Page 1: Quick Start Guide
BOXCHIP S700A RADIO S700A UHF: 400-470mhz S700A VHF: 136-174mhz Quick Start Guide... -
Page 2: Boxchip S700A Radio
BOXCHIP S700A RADIO Thank you for purchasing the BOXCHIP S700A radio. This quick start guide will talk you through the basic features and functions of your new S700A radio. BOXCHIP S700A Overview Standard Included accessories: 1x Antenna (Model Dependent) •... - Page 3 S700 Series Antenna The BOXCHIP S700 series have three antenna styles depending on the radio model - don't be alarmed if yours looks different to the images online. S700A UHF: 400-470mhz Antenna • S700A VHF: 136-174mhz Antenna • S700B: Short Antenna •...
- Page 4 Dual SIM Card and Memory Card Installation Step 1: Remove the battery if pre- installed. (Follow the battery installation and removal procedure below if you are unsure how to do this) Step 2: Locate the black silicone cover which is located in the middle of the device.
-
Page 5: Battery Installation / Removal
Belt Clip Installation (If Required) Step 1: Place belt clip on top of the 2 corresponding belt clip installation holes at the rear of the device (just below the camera and BOXCHIP logo). Step 2: Screw both screws in but do not over tighten. - Page 6 Dock Charger (Optional Accessory) Step 1: Plug the appropriate USB C cable into the back of the dock and into the USB wall charging socket. Step 2: Slot the S700A or S700A battery into the dock as picture. Important: Please read the information label at bottom of the dock before charging for the first time.
- Page 7 BOXCHIP BiMR BiMR is BOXCHIP's powerful proprietary DMR and Analogue Software that allows you to receive or transmit utilising the devices built in VHF or UHF radio. Configuring the BiMR / BPS Software To configure your new radio simply download and install the BPS (BOXCHIP Programming Software) on your home computer or mac.
- Page 8 What PoC Software can be used with BOXCHIP Devices? For the very best BOXCHIP PoC experience we can confirm full compatibility with the following PoC providers: Walkiefleet • Eschat • Tassta • Mobiletorando • Proptt2 • Realptt. • Zello (lacks SOS functionality due to software limitations) •...
- Page 9 B O XC H I P I S A L E A D I N G G LO B A L M A N U FA C T U R E R O F I N T E L L I G E N T C O M M U N I C AT I O N S.
