio of the output image including Full and 1:1 Aspect. Figure 5-2 Full Aspect When the Full aspect for the output image is configured, the FULL LED indicator on the front panel will become solid green.
- Page 12 IR: Infrared receiver for the HIT-3MF3HDMI-641RIPRO Switcher. The longest distance of your IR remote controller to receive the signals is about 12 meters. Figure 5-4 IR Receiving Distance...
-
Page 13: Ir Remote Controller
5.2 IR Remote Controller Figure 5-5 IR Remote Controller Main Channel Port selection: Press the Number#1~6 button to select the key channel on the front panel. Example: Press the “5” button on the Remote controller specified the input signal of the key on the front panel comes from the channel#5 (HDMI INPUT 5 interface on the rear panel). -
Page 14: Rear Panel
5.3 Rear Panel Figure 5-6 HIT-3MF3HDMI-641RIPRO Switcher Rear Panel The HIT-3MF3HDMI-641RIPRO Switcher supports up to 6 input and 2 output jacks on the rear panel, each female terminal separately form the signal input and output jacks. flexible modules cards specified “INPUT1”... - Page 15 VGA cable. AUDIO OUT port: This port is connected to the speaker or other audio output devices HDMI OUT connector: The HIT-3MF3HDMI-641RIPRO Switcher Output connector is connected to the A/V, HDTVs or other output devices.
- Page 16 DVI connector host assignment: Pin # Signal Pin # Signal TMSD data 2- TMDS data 3+ TMDS data 2+ TMDS data 2/4 shield Ground TMDS data 4- Hot plug detect TMDS data 4+ TMDS data 0- DDC clock TMDS data 0+ DDC data TMDS data 0/5 shield Analog vertical sync...
-
Page 17: Chapter 6 Connections
CHAPTER 6 CONNECTIONS Figure 6-1 HIT-3MF3HDMI-641RIPRO Connections 6.1 Input/Output Connections Use the VGA/YPbPr/DVI/HDMI connecting cable to connect the Input modular card (INPUT1 ~ INPUT 6) on the rear panel to the output connector of the sources (CD/DVD player/Camera/ PS3/STB/PC). And use the HDMI or VGA connecting cable to connect the output connector (HDMI OUT/VGA OUT) on the rear panel to the input connector of the HDMI TV, displays, multiplexers and so on. - Page 18 Figure 6-3 Output Connection...
-
Page 19: Switcher System Remote Control
PC Browser. Figure 6-5 LAN port and Control PC Connection The HIT-3MF3HDMI-641RIPRO Switcher supports RS-232 and LAN port on the rear panel for a remote control and allows you to operate settings via the keys located on the... -
Page 20: Ir Connection
6.3 IR Connection The HIT-3MF3HDMI-641RIPRO Switcher provides you an IR receiver for more convenient to react to the controller. If it is difficult for you to aim at IR receiver on the front panel due to the location of Switcher, please connect it to the IR port located on the rear panel for optional position. -
Page 21: Ports And Switchers
6.5 Ports and Switchers HIT-3MF3HDMI-641RIPRO Switcher provides standard RS-232 serial communication port as well as LAN for remotely managing , and Dip Switch for locally setting. Besides the front panel is ideally for the local switching, managing and setting operation. - Page 22 Figure 6-8 (b) Figure 6-9 The Switcher RS-232 port is defined by DCE.
-
Page 23: Rs-485
6.5.2 RS-485 RS-485 is a standard defining the electrical characteristics of drivers and receivers for use in balanced digital multipoint systems. Digital communications networks implementing the RS-485 standard can be used effectively over long distances and in electrically noisy environments. The Switcher support up to two RS-485 ports allows you to control more than one relative Device. -
Page 24: Lan Port
6.5.3 LAN Port The HIT-3MF3HDMI-641RIPRO Switcher supports a network RJ-45 registered jack using 8P8C modular connector, which specifies the physical male and female connectors as well as the pin assignments of the wires in a telephone cable. (A common LAN cable is available.) Figure 6-12 LAN Port 6.5.4 DIP Switcher for 8 Pins... -
Page 25: Device Id Settings
C. DIP Switcher Pin 7: Switch between RS-232 port and LAN port connection. The default value is “OFF”. ON: RS-232 OFF: LAN D. DIP Switcher Pin 8: Reset the web server IP address to 192.168.0.3, the default value is “OFF”. The steps are as below: 1. -
Page 26: Dip Switcher For 2 Pins
01110 01111 10000 10001 10010 10011 10100 10101 10110 10111 11000 11001 11010 11011 11100 11101 11110 11111 6.5.6 DIP Switcher for 2 Pins Figure 6-14 DIP Switcher for 2 Pins DIP Switch RS-485 Terminator: RS-485 Terminator for ON/OFF ON: RS-485 Terminator ON. OFF: RS-485 Terminator OFF. -
Page 27: Chapter 7 Switcher Application Software
CHAPTER 7 SWITCHER APPLICATION SOFTWARE 7.1 Software Introduction The 《AV Matrix》 matrix control software applies to different input/output matrixes. 7.1.1 Software Description The 《AV Matrix》 matrix testing software is an application tool developed for matrix testing and application. The software operation environment is as below: Window7/98/2000/NT/XP/VISTA operating systems (For more information, please refer to:/software/readme.txt before the installation.) 32M internal memory or above... -
Page 28: Connect Hit-3Mf3Hdmi-641Ripro And Pc
7.1.3 Connect HIT-3MF3HDMI-641RIPRO and PC You must power off the HIT-3MF3HDMI-641RIPRO Switcher. Then, connect the Switcher RS-232 port to the PC RS-232 port with the bundled communication cable. And make sure the DIPs on the rear panel are set to Master and RS-232. (Refer to the previous section 6.5.1... -
Page 29: Main Operation Interface
Examples for selecting switching functions: Example: Now there is an HIT-3MF3HDMI-641RIPRO Switcher having all the input/ output ports properly connected to the equipment. If you want to set channel 1 VGA input to output displayer with HDMI OUT interface. Please follow the ways and... - Page 30 Audio Tab: Click the “Audio” tab to show the audio related configuration window. Video Tab: Click the “Video” tab to show the video related configuration window. Disconnect: To disable the connections. After you had configured the connection between input and output ports, you can click this button to disable the connections Select all: Click this button to select all output ports including HDMI OUT, VGA OUT and AUDIO OUT.
-
Page 31: Disconnect Function Key
7.2.2 Disconnect Function Key Disable all the unused output ports. A specific example of operation is described as below: The present input and output relations are shown in Figure 7-4 below: Figure 7-4 Disconnect Function Key... -
Page 32: Options Function
7.2.3 Options Function Activation Function: In the main configuration menu, select Options to prop-up the Options Window as shown in Figure 7-5（a） Figure 7-5 Options（a） Figure 7-5 Options（b） Function Description: Linking Methods: In “Port number” select one of the COM ports as shown in Figure 7-5（b）for a example;... -
Page 33: Lan Web Configuration
HIT-3MF3HDMI-641RIPRO Switcher is integrated HDMI switching equipment. You can only key in the Output Channel No. into the Video field for configuration. HIT-3MF3HDMI-641RIPRO Switcher’s Device ID is based on the DIP of switcher located on the rear panel. - Page 34 Upgrade: Use for firmware upgrade. For more information, refer to Appendix B Firmware Upgrade Options: Allow you to configure the IP address. Save: Click this button to save the connected combinations output and input ports. It also includes the present input/output switching relations and all settings. All Output: A Hot Key for you to set the same value to all output channels.
-
Page 35: Video Configuration
7.3.1 Video Configuration For video configuration, click Video button directly to pop-up “Video Settings” window. Figure 7-8 Video Operation In “Video Settings” window, you can click Change button to switch EDID Output1 and Default port. Figure 7-9 Video Configurations – Default port used ... -
Page 36: Lan Ip Function
Figure 7-12 Device Status Information 7.3.3 LAN IP Function In the main configuration menu, select Options button to pop-up the Browser ex. “Windows Internet Explorer” dialog box, click “OK” to show the IP configuration window as shown in Figure 7-13. Figure 7-13 Network Settings In the “Network Settings”... -
Page 37: Other Application
For this model, the software utility will show at least 1 up to 32 devices. The example as below shows you an ID: 0 for the Name: HIT-3MF3HDMI-641RIPRO Switcher presently. When the Console List is empty, please pay attention to the location of switcher pin on the rear panel of Device is correctly. -
Page 38: Chapter 8 Troubleshooting
CHAPTER 8 TROUBLESHOOTING 1. What to do if LCD is fail in display? Answer: Check the connection of power cord is not loosening and the power cord is in a good status having no any damage. Check the power source is normally. 2. - Page 39 6. What to do if the Switcher panel keys and communication ports are out of order? Answer: Check if the equipment power input is in good contact and the computer communication ports are in good order. If yes, it could be some internal failure of the product, please send for repair by qualified technical engineer.
-
Page 40: Appendix A Ir Controller
APPENDIX A IR CONTROLLER The HIT-3MF3HDMI-641RIPRO Switcher supports a remote controller allows you to remote switch which Input signal by passing through to current output with an extended connection - IR receiver/transmitter. The signal for controller is only available to the IR receiver connected to the IR hole located on the rear panel. -
Page 41: Appendix B Firmware Upgrade
APPENDIX B FIRMWARE UPGRADE This Chapter will introduce you how to upgrade firmware on your web browser. For firmware upgrade, you have to upload the firmware file to your web server and then upload it to your device from web server. Follow the steps as below to upgrade the firmware: 1. - Page 42 For 0: General selecting, you have to adjust the switcher ID on the real panel to “0” that means the device with ID “0” will be upgraded. 4. For 1: Switcher Device will allow you to select target device based on ID 0 to 31 for upgrading firmware.
- Page 43 6. After finishing firmware upgrade successfully, “Firmware Upgrade to Device Success” information will appear as below. Besides, the firmware upgrade will not stop even though the web connection is fail suddenly. Please check with the LCD screen to confirm the firmware upgrade has been finished successfully or wait at least 2 minutes then power off to restart your 7.
-
Page 44: Appendix C Rs-232 Communication Protocol
APPENDIX C RS-232 COMMUNICATION PROTOCOL This AV Matrix RS-232 communication protocol uses fixed length with 5 bytes of information as define below. The default baud rate is 9600 bps, no parity, 8 data bit and 1 stop bit. Command timeout is 300 ms, and byte to byte timeout is 30ms. Use the RS-232 connecting cable to connect the computer serial port to the RS-232 communication port of the Switcher device. -
Page 45: D-1.2 Request Byte
D-1.2 Request Byte Request Byte (RB) Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Request Type (0 - 63) Request Type: Please refer to "Table - Host Request List". 0: Reserve, Always 0. Table - Host Request List Request Description... - Page 46 0x15 Request Audio Output Bass Output Memory 0x16 Control Audio Output Treble Output Level 0x17 Request Audio Output Treble Output Memory 0x18 Control Audio Output Subwoofer Output Level 0x19 Request Audio Output Subwoofer Output Memory 0x1C Control Audio Output Delay Low Output Delay1 0X1D...
-
Page 47: D-1.3 Index Byte
D-1.3 Index Byte Index Byte (IB) Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Index Index: Please refer to "Table - Host Request List" and "Table - Command Index List". Table – Command Index List Index Description The output that will be selected. -
Page 48: D-1.4 Value Byte
D-1.4 Value Byte Value Byte (VB) Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Value Value: Please refer to "Table - Host Request List" and "Table - Command Value List". Table – Command Value List Value Description The input that will be connected. -
Page 49: D-1.5 Crc Byte
D-1.5 CRC Byte CRC Byte (CB) Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 CRC (cyclic redundancy check) CRC: Host must send CRC code to follow the last byte. Table – CRC Table 0A 0B BC E2 DD 83... -
Page 50: Device Ack Packet
CRC Calculation CRC 0 = 0 (initial value) CRC 1 = CRC_ TABLE [CRC 0 ^ Byte 1] = CRC_ TABLE [0x00 ^ 0x20] = 0x23 CRC 2 = CRC_ TABLE [CRC 1 ^ Byte 2] = CRC_ TABLE [0x23 ^ 0x01] = 0x9F CRC 3 = CRC_ TABLE [CRC 2 ^ Byte 3] = CRC_ TABLE [0x9F ^ 0x06] = 0x8D CRC 4 = CRC_ TABLE [CRC 3 ^ Byte 4] = CRC_ TABLE [0x8D ^ 0x03] = 0x93 D-2 Device ACK Packet... -
Page 51: D-2.2 Ack Type B
D-2.2 ACK Type B ACK Byte + LB + Index1 + Value1 + Index2 + Value2 +…..+ CRC Byte Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Device ID (0 – 31) Length for the total data bytes (Index + Value) IB n Index... -
Page 52: D-2.3 Ack Type C
D-2.3 ACK Type C ACK Byte + LB + Data 1 + Data 2 + CRC Byte (Total 5 Bytes) Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Device ID (0 – 31) Length for the total data bytes (This byte is always 2) DB 1 Data 1... -
Page 53: D-2.4 Ack Type D
D-2.4 ACK Type D ACK Byte + LB + INF + OP + IP + Name 1 + Name 2 + Name 3 +..+ CRC Byte Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Device ID (0 - 31) Length for the total data bytes (INFO +..+ Name n) -
Page 54: D-2.5 Ack Type E
D-2.5 ACK Type E ACK Byte + LB + EXTI + VIDI + AUDI + PLUG +..+ CRC Byte Name Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Device ID (0 - 31) Length for the total data bytes (EXINF +..+ DTMAX) LBMAX EXINF... - Page 55 BASS - Bass command flag. (Request 0x14 and 0x15) 1 - Support Bass command. 0 - Not support Bass command. TRE - Treble command flag. (Request 0x16 and 0x17) 1 - Support Treble command. 0 - Not support Treble command. SW - Subwoofer command flag.
